F-219 (Rev 19DEC18)
BSW–110–24–T–S
BSW–124–04–T–S–S
(2.54 mm) .100"
BSW–115–04–G–D
BSW SERIES
BOTTOM MOUNT SOCKET STRIPS
Mates with:
TSW, MTSW, HTSW,
MTLW, TSM, EW, ZW,
HW, DW, PHT
BSW
1
NO. PINS
PER ROW
LEAD
STYLE
PLATING
OPTION
ROW
OPTION
OTHER
OPTION
FEATURES
•
Bottom mount socket
strips accept .025" SQ
terminals.
•
Ideal for soldering and
plugging from the same
side of the board.
•
For low-profile
connections and high
temperature soldering.
02 thru 36
Z
(0.41)
.016
TYP
= Standard
Lead
–04
–24
= 10 µ" (0.25 µm)
Gold contact,
Matte Tin on tail
–L
= Standoffs
for single
and double
rows only.
–S
= Low
Insertion
Force
(8.89)
.350
= 20 µ" (0.51 µm)
Gold contact,
Gold Flash on tail
–G
–T
(0.38)
.015
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?BSW
Insulator Material:
Black Thermoplastic
Insulation Resistance:
5000 MW min
Contact Material:
Phosphor Bronze
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
Operating Temp Range:
-55 °C to +125 °C with Gold
-55 °C to +105 °C with Tin
Withstanding Voltage:
1000 VRMS @ 60 Hz
Insertion Depth:
(3.68 mm) .145" to
(6.35 mm) .250"
RoHS Compliant:
Yes
Lead-Free Solderable:
Wave only
(2.54)
.100
TYP
–S, –M
(0.79) .031
TYP
–D
= Matte Tin
(N/A with Low
Insertion Force)
(–S & –D only)
Row Option
–S*
–M
–D*
Z
(4.31) .170
(3.43) .135
(4.32) .170
*
Less (0.38 mm) .015" with standoffs
01
(No. of Pos. X (2.54) .100) + (0.51) .020
36
X
72
02
Y
–S
–M
= Single Row
–S
(2.54)
.100
(10.16)
.400
(2.54)
.100
Row
Option
–S
–D
X
(2.54)
.100
(3.81)
.150
Y
(5.08)
.200
(6.35)
.250
= Single Row
More Plug Space
–M
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
(2.54)
.100
71
01
–M
Body design may vary slightly
from drawing shown.
= Double Row
–D
FILE NO. E111594
APPLICATIONS
BSW
(SINGLE ROW)
BSW
(DOUBLE ROW)
EW
(SINGLE ROW)
COMPONENT
SIDE
ALSO AVAILABLE
(MOQ Required)
• Other platings
PC
BOARD
PC
BOARD
SOLDER
SIDE
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
TSW
(SINGLE ROW)
TSW
(DOUBLE ROW)
BSW
(SINGLE ROW)
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
