GS82582S18/36GE-400/375/333/300/250
165-Bump BGA
Commercial Temp
Industrial Temp
Features
• Simultaneous Read and Write SigmaSIO™ Interface
• JEDEC-standard pinout and package
• Dual Double Data Rate interface
• Byte Write controls sampled at data-in time
• DLL circuitry for wide output data valid window and future
frequency scaling
• Burst of 2 Read and Write
• 1.8 V +100/–100 mV core power supply
• 1.5 V or 1.8 V HSTL Interface
• Pipelined read operation
• Fully coherent read and write pipelines
• ZQ mode pin for programmable output drive strength
• IEEE 1149.1 JTAG-compliant Boundary Scan
• RoHS-compliant 165-bump BGA package
288Mb SigmaSIO
TM
DDR-II
Burst of 2 SRAM
Clocking and Addressing Schemes
400 MHz–250 MHz
1.8 V V
DD
1.8 V and 1.5 V I/O
A Burst of 2SigmaSIO DDR-II SRAM is a synchronous
device. It employs dual input register clock inputs, K and K.
The device also allows the user to manipulate the output
register clock input quasi independently with dual output
register clock inputs, C and C. If the C clocks are tied high, the
K clocks are routed internally to fire the output registers
instead. Each Burst of 2SigmaSIO DDR-II SRAM also
supplies Echo Clock outputs, CQ and CQ, which are
synchronized with read data output. When used in a source
synchronous clocking scheme, the Echo Clock outputs can be
used to fire input registers at the data’s destination.
Each internal read and write operation in a SigmaSIO DDR-II
B2 RAM is two times wider than the device I/O bus. An input
data bus de-multiplexer is used to accumulate incoming data
before it is simultaneously written to the memory array. An
output data multiplexer is used to capture the data produced
from a single memory array read and then route it to the
appropriate output drivers as needed. Therefore, the address
field of a SigmaSIO DDR-II B2 is always one address pin less
than the advertised index depth (e.g., the 16M x 18 has an 8M
addressable index).
SigmaSIO™ Family Overview
GS82582S18/36GE are built in compliance with the SigmaSIO
DDR-II SRAM pinout standard for Separate I/O synchronous
SRAMs. They are 301,989,888-bit (288Mb) SRAMs. These
are the first in a family of wide, very low voltage HSTL I/O
SRAMs designed to operate at the speeds needed to implement
economical high performance networking systems.
Parameter Synopsis
-400
tKHKH
tKHQV
2.5 ns
0.45 ns
-375
2.66 ns
0.45 ns
-333
3.0 ns
0.45 ns
-300
3.3 ns
0.45 ns
-250
4.0 ns
0.45 ns
Rev: 1.04a 8/2017
1/32
© 2012, GSI Technology
Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.
GS82582S18/36GE-400/375/333/300/250
16M x 18 SigmaQuad SRAM—Top View
1
A
B
C
D
E
F
G
H
J
K
L
M
N
P
R
CQ
NC
NC
NC
NC
NC
NC
D
OFF
NC
NC
NC
NC
NC
NC
TDO
2
SA
Q9
NC
D11
NC
Q12
D13
V
REF
NC
NC
Q15
NC
D17
NC
TCK
3
SA
D9
D10
Q10
Q11
D12
Q13
V
DDQ
D14
Q14
D15
D16
Q16
Q17
SA
4
R/W
SA
V
SS
V
SS
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
SS
V
SS
SA
SA
5
BW1
NC
SA
V
SS
V
SS
V
DD
V
DD
V
DD
V
DD
V
DD
V
SS
V
SS
SA
SA
SA
6
K
K
SA
V
SS
V
SS
V
SS
V
SS
V
SS
V
SS
V
SS
V
SS
V
SS
SA
C
C
7
SA
BW0
SA
V
SS
V
SS
V
DD
V
DD
V
DD
V
DD
V
DD
V
SS
V
SS
SA
SA
SA
8
LD
SA
V
SS
V
SS
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
SS
V
SS
SA
SA
9
SA
NC
NC
NC
NC
NC
NC
V
DDQ
NC
NC
NC
NC
NC
NC
SA
10
SA
NC
Q7
NC
D6
NC
NC
V
REF
Q4
D3
NC
Q1
NC
D0
TMS
11
CQ
Q8
D8
D7
Q6
Q5
D5
ZQ
D4
Q3
Q2
D2
D1
Q0
TDI
11 x 15 Bump BGA—15 x 17 mm
2
Body—1 mm Bump Pitch
Notes:
1. BW0 controls writes to D0:D8. BW1 controls writes to D9:D17.
2. A7 is the expansion address.
Rev: 1.04a 8/2017
2/32
© 2012, GSI Technology
Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.
GS82582S18/36GE-400/375/333/300/250
8M x 36 SigmaQuad SRAM—Top View
1
A
B
C
D
E
F
G
H
J
K
L
M
N
P
R
CQ
Q27
D27
D28
Q29
Q30
D30
D
OFF
D31
Q32
Q33
D33
D34
Q35
TDO
2
SA
Q18
Q28
D20
D29
Q21
D22
V
REF
Q31
D32
Q24
Q34
D26
D35
TCK
3
SA
D18
D19
Q19
Q20
D21
Q22
V
DDQ
D23
Q23
D24
D25
Q25
Q26
SA
4
R/W
SA
V
SS
V
SS
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
SS
V
SS
SA
SA
5
BW2
BW3
SA
V
SS
V
SS
V
DD
V
DD
V
DD
V
DD
V
DD
V
SS
V
SS
SA
SA
SA
6
K
K
SA
V
SS
V
SS
V
SS
V
SS
V
SS
V
SS
V
SS
V
SS
V
SS
SA
C
C
7
BW1
BW0
SA
V
SS
V
SS
V
DD
V
DD
V
DD
V
DD
V
DD
V
SS
V
SS
SA
SA
SA
8
LD
SA
V
SS
V
SS
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
SS
V
SS
SA
SA
9
SA
D17
D16
Q16
Q15
D14
Q13
V
DDQ
D12
Q12
D11
D10
Q10
Q9
SA
10
SA
Q17
Q7
D15
D6
Q14
D13
V
REF
Q4
D3
Q11
Q1
D9
D0
TMS
11
CQ
Q8
D8
D7
Q6
Q5
D5
ZQ
D4
Q3
Q2
D2
D1
Q0
TDI
11 x 15 Bump BGA—15 x 17 mm
2
Body—1 mm Bump Pitch
Notes:
1. BW0 controls writes to D0:D8. BW1 controls writes to D9:D17.
2. BW2 controls writes to D18:D26. BW3 controls writes to D27:D35.
3. A2 is the expansion address.
Rev: 1.04a 8/2017
3/32
© 2012, GSI Technology
Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.
GS82582S18/36GE-400/375/333/300/250
Pin Description Table
Symbol
SA
R/W
BW0–BW1
BW0–BW3
K
C
TMS
TDI
TCK
TDO
V
REF
ZQ
K
C
D
OFF
LD
CQ
CQ
Dn
Qn
V
DD
V
DDQ
V
SS
NC
Description
Synchronous Address Inputs
Read/Write Contol Pin
Synchronous Byte Writes
Synchronous Byte Writes
Input Clock
Output Clock
Test Mode Select
Test Data Input
Test Clock Input
Test Data Output
HSTL Input Reference Voltage
Output Impedance Matching Input
Input Clock
Output Clock
DLL Disable
Synchronous Load Pin
Output Echo Clock
Output Echo Clock
Synchronous Data Inputs
Synchronous Data Outputs
Power Supply
Isolated Output Buffer Supply
Power Supply: Ground
No Connect
Type
Input
Input
Input
Input
Input
Input
Input
Input
Input
Output
Input
Input
Input
Output
—
—
Output
Output
Input
Output
Supply
Supply
Supply
—
Comments
—
Write Active Low; Read Active High
Active Low
x18 Version
Active Low
x36 Version
Active High
Active High
—
—
—
—
—
—
Active Low
Active Low
Active Low
Active Low
Active Low
Active High
—
—
1.8 V Nominal
1.8 or 1.5 V Nominal
—
—
Notes:
1. C, C, K, or K cannot be set to V
REF
voltage.
