F-219 SUPPLEMENT
IPD1–10–D–K–M
CC79L–2630–01–L
IPD1–15–S–K
(2.54 mm) .100"
IPD1, CC79L, CC79R, PK-79 SERIES
DISCRETE WIRE CABLE COMPONENTS
SPECIFICATIONS
For complete specifications
see www.samtec.com?IPD1,
www.samtec.com?CC79L, or
www.samtec.com?CC79R
Keyed
polarization
Single or
double row
TOOLING
• Hand Tool (20-30 AWG):
CAT-HT-179-2030-13
• Mini Applicator
(20-24 AWG):
CAT-MC-179-2024-XX-01
• Mini Applicator
(26-30 AWG):
CAT-MC-179-2630-XX-01
• Extraction Tool:
CAT-EX-179-01
Metal or plastic
latch options
TYPE
POSITIONS
PER ROW
ROW
OPTION
K
–K
LATCH
OPTION
TYPE
WIRE
GAUGE
01
PLATING
OPTION
PK-79
• Replaces the CC79 contact
in the Mini Mate
®
housing
(IPD1) for customizable
polarization
• Plugs are molded black for
better visibility against the
white Mini Mate
®
housing
• PK-79 plugs are packaged
in standard 50 pcs/bulk bag
• Handle is easily removed
after insertion
• See
www.samtec.com?PK79
for complete specifications
IPD1
= Body,
Loose
(Standard sizes)
–02, –03,
–04, –05,
–06, –08,
–10, –12,
–15, –16,
–20, –25
= Single
Row
–S
= Double
Row
–D
= Keyed
Polarization
CC79L
= Contact,
Loose
= 26 to 30 AWG
–2630
–2024
= Metal Latch
(Metal for more
rugged
environments)
(–02, –05 & –10
positions only)
(Leave blank for
plastic latch)
–M
CC79R
= Contact,
Full Reel
(12,000
Parts
per Reel)
= 20 to 24 AWG
= 10 µ"
(0.25 µm)
Gold on
contact,
Tin on tail
–L
(12.83)
.505
–S
PK-79
–D
(7.24)
.285
–M
(1.57)
.062
DIA
(1.91)
.075
(3.17)
.125
(1.52)
.060
(17.93)
(3.81) .706
.150
Insulator Material:
Nylon 66
Due to technical progress, all designs, specifications and components are subject to change without notice.
Contact Material:
Phosphor Bronze
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
