KEMET Organic Capacitor (KO-CAP
®
)
T52X/T530 Polymer Electrolytic Capacitors
Overview
The KEMET Organic Capacitor (KO-CAP) is a solid electrolytic capacitor with a conductive polymer cathode capable
of delivering very low ESR and improved capacitance retention at high frequencies. KO-CAP combines the low ESR of
multilayer ceramic, the high capacitance of aluminum electrolytic, and the volumetric efficiency of tantalum into a single
surface mount package. Unlike liquid electrolyte-based capacitors, KO-CAP has a very long operational life and high ripple
current capabilities.
The T52X/T530 provides the widest range of voltages, capacitance and case size options in the KO-CAP family and is
suitable for general purpose DC applications for up to 48 volt DC voltage rails.
Benefits
•
•
•
•
•
•
•
•
•
ESR values down to 5 mΩ
Stable capacitance across temperature and voltage
No aging effects
High ripple handling
Volumetrically efficient
High frequency capacitance retention
100% accelerated steady state aging
100% surge current tested
Halogen-free epoxy and RoHS compliant
Applications
Typical applications include DC/DC converters, audio/sound circuits (mobile phone and base stations, smart phones, MP3
players), power supply inputs, portable electronics (notebook PCs, displays, SSDs, HDDs and USBs, digital cameras, GPS
navigation systems, WiFi modules), telecommunications, consumer electronics (analytical and test equipment, high speed
servers), high voltage applications such as 12 V to 48 V power input rails, densely populated circuits with space restrictions,
microprocessor decoupling, and high ripple current applications.
One world. One KEMET
© KEMET Electronics Corporation • KEMET Tower • One East Broward Boulevard
Fort Lauderdale, FL 33301 USA • 954-766-2800 • www.kemet.com
T2076_T52X-530 • 4/16/2019
1
KEMET Organic Capacitor (KO-CAP
®
)
T52x/T530 Polymer Electrolytic Capacitors
Environmental Compliance
• RoHS Compliant (6/6) according to Directive 2002/95/EC when ordered with 100% Sn, Ni-Pd-Au or
non-magnetic 100% Sn solder
• Halogen-free
• Epoxy compliant with UL94 V-0
K-SIM
For a detailed analysis of specific part numbers, please visit ksim.kemet.com to access KEMET’s K-SIM software. KEMET
K-SIM is designed to simulate behavior of components with respect to frequency, ambient temperature, and DC bias levels.
Series Reference Selection
Series
Voltage Range
< 1 V to 9 V
Applications
T520
T521
T523
T525
T527
T529
T530
Standard
High Voltage
Facedown
Terminal
High Temperature
Small Size
Miniature
High Cap/
Low ESR
X
X
X
X
X
X
X
X
12 V to 48 V
Applications
*
X
X**
*
X
X
X
X
X
Temperature Rating
85°C Rated
X**
105°C Rated
X
X
X**
X
X
125°C Rated
Special Features
Miniature Size
Low ESL
X
X
X
* Not recommended for new design.
** Selected values.
© KEMET Electronics Corporation • KEMET Tower • One East Broward Boulevard
Fort Lauderdale, FL 33301 USA • 954-766-2800 • www.kemet.com
T2076_T52X-530 • 4/16/2019
2
KEMET Organic Capacitor (KO-CAP
®
)
T52x/T530 Polymer Electrolytic Capacitors
Ordering Information
T
Capacitor
Class
520
Series
V
157
M
006
Rated
Voltage
(VDC)
A
Failure
Rate/
Design
T
Termination Finish
E045
ESR Code
Packaging
(C-Spec)
Case Capacitance Code Capacitance
Size
1
(pF)
Tolerance
T=
Tantalum
520 = Polymer
521 = High
voltage
523 = Facedown
terminal
525 = 125°C
rated
527 = Facedown
terminal
529 = Substrate
terminal
530 = 125°C High
capacitance
A
B
C
D
H
I
J
L
M
P
Q
T
U
V
W
X
Y
First two digits
represent
significant
figures. Third
digit specifies
number of
zeros.