2. When ZQ pin is directly connected to V
DDQ
, output impedance is set to minimum value and it cannot be connected to ground or left
unconnected.
3. NC = Not Connected to die or any other pin
Rev: 1.04a 8/2017
4/32
© 2012, GSI Technology
Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.
GS82582S18/36GE-400/375/333/300/250
Background
Separate I/O SRAMs, like SigmaQuad SRAMs, are attractive in applications where alternating reads and writes are needed. On the
other hand, Common I/O SRAMs like the SigmaCIO family are popular in applications where bursts of read or write traffic are
needed. The SigmaSIO SRAM is a hybrid of these two devices. Like the SigmaQuad family devices, the SigmaSIO features a
separate I/O data path, offering the user independent Data In and Data Out pins. However, the SigmaSIO devices offer a control
protocol like that offered on the SigmaCIO devices. Therefore, while SigmaQuad SRAMs allow a user to operate both data ports at
the same time, they force alternating loads of read and write addresses. SigmaSIO SRAMs allow continuous loads of read or write
addresses like SigmaCIO SRAMs, but in a separate I/O configuration.
Like a SigmaQuad SRAM, a SigmaSIO DDR-II SRAM can execute an alternating sequence of reads and writes. However, doing
so results in the Data In port and the Data Out port stalling with nothing to do on alternate transfers. A SigmaQuad device would
keep both ports running at capacity full time. On the other hand, the SigmaSIO device can accept a continuous stream of read
commands and read data or a continuous stream of write commands and write data. The SigmaQuad device, by contrast, restricts
the user from loading a continuous stream of read or write addresses. The advantage of the SigmaSIO device is that it allows twice
the random address bandwidth for either reads or writes than could be acheived with a SigmaQuad version of the device.
SigmaDDR (CIO) SRAMs offer this same advantage, but do not have the separate Data In and Data Out pins offered on the
SigmaSIO SRAMs. Therefore, SigmaSIO devices are useful in psuedo dual port SRAM applications where communication of
burst traffic between two electrically independent busses is desired.
Each of the three SigmaQuad Family SRAMs—SigmaQuad, SigmaDDR, and SigmaSIO—supports similar address rates because
random address rate is determined by the internal performance of the RAM. In addition, all three SigmaQuad Family SRAMs are
based on the same internal circuits. Differences between the truth tables of the different devices proceed from differences in how
the RAM’s interface is contrived to interact with the rest of the system. Each mode of operation has its own advantages and
disadvantages. The user should consider the nature of the work to be done by the RAM to evaluate which version is best suited to
the application at hand.
Burst of 2 SigmaSIO DDR-II SRAM DDR Read
The status of the Address Input, R/W, and LD pins are sampled at each rising edge of K. LD high causes chip disable. A high on
the R/W pin begins a read cycle. The two resulting data output transfers begin after the next rising edge of the K clock. Data is
clocked out by the next rising edge of the C if it is active. Otherwise, data is clocked out at the next rising edge of K. The next data
chunk is clocked out on the rising edge of C, if active. Otherwise, data is clocked out on the rising edge of K.
Burst of 2 SigmaSIO DDR-II SRAM DDR Write
The status of the Address Input, R/W, and LD pins are sampled at each rising edge of K. LD high causes chip disable. A low on the
R/W pin, begins a write cycle. Data is clocked in by the next rising edge of K and then the rising edge of K.
Rev: 1.04a 8/2017
5/32
© 2012, GSI Technology
Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.
