F-219
ZLTMM–112–75–L–D–285
LTMM–110–02–F–D–RA
LTMM–113–02–T–D
(2.00 mm) .0787"
LTMM, ZLTMM SERIES
SHROUDED HEADER & STACKER
Mates with:
SQT, SQW, ESQT, SMM
LTMM
1
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?LTMM
or www.samtec.com?ZLTMM
Insulator Material:
Black Liquid Crystal Polymer
Terminal Material:
Phosphor Bronze
Plating:
Sn or Au over
50 µ" (1.27 µm) Ni
Operating Temp Range:
-55 °C to +105 °C with Tin;
-55 °C to +125 °C with Gold
RoHS Compliant:
Yes
NO. PINS
PER ROW
02
PLATING
OPTION
D
TAIL
OPTION
OTHER
OPTION
04, 05, 06, 07, 08, 10, 12,
13, 15, 17, 20, 22, 25
(Standard sizes)
(0.51)
.020
(2.00) .0787 x
No. of positions + (2.39) .094
02 04
= Gold flash
on post,
Matte Tin on tail
–F
Leave blank for
Through-hole
= Polarized
Position
–“XX”
–LC
= 10 µ" (0.25 µm)
Gold on post,
Matte Tin on tail
(6.00)
.237
–L
–T
= Right-angle
–RA
= Surface Mount
–SM
= Locking
Clip
(-SM only)
(Manual
placement
required)
PROCESSING
Lead–Free Solderable:
Yes
SMT Lead Coplanarity:
(0.10 mm) .004" max
= Matte Tin
(0.89)
.035
(0.38)
.015
(1.27)
.050
(7.79)
.307
(2.00)
.0787
(2.29)
.090
(1.52)
.060
(2.00)
.0787
(2.97)
.117
01 03
(2.00) .0787
(3.55)
.140
(4.80)
.190
(0.38)
.015
= (7.50 mm)
.295" DIA
Film Pick &
Place Pad
(-SM only)
–K
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
(0.51) .020 SQ
T/H
–SM
–RA
–SM
–RA
= Tape & Reel
(–SM only)
–TR
OTHER
SOLUTIONS
• Shrouded IDC headers and
stackers to mate with TCSD
Series. See STMM and
ZSTMM Series.
ZLTMM
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart.
PLATING
OPTION
D
BODY
HEIGHT
OTHER
OPTION
ALSO AVAILABLE
(MOQ Required)
• Other sizes
• Other platings
04, 05, 06, 07,
08, 10, 12, 13,
15, 17, 20, 22, 25
(Standard sizes)
(0.51)
.020
(2.00) .0787 x
No. of positions + (2.39) .094
02 04
= Gold flash on post,
Matte Tin on tail
–F
–“XXX”
= Body
Height
= Polarized
Position
MAX BODY
HEIGHT
(7.42) 0.292
–“XX”
= 10 µ" (0.25 µm)
Gold on post,
Matte Tin on tail
–L
–T
(6.00)
.237
(2.00)
.0787
01 03
= Matte Tin
(3.55)
.140
(2.00)
.0787
(4.80)
.190
(3.18)
.125
(3.05)
.120
BODY
HEIGHT
(6.35)
B
(OAL) .250
MIN
LEAD
STYLE
–75
–62
–65
–73
–63
–66
–69
–74
–70
–71
–72
B
(OAL)
(9.58) 0.377
(10.08) 0.397 (7.92) 0.312
(10.49) 0.413 (8.33) 0.328
(12.09) 0.476 (9.93) 0.391
(14.10) 0.555 (11.94) 0.470
(15.09) 0.594 (12.93) 0.509
(15.60) 0.614 (13.44) 0.529
(17.09) 0.673 (14.94) 0.588
(17.60) 0.693 (15.44) 0.608
(21.08) 0.830 (18.92) 0.745
(21.62) 0.851 (19.46) 0.766
(0.38)
.015
(0.51)
.020
SQ
(2.29)
.090
MIN
Note:
This Series is non-standard,
non-returnable.
Note:
For added mechanical stability,
Samtec recommends mechanical
board spacers be used in applications
with gold or selective gold plated
connectors. Contact ipg@samtec.com
for more information.
