SMBJ3V3
www.vishay.com
Vishay General Semiconductor
Surface Mount T
RANS
Z
ORB®
Transient Voltage Suppressors
FEATURES
• Uni-directional polarity only
• Peak pulse power: 600 W (10/1000 μs)
• Excellent clamping capability
• Very fast response time
• Meets MSL level 1, per J-STD-020, LF
maximum peak of 260 °C
• AEC-Q101 qualified
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
TYPICAL APPLICATIONS
SMB (DO-214AA)
Use in sensitive electronics protection against voltage
transients induced by inductive load switching and lighting
on ICs, MOSFET, signal lines of sensor units specifically for
protecting 3.3 V supplied sensitive equipment against
transient overvoltages.
4.1 V
3.3 V
600 W
5W
60 A
175 °C
Uni-directional
SMB (DO-214AA)
PRIMARY CHARACTERISTICS
V
BR
(uni-directional)
V
WM
P
PPM
P
D
I
FSM
(uni-directional only)
T
J
max.
Polarity
Package
MECHANICAL DATA
Case:
SMB (DO-214AA)
Molding compound meets UL 94 V-0 flammability rating
Base P/N-E3 - RoHS-compliant and commercial grade
Base P/NHE3 - RoHS-compliant and AEC-Q101 qualified
Terminals:
matte tin plated leads, solderable per
J-STD-002 and JESD 22-B102
E3 suffix meets JESD 201 class 2 whisker test, HE3 suffix
meets JESD 201 class 2 whisker test
Polarity:
color band denotes cathode end
MAXIMUM RATINGS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Peak pulse power dissipation
(1)(2)
Peak pulse current with a 10/1000 μs waveform (fig. 1)
Peak pulse current with a 8/20 μs waveform (fig. 1)
Peak forward surge current 8.3 ms single half sine-wave
(2)
Power dissipation on infinite heatsink, T
A
= 75 °C
Operating junction and storage temperature range
Notes
(1)
Non-repetitive current pulse, per fig. 1
(2)
Mounted on 0.2" x 0.2" (5.0 mm x 5.0 mm) copper pads to each terminal
SYMBOL
P
PPM
I
PP
I
PPM
I
FSM
P
D
T
J
, T
STG
VALUE
600
50
200
60
5
-65 to +175
UNIT
W
A
A
A
W
°C
ELECTRICAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
DEVICE
TYPE
DEVICE
MARKING
CODE
BREAKDOWN
VOLTAGE
V
BR
AT I
T
MIN.
V
SMBJ3V3
KC
4.1
mA
1.0
MAXIMUM
REVERSE
LEAKAGE
CURRENT
I
R
AT V
WM
μA
200
TYPICAL
MAXIMUM MAXIMUM
TYPICAL
JUNCTION
STAND-OFF CLAMPING CLAMPING
TEMPERATURE
CAPACITANCE
VOLTAGE VOLTAGE
VOLTAGE
COEFFICIENT
C
J
AT 0 V
V
C
AT I
PP
V
C
AT I
PPM
V
WM
OF V
BR
1 MHz
10/1000 μs
8/20 μs
V
3.3
V
7.3
A
50
V
10.3
A
200
10
-4
/°C
-5.3
pF
5200
Revision: 16-Jan-18
Document Number: 88940
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
SMBJ3V3
www.vishay.com
Vishay General Semiconductor
THERMAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Typical thermal resistance, junction to lead
(1)
Typical thermal resistance, junction to ambient
(2)
SYMBOL
R
JL
R
JA
VALUE
20
100
UNIT
°C/ W
Notes
(1)
Thermal resistance from junction to lead - mounted on 0.2" x 0.2" (5.0 mm x 5.0 mm) copper pads to each terminal
(2)
Thermal resistance from junction to ambient - mounted on the recommended PCB pad layout
ORDERING INFORMATION
(Example)
PREFERRED P/N
SMBJ3V3-E3/52
SMBJ3V3-E3/5B
SMBJ3V3HE3/52
(1)
UNIT WEIGHT (g)
0.096
0.096
0.096
0.096
PREFERRED PACKAGE CODE
52
5B
52
5B
BASE QUANTITY
750
3200
750
3200
DELIVERY MODE
7" diameter plastic tape and reel
13" diameter plastic tape and reel
7" diameter plastic tape and reel
13" diameter plastic tape and reel
SMBJ3V3HE3/5B
(1)
Note
(1)
AEC-Q101 qualified
RATINGS AND CHARACTERISTICS CURVES
(T
A
= 25 °C unless otherwise noted)
150
10
I
PPM
- Peak Pulse Current, % I
RSM
t
r
= 10
µs
t
r
= 8
µs
Peak
Value
I
PPM
100
Half
Value
- I
PP
I
PPM
2
50
t
d
= 1000 µs
t
d
= 20 µs
I
R
(T
J
)/I
R
(T
J
= 25 °C)
T
J
= 25 °C
Pulse Width (t
d
)
is defined as the Point
where
the Peak Current
decays to 50 % of I
PPM
1
t
d
0
0
1.0
2.0
3.0
4.0
0.1
0
25
50
75
100
125
150
175
t - Time (ms)
T
J
- Junction T emperature (°C)
Fig. 1 - Pulse Wave Form
10
Fig. 3 -
Relative Variation of Leakage Current vs.
Junction Temperature
10
P
PPM
- Peak Pulse Power (kW)
Clamping
Voltage
(V)
8
1
6
10/1000 µs
8/20 µs
0.1
0.01
4
0.1
1
10
0.1
1
10
100
1000
t
d
- Pulse Width (ms)
I
PP
(A)
Fig. 2 -
Peak Pulse Power Rating Curve
Fig. 4 -
Clamping Voltage vs. Peak Pulse Current (T
J
initial = 25 °C)
Revision: 16-Jan-18
Document Number: 88940
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
SMBJ3V3
www.vishay.com
Vishay General Semiconductor
100
5500
C
J
- Junction Capacitance (pF)
I
F
- Peak Forward Current (A)
5000
4500
4000
3500
3000
2500
2000
0
0.5
1
1.5
2
2.5
3
3.5
T
J
= 175 °C
10
T
J
= 25 °C
1
0.1
0
0.2
0.4
0.6
0.8
1
1.2
1.4
1.6
1.8
Reverse
Voltage
(V)
V
F
- Forward
Voltage
Drop (V)
Fig. 5 - Typical Junction Capacitance
Fig. 7 -
Typical Peak Forward Voltage Drop vs.
Peak Forward Current
100
Transient Thermal Impedance (°C/W)
10
1
0.01
0.1
1
10
100
1000
t - Pulse Duration (s)
Fig. 6 -
Typical Transient Thermal Impedance
PACKAGE OUTLINE DIMENSIONS
in inches (millimeters)
SMB (DO-214AA)
Cathode Band
0.085 (2.159)
MAX.
Mounting Pad Layout
0.086 (2.20)
0.077 (1.95)
0.155 (3.94)
0.130 (3.30)
0.086 (2.18)
MIN.
0.180 (4.57)
0.160 (4.06)
0.012 (0.305)
0.006 (0.152)
0.096 (2.44)
0.084 (2.13)
0.060 (1.52)
MIN.
0.220 REF.
0.060 (1.52)
0.030 (0.76)
0.220 (5.59)
0.205 (5.21)
0.008 (0.2)
0 (0)
Revision: 16-Jan-18
Document Number: 88940
3
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
