• Enables system boot up via the LAN (32-bit and 64-bit)
• Flash interface for PXE image
• Easy system monitoring with industry-standard consoles
• Gives an indication to the manageability firmware or external devices that the chip or
the driver is not functioning
Specifications
General
Connectors
• One or two LC fiber-optic connectors
• SFP+ Direct Attach cables
Network Standards
IEEE 802.3
SFF-8431
• Optical: 1 GbE/10 Gb
• Direct Attach: 10 GbE
PCI Express 2.0 (5.0 GT/s)
4-lane PCI Express and 8-lane PCI Express
INTA, MSI, MSI-X
FCC B, UL, CE, VCCI, BSMI, CTICK, KCC
Intel® 82599 10 Gigabit Ethernet Controller
Single-port
Maximum: 8.71W* Typical: 3.9W**
Maximum: 8.71W* Typical: 3.9W**
Maximum: 5.18W* Typical: 4.1W**
Dual Port
10GBASE-SR
10GBASE-LR
Direct Attached
Maximum: 14.4W* Typical: 4.8W**
Maximum: 14.4W* Typical: 4.8W**
Maximum: 7.4W* Typical: 4.1 W**
(NOTE: Intel® Ethernet SFP+ Optics are required if optics will be used)
Technical Features
Data rate supported per port
Bus type
Bus width
Interrupt levels
Hardware certifications
Controller-processor
Power Consumption
10GBASE-SR/1000BASE-SX
10GBASE-LR/1000BASE-LX
Direct Attached Twinax
Operating temperature
Air Flow
Storage temperature
Storage humidity
LED Indicators
Physical Dimensions
0 °C to 55 °C (32 °F to 131 °F)
Minimum of 100 LFM required
-40 °C to 70 °C (-40 °F to 158 °F)
Maximum: 90% non-condensing relative humidity at 35 °C
LINK (solid) and ACTIVITY (blinking)
LINK SPEED (green=10 Gbps; yellow=1 Gbps)
Standard OCP Form Factor
IA-32
N/A
N/A
N/A
Y
Y
Y
Y
Y
Y
N/S
x86-64
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Network Operating System (NOS) Support
Operating System
Windows Server 2008 R2 SP1
Windows Server 2012
Windows Server 2012 R2
Linux* Stable Kernel version 2.6/3.x
Linux RHEL 5.9
Linux RHEL 6.4
Linux SLES 10 SP4
Linux SLES 11 SP2
Free BSD 9
UEFI 2.1/2.3
*Calculated max assumes that either SR or LR optics consume 3.15W.
**Average
of measurement data taken at nominal voltage and 25 °C temperature
Intel® Ethernet Server Adapter
X520 Series for OCP Product Codes
Configuration
Single Port
Dual Port
Product Code
X520DA1OCP
2
X520DA1OCPG2P20
3
X520DA2OCP
2
X520DA2OCPG2P20
3
Intel® Ethernet SFP+
Twinaxial Cable Product Codes
Cable Length (m)
1
3
5
Product Code
XDACBL1M
XDACBL3M
XDACBL5M
Intel® Ethernet SFP+
Optic Product Codes
Configuration
SR Optic
LR Optic
Product Code
E10GSFPSR
E10GSFPLR
For product information
To speak to a customer service represen-
tative, please call 1-800-538-3373 (U.S.
and Canada) or visit support.intel.com/
support/go/network/ contact.htm for
the telephone number in your area. For
additional product information on Intel
Networking Connectivity products, visit
www.intel.com/go/ethernet.
Customer Support
Intel® Customer Support Services offers
a broad selection of programs including
phone support and warranty service. For
more information, contact us at support.
intel.com/support/go/network/ adapter/
home.htm.
(Service and availability may vary by
country.)
For more information on the Intel® Ethernet CNA X520-DA1OCP, visit
www.intel.com/go/ethernet
Requires a system supporting VMDq.
SMBus enabled.
3
NC-SI enabled.
1
2
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS
IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER AND INTEL DISCLAIMS ANY
EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABIL-
ITY, OR INFRINGE- MENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.
A “Mission Critical Application” is any application in which failure of the Intel Product could result, directly or indirectly, in personal injury or death. SHOULD YOU PURCHASE OR USE INTEL’S PRODUCTS
FOR ANY SUCH MIS- SION CRITICAL APPLICATION, YOU SHALL INDEMNIFY AND HOLD INTEL AND ITS SUBSIDIARIES, SUBCONTRACTORS AND AFFILIATES, AND THE DIRECTORS, OFFICERS, AND EMPLOY-
EES OF EACH, HARMLESS AGAINST ALL CLAIMS COSTS, DAMAGES, AND EXPENSES AND REASONABLE ATTORNEYS’ FEES ARISING OUT OF, DIRECTLY OR INDIRECTLY, ANY CLAIM OF PRODUCT LIABILITY,
PERSONAL INJURY, OR DEATH ARISING IN ANY WAY OUT OF SUCH MISSION CRITICAL APPLICATION, WHETHER OR NOT INTEL OR ITS SUBCONTRACTOR WAS NEGLIGENT IN THE DESIGN, MANUFACTURE,
OR WARNING OF THE INTEL PROD- UCT OR ANY OF ITS PARTS.
Intel may make changes to specifications and product descriptions at any time, without notice. Designers must not rely on the absence or characteristics of any features or instructions marked “re-
served” or “undefined”. Intel reserves these for future definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from future changes to them. The information here
is subject to change without notice. Do not finalize a design with this information.
The products described in this document may contain design defects or errors known as errata which may cause the product to deviate from published specifications. Current characterized errata are
available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.
Copies of documents which have an order number and are referenced in this document, or other Intel literature, may be obtained by calling 1-800-548-4725, or go to: http://www.intel.com/design/
literature.htm.
*Intel, the Intel logo, and Xeon are trademarks of Intel Corporation in the U.S. and other countries. Other names and brands may be claimed as the property of others.
