GS8182D19/37BD-435/400/375/333/300
165-Bump BGA
Commercial Temp
Industrial Temp
Features
• 2.0 Clock Latency
• Simultaneous Read and Write SigmaQuad™ Interface
• JEDEC-standard pinout and package
• Dual Double Data Rate interface
• Byte Write controls sampled at data-in time
• Burst of 4 Read and Write
• 1.8 V +100/–100 mV core power supply
• 1.5 V or 1.8 V HSTL Interface
• Pipelined read operation
• Fully coherent read and write pipelines
• ZQ pin for programmable output drive strength
• Data Valid Pin (QVLD)
• IEEE 1149.1 JTAG-compliant Boundary Scan
• 165-bump, 13 mm x 15 mm, 1 mm bump pitch BGA package
• RoHS-compliant 165-bump BGA package available
18Mb SigmaQuad-II+
Burst of 4 SRAM
435 MHz–300 MHz
1.8 V V
DD
1.8 V and 1.5 V I/O
one element in a family of low power, low voltage HSTL I/O
SRAMs designed to operate at the speeds needed to implement
economical high performance networking systems.
Clocking and Addressing Schemes
The GS8182D19/37D SigmaQuad-II+ SRAMs are
synchronous devices. They employ two input register clock
inputs, K and K. K and K are independent single-ended clock
inputs, not differential inputs to a single differential clock input
buffer.
Each internal read and write operation in a SigmaQuad-II B4
RAM is four times wider than the device I/O bus. An input
data bus de-multiplexer is used to accumulate incoming data
before it is simultaneously written to the memory array. An
output data multiplexer is used to capture the data produced
from a single memory array read and then route it to the
appropriate output drivers as needed. Therefore the address
field of a SigmaQuad-II B4 RAM is always two address pins
less than the advertised index depth (e.g., the 2M x 8 has a
512K addressable index).
SigmaQuad™ Family Overview
The GS8182D19/37D are built in compliance with the
SigmaQuad-II+ SRAM pinout standard for Separate I/O
synchronous SRAMs. They are 18,874,368-bit (18Mb)
SRAMs. The GS8182D19/37D SigmaQuad SRAMs are just
Parameter Synopsis
-435
tKHKH
tKHQV
2.3 ns
0.45 ns
-400
2.5 ns
0.45 ns
-375
2.67 ns
0.45 ns
-333
3.3 ns
0.45 ns
-300
3.0 ns
0.45 ns
Rev: 1.03a 11/2011
1/27
© 2008, GSI Technology
Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.
GS8182D19/37BD-435/400/375/333/300
512K x 36 SigmaQuad-II+ SRAM—Top View
1
A
B
C
D
E
F
G
H
J
K
L
M
N
P
R
CQ
Q27
D27
D28
Q29
Q30
D30
Doff
D31
Q32
Q33
D33
D34
Q35
TDO
2
NC/SA
(288Mb)
Q18
Q28
D20
D29
Q21
D22
V
REF
Q31
D32
Q24
Q34
D26
D35
TCK
3
NC/SA
(72 Mb)
D18
D19
Q19
Q20
D21
Q22
V
DDQ
D23
Q23
D24
D25
Q25
Q26
SA
4
W
SA
V
SS
V
SS
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
SS
V
SS
SA
SA
5
BW2
BW3
SA
V
SS
V
SS
V
DD
V
DD
V
DD
V
DD
V
DD
V
SS
V
SS
SA
SA
SA
6
K
K
NC
V
SS
V
SS
V
SS
V
SS
V
SS
V
SS
V
SS
V
SS
V
SS
SA
QVLD
NC
7
BW1
BW0
SA
V
SS
V
SS
V
DD
V
DD
V
DD
V
DD
V
DD
V
SS
V
SS
SA
SA
SA
8
R
SA
V
SS
V
SS
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
SS
V
SS
SA
SA
9
NC/SA
(36Mb)
D17
D16
Q16
Q15
D14
Q13
V
DDQ
D12
Q12
D11
D10
Q10
Q9
SA
10
NC/SA
(144Mb)
Q17
Q7
D15
D6
Q14
D13
V
REF
Q4
D3
Q11
Q1
D9
D0
TMS
11
CQ
Q8
D8
D7
Q6
Q5
D5
ZQ
D4
Q3
Q2
D2
D1
Q0
TDI
11 x 15 Bump BGA—13 x 15 mm
2
Body—1 mm Bump Pitch
Notes:
1. BW0 controls writes to D0:D8; BW1 controls writes to D9:D17; BW2 controls writes to D18:D26; BW3 controls writes to D27:D35
2. NC = Not connected
Rev: 1.03a 11/2011
2/27
© 2008, GSI Technology
Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.
