F-219
PESC–02–40–02–01–L–VT
(6.35 mm) .250"
(PWR)
(2.54 mm) .100"
(SIG)
PETC–01–40–01–01–L–VT
PETC, PESC SERIES
40 A SIGNAL/POWER COMBO SYSTEM
SPECIFICATIONS
For complete specifications
see www.samtec.com?PETC
or www.samtec.com?PESC
Insulator Material:
Black LCP
Terminal Material:
Copper Alloy
Plating:
Sn or Au over 50 µ" (1.27 µm) Ni
Current Rating (Signal Pin):
5.7 A per pin
(4 pins powered)
Insertion Depth (Power Pin):
(5.00 mm) .197" to
(8.46 mm) .333"
Wiping Distance (Power Pin):
(0.38 mm) .015"
Operating Temp Range:
-55 °C to +125 °C for Au
-55 °C to +105 °C for Sn
Voltage Rating:
Signal: 450 VAC/636 VDC
Power: 650 VAC/919 VDC
Standard Creepage:
(3.66 mm) .144" (power)
Standard Clearance:
(3.31 mm) .130" (power)
RoHS Compliant:
Yes
Lead–Free Solderable:
Yes
PETC/PESC
POWER CURRENT RATING
PINS
(PER CONTACT)
1
31.4 A
2
28.0 A
3
24.4 A
4
22.9 A
PETC
POWER
PINS
SIGNAL
PINS
POWER
PINS
01
PLATING
OPTION
TAIL
OTHER
OPTION
–01, –02, –04
A
04
–12
–40
–01, –02, –04
= 10 µ" (0.25 µm)
Gold on contact area,
Matte Tin on tail
= Matte Tin
–L
–T
=Vertical
–VT
= Right-
angle
–RA
= Screw Down
(Right- angle
only)
–SD
–LC
(14.50)
.571
(11.43)
.450
01
(2.54)
.100
(0.64)
.025
SQ
(6.35)
.250
TYP
A
POWER
12
40
PINS/
END
SIGNAL SIGNAL
PINS
PINS
= Locking Clip
(Manual
placement
required)
–01
(14.62)
.575
–02
–04
(39.37) (57.15)
1.550 2.250
(52.07) (69.85)
2.050 2.750
(77.47) (95.25)
3.050 3.750
CREEPAGE
AND
CLEARANCE
(2.54)
.100
(2.35)
.093
–RA–SD
(0.50) .020
Selectively loading
contacts achieves customer
specific creepage and
clearance requirements.
Contact asp@samtec.com
PESC
POWER
PINS
SIGNAL
PINS
POWER
PINS
01
PLATING
OPTION
TAIL
OTHER
OPTION
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
–01, –02, –04
(11.43)
.450
A
–12
–40
04
–01, –02, –04
= 10 µ" (0.25 µm)
Gold on contact area,
Matte Tin on tail
= Matte Tin
–L
–T
=Vertical
–VT
= Right-
angle
–RA
= Screw
Down
(Right-
angle only)
–SD
ALSO AVAILABLE
(MOQ Required)
• Other signal pins
• Power pins
• Asymmetric power
pin placement
• Other platings
(12.00)
.472
(25.20) .992
(3.81) .150 DIA
= Locking
Clip
(Manual
placement
required)
–LC
(2.54)
.100
01
(6.35)
.250
TYP
(4.40)
.173
(12.00)
.472
–RA–SD
(12.64)
.497
(4.29)
.169
(2.54)
.100
Notes:
The number of power pins on
each end must equal.
Some sizes, styles
and options are non-standard,
non-returnable.
(2.54) .100
(0.79) .031 X (0.41) .016
(0.50) .020
(2.47)
.097
A
POWER
PINS/END
12 SIGNAL PINS 40 SIGNAL PINS
–01
–02
–04
(39.37) 1.550
(52.07) 2.050
(77.47) 3.050
(57.15) 2.250
(69.85) 2.750
(95.25) 3.750
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
