F-219
IPS1–120–01–L–D–VS
IPS1–125–01–L–D
(2.54 mm) .100"
IPS1 SERIES
SHROUDED POWER CONNECTOR SET
SPECIFICATIONS
For complete specifications
see www.samtec.com?IPS1
Insulator Material:
Black LCP
Contact Material:
Phosphor Bronze
Plating:
Sn or Au over
50 µ" (1.27 µm) Ni
Operating Temp Range:
-55 °C to +105 °C with Tin;
-55 °C to +125 °C with Gold
Insertion Depth:
(3.81 mm) .150" to
(6.48 mm) .255"
Wiping Distance:
(0.38 mm) .015"
Voltage Rating:
775 VAC/1095 VDC
Standard Creepage:
(2.55 mm) .100" (without -LC)
(1.08 mm) .043" (with -LC)
Standard Clearance:
(1.75 mm) .069" (without -LC)
(0.62 mm) .024" (with -LC)
RoHS Compliant:
Yes
IPT1/IPS1
CURRENT RATING
(PER CONTACT)
5.9 A
4.8 A
4.1 A
3.6 A
2.3 A
Mates with:
IPT1
Each contact
individually
shrouded for
electrical and
mechanical
protection
CREEPAGE
AND CLEARANCE
(4.70 mm)
.185"
Selectively loading
contacts achieves customer
specific creepage and
clearance requirements.
Contact asp@samtec.com
Choice of
through-hole or
surface mount
• Individually
shrouded
contacts
• Locking clip
option
PINS
1
2
3
4
50
IPS1
1
NO. PINS
PER ROW
01
PLATING
OPTION
D
TAIL
OPTION
Leave
blank for
Through-hole
OTHER
OPTION
05, 10, 15, 20, 25
(Standard sizes)
PROCESSING
Lead–Free Solderable:
Yes
SMT Lead Coplanarity:
(0.13 mm) .005" max (05-10)*
(0.15 mm) .006" max (15-25)*
*(.004" stencil solution
may be available; contact
IPG@samtec.com)
= 10 µ" (0.25 µm)
Gold on contact,
Matte Tin on tail
–L
= Surface
Mount
–VS
= Locking Clip
(Manual
placement
required)
(–VS only)
–LC
= Right-angle
No. of positions x (2.54) .100
+ (0.38) .015
50
–RA
02
= (5.50 mm)
.217" DIA
Polyimide film
Pick & Place
Pad
(–VS only)
–K
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
FILE NO. E111594
(4.95)
.195
(2.54)
49
.100
(2.54)
.100
01
= Tape &
Reel
Packaging
(–VS only)
(7.87)
.310
–TR
Through-hole
Surface Mount
ALSO AVAILABLE
(MOQ Required)
•
•
•
•
Other sizes
Other platings
Latching feature
No. 1 position polarized
(2.54)
.100
(8.51)
.335
(3.81)
.150
(1.27)
.050
(2.54)
.100
(0.41)
.016
(0.51)
.020
(0.79)
.031
–VS
(2.54)
.100
–RA
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
