F-219
SIR1–15–L–S–A
SIB–120–02–F–S
(2.54 mm) .100"
SIB, SIR1 SERIES
ONE-PIECE INTERFACES
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?SIB
Insulator Material:
Black Liquid Crystal Polymer
Contact Material:
Phosphor Bronze
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
Current Rating:
2.6 A per pin
(1 pin powered)
Operating Temp Range:
-55 °C to +125 °C
RoHS Compliant:
Yes
SIB
1
NO. OF
POSITIONS
02
PLATING
OPTION
S
OPTION
02 thru 30
(Per Row)
= Gold flash on contact,
Matte Tin on tail
–F
= Locking
Clip
(Manual
placement
required)
–LC
No. of positions x (2.54) .100
(4.45)
.175
(8.51)
.335
01
PROCESSING
Lead-Free Solderable:
Yes
SMT Lead Coplanarity:
(0.10 mm) .004" max (02-19)
(0.15 mm) .005" max (20-30)*
*(.004" stencil solution
may be available; contact
IPG@samtec.com)
(1.13)
.044
(1.42)
.056
(0.38)
.015
(2.54)
.100
– LC
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
(3.81)
.150
(5.27)
.207
Note:
The SIB Series
is intended for vertical
mating only.
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
FILE NO. E111594
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?SIR1
Insulator Material:
Black LCP
Contact Material:
Phosphor Bronze
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
Current Rating:
2.8 A per pin
(1 pin powered)
Weld Tab:
Phosphor Bronze
RoHS Compliant:
Yes
SIR1
NO. OF
POSITIONS
PLATING
OPTION
S
OPTION
–03, –05, –10, –15
(Per Row)
No. of positions x (2.54) .100
+ (2.54) .100
(5.08)
.200
01
= 10 µ" (0.25 µm) Gold on contact,
Matte Tin on tail
–L
= Alignment Pin
–A
–K
= 30 µ" (0.76 µm) Gold on contact,
Matte Tin on tail
–S
= (4.00 mm) .157"
DIA Polyimide
Film Pick &
Place Pad
PROCESSING
Lead-Free Solderable:
Yes
SMT Lead Coplanarity:
(0.10 mm) .004" max
= Tape & Reel
–TR
(2.54)
.100
(2.54)
.100
(4.45)
.175
No. of positions x (2.54) .100
+ (1.016) .040
(0.50)
.020
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
FILE NO. E111594
(6.00)
.236
(0.25)
.010
(1.40)
.055
(2.25)
.089
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
