GS8662TT19BGD-350 datasheet, PDF

Datasheet> All Categories > storage> storage> GS8662TT19BGD-350

GS8662TT19BGD-350: DescriptionStatic random access memory 1.8 or 1.5V 4M x 18 72M; Categorystorage storage; File Size327KB，29 Pages; ManufacturerGSI Technology; Websitehttp://www.gsitechnology.com/; Environmental Compliance

Download Datasheet Parametric View All

GS8662TT19BGD-350 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	GS8662TT19BGD-350	-	-	View	Buy Now

GS8662TT19BGD-350 Overview

Static random access memory 1.8 or 1.5V 4M x 18 72M

GS8662TT19BGD-350 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	GSI Technology
Parts packaging code	BGA
package instruction	LBGA, BGA165,11X15,40
Contacts	165
Reach Compliance Code	compliant
ECCN code	3A991.B.2.B
Factory Lead Time	8 weeks
Maximum access time	0.45 ns
Other features	PIPELINED ARCHITECTURE, LATE WRITE
Maximum clock frequency (fCLK)	350 MHz
I/O type	COMMON
JESD-30 code	R-PBGA-B165
JESD-609 code	e1
length	15 mm
memory density	75497472 bit
Memory IC Type	DDR SRAM
memory width	18
Humidity sensitivity level	3
Number of functions	1
Number of terminals	165
word count	4194304 words
character code	4000000
Operating mode	SYNCHRONOUS
Maximum operating temperature	70 °C
Minimum operating temperature
organize	4MX18
Output characteristics	3-STATE
Package body material	PLASTIC/EPOXY
encapsulated code	LBGA
Encapsulate equivalent code	BGA165,11X15,40
Package shape	RECTANGULAR
Package form	GRID ARRAY, LOW PROFILE
Parallel/Serial	PARALLEL
Peak Reflow Temperature (Celsius)	260
power supply	1.5/1.8,1.8 V
Certification status	Not Qualified
Maximum seat height	1.4 mm
Maximum standby current	0.24 A
Minimum standby current	1.7 V
Maximum slew rate	0.59 mA
Maximum supply voltage (Vsup)	1.9 V
Minimum supply voltage (Vsup)	1.7 V
Nominal supply voltage (Vsup)	1.8 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	Tin/Silver/Copper (Sn/Ag/Cu)
Terminal form	BALL
Terminal pitch	1 mm
Terminal location	BOTTOM
Maximum time at peak reflow temperature	NOT SPECIFIED
width	13 mm

Preview

Download Datasheet

View All

GS8662TT07/10/19/37BD-450/400/350/333/300

165-Bump BGA

Commercial Temp

Industrial Temp

Features

• 2.0 Clock Latency

• Simultaneous Read and Write SigmaDDR™ Interface

• Common I/O bus

• JEDEC-standard pinout and package

• Double Data Rate interface

• Byte Write controls sampled at data-in time

• Burst of 2 Read and Write

• Dual-Range On-Die Termination (ODT) on Data (D), Byte

Write (BW), and Clock (K, K) inputs

• 1.8 V +100/–100 mV core power supply

• 1.5 V or 1.8 V HSTL Interface

• Pipelined read operation with self-timed Late Write

• Fully coherent read and write pipelines

• ZQ pin for programmable output drive strength

• Data Valid pin (QVLD) Support

• IEEE 1149.1 JTAG-compliant Boundary Scan

• 165-bump, 13 mm x 15 mm, 1 mm bump pitch BGA package

• RoHS-compliant 165-bump BGA package available

72Mb SigmaDDR-II+

Burst of 2 SRAM

450 MHz–300 MHz

1.8 V V

1.8 V or 1.5 V I/O

SRAMs. The GS8662TT07/10/19/37BD SigmaDDR-II+

SRAMs are just one element in a family of low power, low

voltage HSTL I/O SRAMs designed to operate at the speeds

needed to implement economical high performance

networking systems.

Clocking and Addressing Schemes

The GS8662TT07/10/19/37BD SigmaDDR-II+ SRAMs are

synchronous devices. They employ two input register clock

inputs, K and K. K and K are independent single-ended clock

inputs, not differential inputs to a single differential clock input

buffer.

Each internal read and write operation in a SigmaDDR-II+ B2

RAM is two times wider than the device I/O bus. An input data

bus de-multiplexer is used to accumulate incoming data before

it is simultaneously written to the memory array. An output

data multiplexer is used to capture the data produced from a

single memory array read and then route it to the appropriate

output drivers as needed. Therefore, the address field of a

SigmaDDR-II+ B2 RAM is always one address pin less than

the advertised index depth (e.g., the 8M x 8 has an 4M

addressable index).

SigmaDDR™ Family Overview

The GS8662TT07/10/19/37BD are built in compliance with

the SigmaDDR-II+ SRAM pinout standard for Common I/O

synchronous SRAMs. They are 75,497,472-bit (72Mb)

Parameter Synopsis

-450

tKHKH

tKHQV

2.22 ns

0.45 ns

-400

2.5 ns

0.45 ns

-350

2.86 ns

0.45 ns

-333

3.0 ns

0.45 ns

-300

3.3 ns

0.45 ns

Rev: 1.00b 8/2017

1/29

Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.