K = ±10%
M = ±20%
002 = 2
2R5 = 2.5
003 = 3
004 = 4
006 = 6.3
008 = 8
010 = 10
011 = 11
12R = 12.5
016 = 16
020 = 20
025 = 25
035 = 35
050 = 50
063 = 63
075 = 75
A=
N/A
T = 100% Matte tin
(Sn)-plated
H*** = Tin/lead
(SnPb) solder coated
(5% Pb minimum)
P* = Ni-Pd-Au-plated
N = Non-magnetic
100% Tin (Sn)
M = Non-magnetic
(SnPb)
A** = Ni-Au
E = ESR
last three
digits
specify ESR
in mΩ
(045 = 45
mΩ)
Blank = 7" reel
7280**** = 13"
reel
Gold termination available upon request
* P termination only available on select part numbers
** A termination only available on T529 part numbers
*** H termination not available for T527/T529 part numbers
**** 13" reel not available for T520A case and some other part numbers
Performance Characteristics
Item
Operating Temperature
Rated Capacitance Range
Capacitance Tolerance
Rated Voltage Range
DF (120 Hz)
ESR (100 kHz)
Leakage Current
Performance Characteristics
−55°C to 85°C/105°C/125°C (refer to part number for maximum temperature rating)
4.7 – 1,500 µF at 120 Hz/25°C
K tolerance (10%), M tolerance (20%)
2 – 75 V
Refer to Part Number Electrical Specification Table*
Refer to Part Number Electrical Specification Table**
Refer to Part Number Electrical Specification Table
* For T529 Series DF measurement apply 1.5 V DC
** For PN T520B477M2R5ATE014 the ESR measurement should be taken at 300 to 500kHz
© KEMET Electronics Corporation • KEMET Tower • One East Broward Boulevard
Fort Lauderdale, FL 33301 USA • 954-766-2800 • www.kemet.com
T2076_T52X-530 • 4/16/2019
3
KEMET Organic Capacitor (KO-CAP
®
)
T52x/T530 Polymer Electrolytic Capacitors
Qualification
Test
Condition
Δ C/C
Temperature: 85°C, 105°C, 125°C**
Voltage: 1.0 Rated Voltage
2/3 Rated Voltage for 125°C rating PN
Time: 2,000 Hours
1,000 Hours for T527/T529***
DF
DCL
ESR
Δ C/C
Storage Life
Temperature: 105°C, 125°C**
Voltage: 0 Voltage
Time: 2,000 Hours
(N/A for T527 and T529***)
DF
DCL
ESR
Δ C/C
Temperature: 60°C
Voltage: No Load
Humidity: 90% RH
Time: 500 Hours, 1,000 Hours (T525, T530)
DF
DCL
ESR
+25°C
Extreme temperature exposure at
a succession of continuous steps
at +25°C, −55°C, +25°C, +85°C,
+105°/125°C, +25°C
Δ
C/C
DF
DCL
IL*
Characteristics
Within −20%/+10% of initial value
T527 and T529: Within initial DC/C limits
Within initial limits
T527 and T529: Within 1.5 x initial limits***
85°C and 105°C rated parts: Within 1.25 x initial limit
125°C rated parts: Within 2.0 x initial limits
T527: Within initial limits
T529: Within 3.0 x initial limits
Within 2.0 x initial limit
(N/A for T527 and T529***)
Within −20%/+10% of initial value
Within initial limits
Within 1.25 x initial limit
T521: 1.25 x IL at 105°C, 2x IL at 125°C
T525/T530: Within 2.0 x initial limit
Within 2.0 x initial limit
Within −5%/+35% of initial value
T527/T529: −20% to +30% of initial DC/C limit
T520B477M2R5ATE014: −20% to +50% of initial DC/C limit
Within initial limits
T527/T529: Within 1.5 x initial limits***
Within 5.0 x initial limit
T521/T525/T529/T530: Within 3.0 x initial limit***
T527: Within initial limits
Within 2.0 x initial limit
T525/T527/T529/T530: N/A***
−55°C
+85°C
+105º/125°C
±20%
−20% - 0%
of DC/C
(T527/29)***
IL
±20%
±30%
+50% - 0% of
DC/C (T527/29)***
1.5 x IL
IL (T529)
Endurance
Humidity
Temperature
Stability
IL
IL
Δ C/C
1.2 x IL
Surge Voltage
Temperature: 105°C, 85°C** (T527/T529)
