F-219 SUPPLEMENT
IPS6–04–01–L
CC10L–1012–L
(6.35 mm) .250"
PET–04–01–L–VT
IPS6, CC10, PET SERIES
DISCRETE WIRE COMPONENTS & TOOLING
SPECIFICATIONS
For complete specifications
see www.samtec.com?IPS6
or www.samtec.com?CC10
IPS6
POSITIONS
PER ROW
01
LATCH
TYPE
WIRE
GAUGE
PLATING
OPTION
TOOLING
• Hand Tool:
CAT-HT-310-1012-14
• Mini Applicator:
CAT-MC-310-1012-XX-02
–02, –04, –06, –08
No. of positions x (6.35) .250
+ (23.31) .918
(12.00)
.472
= Latch
–L
CC10R
= Contact,
Full Reel
= 10 to 12 AWG
–1012
CC10L
= Contact,
Loose
= 10 µ"
(0.25 µm)
Gold on
contact,
Matte Tin
on tail
–L
= Matte Tin
(32.50)
1.280
(27.00)
1.063
–T
(1.91)
.075
(3.81)
.150
(23.00) .910
(1.60)
.063 DIA
• Screw down
(right-angle)
Mates with:
PES, PESS
PET
SPECIFICATIONS
For complete specifications
see www.samtec.com?PET
Insulator Material:
Black LCP
Terminal Material:
Copper Alloy
Plating:
Sn or Au over
50 µ" (1.27 µm) Ni
Operating Temp Range:
-55 °C to +105 °C with Tin
-55 °C to +125 °C with Gold
Voltage Rating:
725 VAC/1025 VDC
RoHS Compliant:
Yes
Lead–Free Solderable:
Yes
NO. PINS
PER ROW
LEAD
STYLE
PLATING
OPTION
TAIL
OPTION
OTHER
OPTION
–02, –04,
–06, –08
ALSO AVAILABLE
(MOQ Required)
• Locking Clip
(Manual placement required)
• No Latch ears
• Other platings
= Use with
(1.60 mm) .062"
Thick PCB
–01
–02
= 10 µ" (0.25 µm)
Gold on contact,
Matte Tin on tail
–L
–T
= Vertical
–VT
= Use with
(3.18 mm) .125"
Thick PCB
= Matte Tin
= Right-angle
(Screw Down
option
required)
– RA
= Screw
Down
(Right-
angle only)
–SD
LEAD STYLE
A
(2.35) .093
(3.95) .156
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
FILE NO. E111594
–01
–02
No. of positions x (6.35) .250 + (16.51) .650
(11.43) .450
(6.35)
(2.70) .106
.250 TYP
(3.81)
.150 DIA
(14.62)
.575
(14.50)
.571
A
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
(2.54)
.100
(0.50) .020
(0.64)
.025 (0.64)
.025
A
(2.54) .100
(5.69)
.224
(23.50) .925
(2.54) .100
(5.54) .218
–VT
Due to technical progress, all designs, specifications and components are subject to change without notice.
–RA–SD
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
