F-219 SUPPLEMENT
YFT–20–05–H–08–SB
(1.27 mm) .050"
YFT–20–05–H–05–SB
YFT–40–05–H–10–SB
YFT SERIES
LOW-PROFILE OPEN-PIN-FIELD TERMINAL
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?YFT
Insulator Material:
Black Liquid Crystal
Polymer
Terminal Material:
Brass
Operating Temp Range:
-55 °C to +125 °C
Plating:
Au over 50 µ" (1.27 µm) Ni
Working Voltage:
275 VAC when mated with YFS
Mated Cycles:
200 with YFS
RoHS Compliant:
No
Lead-Free Solderable:
No
Mates with:
YFS
Five, eight
or ten rows
(1.27 mm)
.050"
pitch
Up to
500 pins
Low-profile
(5.00 mm) .197"
mated height
0 year m
Passed 2 gas testing.
FT
flowing
c.com?Y
ww.samte
Go to: w
ESULTS
TEST R
ixed
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
Tin-Lead
Solder Balls
TYPE
NO. PINS
PER ROW
05
PLATING
OPTION
ROW
OPTION
SB
OTHER
OPTION
DIFFERENTIAL
APPLICATION
(1.27) .050
(1.27)
.050
= Header
YFT
= –05, –08,
and –10 row
– 20
= 30 µ"
(0.76 µm)
Gold on post
–H
=Five Row
– 05
– 08
– 10
=Polyimide Film Pick
& Place Pad
–K
–30, –40, –50
= –10 row only
ARRAY
50x10
40x10
30x10
20x10
20x8
20x5
PAIR
COUNT
125
100
75
50
40
25
10
=Eight Row
=Tape & Reel
– TR
=Ten Row
(No. of pins/row x (1.27) .050)
+ (2.54) .100
(1.27) .050
500
YFT/YFW
MATED
HEIGHT
YFS
STACK HEIGHTS
(3.94)
.155
ALSO AVAILABLE
(MOQ Required)
• 30, 40 & 50 positions
in 5 & 8 rows
• 3 & 6 rows
Contact Samtec.
(1.27)
.050
01
491
No. of
rows
x
(2.67) (1.27)
.105 .050
+
(3.05)
.120
(0.41)
.016
DIA
(4.50)
.177
HEADER/
STACKER
YFT-05
YFW-07*
YFW-09*
YFW-12*
YFW-19*
YFW-25*
MATED
HEIGHT
(5.00) .197
(7.00) .276
(9.00) .354
(12.00) .472
(19.00) .748
(25.00) .984
Processing conditions
will affect mated height.
* See YFW Series for
specifications
(0.76)
.030
DIA
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