Voltage: 1.32 x Rated voltage
Time: 1,000 cycles
MIL–STD–202, Method 213, Condition I,
100 G Peak.
MIL–STD–202, Method 204, Condition D,
10 Hz to 2,000 Hz, 20 G peak
DF
DCL
ESR
N/A
10 x IL
10 x IL
IL (T529)
1.25 CV (T529)
Within −20%/+10% of initial value
T527/T529 Series: Within initial DC/C limits
Within initial limits
Within initial limits
Within initial limits
T527/T529 Series: N/A
Within ±10% of initial value
Within initial DC/C limits
Within initial limits
Within initial limits
Mechanical
Shock/Vibration
Δ C/C
DF
DCL
*IL = Initial limit
**Refer to part number specifications for individual temperature classification.
***This condition/exclusion applies also to PN T520B477M2R5ATE014
© KEMET Electronics Corporation • KEMET Tower • One East Broward Boulevard
Fort Lauderdale, FL 33301 USA • 954-766-2800 • www.kemet.com
T2076_T52X-530 • 4/16/2019
4
KEMET Organic Capacitor (KO-CAP
®
)
T52x/T530 Polymer Electrolytic Capacitors
Reliability
KO-CAP capacitors have an average failure rate of 0.5 %/1,000 hours at category voltage, U
C
, and category temperature,
T
C
. These capacitors are qualified using industry test standards at U
C
and T
C
. The minimum test time (1,000 hours or 2,000
hours) is dependent on the product.
The actual life expectancy of KO-CAP capacitors increases when application voltage, U
A
, and application temperature, T
A
,
are lower than U
C
and T
C
. As a general guideline, when U
A
< 0.9 * U
C
and T
A
< 85°C, the life expectancy will typically exceed
the useful lifetime of most hardware (> 10 years).
The lifetime of a KO-CAP capacitor at a specific application voltage and temperature can be modeled using the equations
below. A failure is defined as passing enough current to blow a 1-amp fuse. The calculation is an estimation based on
empirical results and is not a guarantee.
VAF =
where:
( )
U
A
U
C
n
[ (
TAF = e
E
a
k
1
273+T
A
1
273+T
C
)]
VAF = acceleration factor due to voltage, unitless
U
C
= category voltage, volt
U
A
= application voltage, volt
n = exponent, 16
where:
TAF = acceleration factor due to temperature, unitless
E
a
= activation energy, 1.4 eV
k = Boltzmann’s constant, 8.617E-5 eV/K
T
A
= application temperature, °C
T
C
= category temperature, °C
AF = VAF * TAF
where:
AF = acceleration factor, unitless
TAF = accerlation factor due to temperature, unitless
VAF = acceleration factor due to voltage, unitless
where:
Life
U ,T
= Life
U ,T
* AF
A
A
C
C
Life
UA, TA
= guaranteed life application voltage
and temperature, years
Life
UC, TC
= guaranteed life category voltage
and temperature, years
AF = acceleration factor, unitless
Terms:
Category voltage, U
C
: maximum recommended peak DC operating voltage for continuous operation at the category temperature, T
C
Rated voltage, U
R
: maximum recommended peak DC operating voltage for continuous operation up to the rated temperature, T
R
Category temperature, T
C
: maximum recommended operating temperature. Voltage derating may be required at T
C
Rated temperature, T
R
: maximum recommended operating temperature without voltage derating. T
R
is equal to or lower than T
C
Reliability Table 1 – Common temperature range classifications
85°C (T
R
) /
85°C (T
C
)
105°C (T
R
) /
105°C (T
C
)
105°C (T
R
) /
125°C (T
C
)
Rated Voltage (U
R
)
Category Voltage (U
C
)
Rated Voltage (T
R
)
Category Voltage (U
C
)
Rated Voltage (T
R
)
Category Voltage (U
C
)
2.5
2.5
2.5
2.5
2.5
1.7
4.0
4.0
4.0
4.0
4.0
2.7
6.3
6.3
6.3
6.3
6.3
4.2
8.0
8.0
8.0
8.0
8.0
5.4
10.0
10.0
10.0
10.0
10.0
6.7
12.5
12.5
12.5
12.5
12.5
8.4
16.0
16.0
16.0
16.0
16.0
10.7
20.0
20.0
20.0
20.0
20.0
13.4
25.0
25.0
25.0
25.0
25.0
16.8
35.0
35.0
35.0
35.0
35.0
23.5
50.0
50.0
50.0
50.0
50.0
33.5
63.0
63.0
63.0
63.0
63.0
42.2
75.0
75.0
75.0
75.0
75.0
50.3
© KEMET Electronics Corporation • KEMET Tower • One East Broward Boulevard
Fort Lauderdale, FL 33301 USA • 954-766-2800 • www.kemet.com
T2076_T52X-530 • 4/16/2019
5
京公网安备 11010802033920号
EEWORLD