GS8182D19/37BD-435/400/375/333/300
1M x 18 SigmaQuad-II+ SRAM—Top View
1
A
B
C
D
E
F
G
H
J
K
L
M
N
P
R
CQ
NC
NC
NC
NC
NC
NC
Doff
NC
NC
NC
NC
NC
NC
TDO
2
NC/SA
(144 Mb)
Q9
NC
D11
NC
Q12
D13
V
REF
NC
NC
Q15
NC
D17
NC
TCK
3
NC/SA
(36 Mb)
D9
D10
Q10
Q11
D12
Q13
V
DDQ
D14
Q14
D15
D16
Q16
Q17
SA
4
W
SA
V
SS
V
SS
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
SS
V
SS
SA
SA
5
BW1
NC
SA
V
SS
V
SS
V
DD
V
DD
V
DD
V
DD
V
DD
V
SS
V
SS
SA
SA
SA
6
K
K
NC
V
SS
V
SS
V
SS
V
SS
V
SS
V
SS
V
SS
V
SS
V
SS
SA
QVLD
NC
7
NC/SA
(288Mb)
BW0
SA
V
SS
V
SS
V
DD
V
DD
V
DD
V
DD
V
DD
V
SS
V
SS
SA
SA
SA
8
R
SA
V
SS
V
SS
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
DDQ
V
SS
V
SS
SA
SA
9
SA
NC
NC
NC
NC
NC
NC
V
DDQ
NC
NC
NC
NC
NC
NC
SA
10
NC/SA
(72 Mb)
NC
Q7
NC
D6
NC
NC
V
REF
Q4
D3
NC
Q1
NC
D0
TMS
11
CQ
Q8
D8
D7
Q6
Q5
D5
ZQ
D4
Q3
Q2
D2
D1
Q0
TDI
11 x 15 Bump BGA—13 x 15 mm
2
Body—1 mm Bump Pitch
Notes:
1. BW0 controls writes to D0:D8. BW1 controls writes to D9:D17.
2. NC = Not connected
Rev: 1.03a 11/2011
3/27
© 2008, GSI Technology
Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.
GS8182D19/37BD-435/400/375/333/300
Pin Description Table
Symbol
SA
R
W
BW0–BW3
K
K
TMS
TDI
TCK
TDO
V
REF
ZQ
Qn
Dn
Description
Synchronous Address Inputs
Synchronous Read
Synchronous Write
Synchronous Byte Writes
Input Clock
Input Clock
Test Mode Select
Test Data Input
Test Clock Input
Test Data Output
HSTL Input Reference Voltage
Output Impedance Matching Input
Synchronous Data Outputs
Synchronous Data Inputs
Disable DLL when low
Output Echo Clock
Output Echo Clock
Power Supply
Isolated Output Buffer Supply
Power Supply: Ground
Q Valid Output
No Connect
Type
Input
Input
Input
Input
Input
Input
Input
Input
Input
Output
Input
Input
Output
Input
Input
Output
Output
Supply
Supply
Supply
Output
—
Comments
—
Active Low
Active Low
Active Low
x18/x36 only
Active High
Active Low
—
—
—
—
—
—
D
off
CQ
CQ
V
DD
V
DDQ
V
SS
QVLD
NC
Active Low
—
—
1.8 V Nominal
1.5 or 1.8 V Nominal
—
—
—
Notes:
1. NC = Not Connected to die or any other pin
2. When ZQ pin is directly connected to V
DDQ
, output impedance is set to minimum value and it cannot be connected to ground or left
unconnected.
3. K, K cannot be set to V
REF
voltage
Rev: 1.03a 11/2011
4/27
© 2008, GSI Technology
Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.
GS8182D19/37BD-435/400/375/333/300
Background
Separate I/O SRAMs, from a system architecture point of view, are attractive in applications where alternating reads and writes are
needed. Therefore, the SigmaQuad-II+ SRAM interface and truth table are optimized for alternating reads and writes. Separate I/O
SRAMs are unpopular in applications where multiple reads or multiple writes are needed because burst read or write transfers from
Separate I/O SRAMs can cut the RAM’s bandwidth in half.
SigmaQuad-II+ B4 SRAM DDR Read
The status of the Address Input, W, and R pins are sampled by the rising edges of K. W and R high causes chip disable. A low on
the Read Enable-bar pin, R, begins a read cycle. R is always ignored if the previous command loaded was a read command. .
Clocking in a high on the Read Enable-bar pin, R, begins a read port deselect cycle.
SigmaQuad-II+ B4 SRAM DDR Write
The status of the Address Input, W, and R pins are sampled by the rising edges of K. W and R high causes chip disable. A low on
the Write Enable-bar pin, W, and a high on the Read Enable-bar pin, R, begins a write cycle. W is always ignored if the previous
command was a write command. Data is clocked in by the next rising edge of K, the rising edge of K after that, the next rising edge
of K, and finally by the next rising edge of K. and by the rising edge of the K that follows.
Rev: 1.03a 11/2011
5/27
© 2008, GSI Technology
Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.
