I so l a t e d a nd Regula te d 5 WATT Mo dular DC/DC Conv erter s
5 Sided EMI Shielding
Regulated Outputs
1600V Isolation
Short Circuit Protection
4:1 Input Range
Input PI Filter
SB05
series
Unit measures 0.8”W x 1.25”L x 0.4”H
Model Number
SINGLE OUTPUT
SB05-123.3S
SB05-243.3S
SB05-483.3S
SB05-125S
SB05-245S
SB05-485S
SB05-1212S
SB05-2412S
SB05-4812S
SB05-1215S
SB05-2415S
SB05-4815S
SB05-1224S
SB05-2424S
SB05-4824S
DUAL OUTPUT
SB05-125D
SB05-245D
SB05-485D
SB05-1212D
SB05-2412D
SB05-4812D
SB05-1215D
SB05-2415D
SB05-4815D
Output Voltage
Output Amps
Input Range
3.3VDC
5 VDC
12 VDC
15 VDC
24VDC
1
1
1
1
1
1
0.416
0.416
0.416
0.333
0.333
0.333
0.208
0.208
0.208
+/-0.5
+/-0.5
+/-0.5
+/-0.208
+/-0.208
+/-0.208
+/-0.166
+/-0.166
+/-0.166
9-18 VDC
18.36 VDC
36-75 VDC
9-18 VDC
18-36 VDC
36-75 VDC
9-18 VDC
18-36 VDC
36-75 VDC
9-18 VDC
18-36 VDC
36-75 VDC
9-18 VDC
18-36 VDC
36-75 VDC
9-18 VDC
18-36 VDC
36-75 VDC
9-18 VDC
18-36 VDC
36-75 VDC
9-18 VDC
18-36 VDC
36-75 VDC
Order On-Line!
astrodyne.com
+/-5 VDC
+/-12 VDC
+/-15 VDC
WWW.ASTRODYNE.COM
300 Myles Standish Blvd., Taunton, MA 02780
Ph: 1-800-823-8082
Fax: 508-823-8181
I so l a t e d a nd Regula te d 5 WATT Mo dular DC/DC Conv erter s
INPUT SPECIFICATIONS
Input Voltage Ranges:
12 VDC Nominal
24 VDC Nominal
48 VDC Nominal
9-18 VDC
18-36 VDC
36-75 VDC
SB05
1600VDC
10-9nth Ohm min.
300Khz
series
GENERAL SPECIFICATIONS
Input-Out Isolation
Isolation Resistance
Switching Frequency
OUTPUT SPECIFICATIONS
Voltage and Current
Load Regulation
Line Regulation
Temperature Coefficient
Ripple/Noise(Single/Dual)
Voltage Accuracy
Short Circuit Protection
Efficiency
See Selection Chart
10% to FL
(HL-LL)
+/-0.02%/°C
0.7% +70mVp-p max.
+/- 2%
Continuous
123.3S, 125S, 125D,
243.3S, 245S, 245D,
483.3S, 485S,
485D
1212D, 1215D, 2412D,
2415D, 4812D, 4815D
1212S, 1215S, 1224S,
2412S, 2415S, 2424S,
4812S, 4815S, 4824S
ENVIRONMENTAL SPECIFICATIONS
Oper. Temperature
Storage Temperature
Cooling
-25 to +71°C(FL)
-55 to +105°C
*
Free Air Convection
+/- 1%
+/- 0.5%
PHYSICAL SPECIFICATIONS
Case Material
Construction
Weight
Nickel-Coated Copper with
Non-Conductive Base
Fully Encapsulated
0.9 oz, (25g)
78%
79%
81%
82%
All specifications are typical at nominal input, full load, and 25DegC unless
otherwise noted
*
These are stress ratings. Exposure of the devices to any of these conditions
may adversely affect long term reliability. Proper operation under conditions
other than the standard operating conditions is neither warranteed nor implied.
Astrodyne products are not authorized or warranteed for use
as critical components in life support systems, equipment used
in hazardous environments, nuclear controls systems, or other
mission-critical applications.
WWW.ASTRODYNE.COM
300 Myles Standish Blvd., Taunton, MA 02780
Ph: 1-800-823-8082
Fax: 508-823-8181
I so l a t e d a nd Regula te d 5 WATT Mo dular DC/DC Conv erter s
MECHANICAL DIMENSIONS
Pin #
2
3
9
10
11
14
15
16
22
23
Single Outputs
-Vin
-Vin
NC
NC
NC
+ Output
NC
- Output
+Vin
+Vin
SB05
Dual Outputs
-Vin
-Vin
Common
NC
- Output
+ Output
NC
Common
+Vin
+Vin
series
ALL DIMENSIONS IN mm
PIN PITCH TOLERANCE +/- 0.35mm
OUTPUT DERATING CURVE
WWW.ASTRODYNE.COM
300 Myles Standish Blvd., Taunton, MA 02780
Ph: 1-800-823-8082
Fax: 508-823-8181
