TOMC
www.vishay.com
Vishay Dale Thin Film
Molded, 50 mil Pitch, Dual-In-Line Thin Film Resistor,
Surface Mount Network
FEATURES
• 0.090" (2.29 mm) maximum seated height
• Rugged, molded case construction (0.22"
wide)
• Highly stable thin film ratio stability
(R ± 0.015 % at 70 °C for 2000 h)
• Low temperature coefficient, ± 25 ppm/°C
(- 55 °C to + 125 °C)
• Wide resistance range 100
to 100 k
• Isolated/bussed circuits
• Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
Note
*
Lead (Pb)-containing terminations are not RoHS-compliant.
Exemptions may apply.
Actual Size
Vishay Dale Thin Film offers standard circuits in 16 pins in a
medium body molded surface mount package. The
networks are available over a resistance range of 100
to
100 k. The network features tight ratio tolerances and
close TCR tracking. In addition to the standards shown,
custom circuits are available upon request.
TYPICAL PERFORMANCE
ABSOLUTE
TCR
25
ABSOLUTE
TOL.
0.1
TRACKING
5
RATIO
0.025
The 03 circuit provides a
choice of 8 nominally
equal resistors with each
resistor isolated from all
others and wired directly
across.
SCHEMATIC
The 01 circuit provides 15
nominally equal resistors,
each connected between
a common lead (16) and a
discrete PC board pin.
PIN 1
PIN 1
TOMC-1601
01 circuit
TOMC-1603
03 circuit
Ref.
Ref.
STANDARD ELECTRICAL SPECIFICATIONS
TEST
Material
Pin/Lead Number
Resistance Range
TCR: Absolute
TCR: Tracking
Tolerance: Absolute
Tolerance: Ratio
Power Rating: Resistor
Power Rating: Package
Stability: Absolute
Stability: Ratio
Voltage Coefficient
Working Voltage
Operating Temperature Range
Storage Temperature Range
Noise
Thermal EMF
Shelf Life Stability: Absolute
Shelf Life Stability: Ratio
Revision: 08-Jan-13
SPECIFICATIONS
Passivated nichrome
16
100
to 100 kper resistor
± 25 ppm/°C
± 5 ppm/°C
± 0.1 % to 1 %
± 0.025 % to 0.5 %
50 mW = PIN 16 common
100 mW = isolated
750 mW
R
± 0.05 %
R
± 0.015 %
0.1 ppm/V
100 V max. not to exceed
P
x
R
- 55 °C to + 125 °C
- 55 °C to + 150 °C
< - 30 dB
0.08 μV/°C
R
± 0.01 %
R
± 0.002 %
CONDITIONS
-
-
-
- 55 °C to + 125 °C
- 55 °C to + 125 °C
+ 25 °C
+ 25 °C
Maximum at + 70 °C
Maximum at + 70 °C
2000 h at + 70 °C
2000 h at + 70 °C
-
-
-
-
-
-
1 year at + 25 °C
1 year at + 25 °C
Document Number: 60008
1
For technical questions, contact:
thinfilm@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
TOMC
www.vishay.com
Vishay Dale Thin Film
DIMENSION
A
B
C
D
E
F
G
H
J
K
L
M
N
P
Q
R
S
INCHES
0.350
0.400
0.440
0.050
0.018
0.160
0.08
0.036
0.22
0.244
0.30
0.045
0.003
0.005
0.008
0.085
0.003
MILLIMETERS
8.89
10.16
11.176
1.27
0.457
4.06
2.03
0.914
5.59
6.20
7.52
1.14
0.076
1.27
0.203
2.16
0.076
DIMENSIONS AND IMPRINTING
in inches and millimeters
A
D
E Typical
Part Number
Date
Code
Vishay
Symbol
Lead #1
Indicator
M
Centered
7°
F Maximum J
Marking
7°
Area
G
H
TOMC-XX
K
L ± 0.015
(1.27)
B
Centered Maximum,
Marking Area
C
S
7°
P
Q
R
N
7°
MECHANICAL SPECIFICATIONS
Resistive Element
Substrate Material
Body
Terminals
Lead (Pb)-free Option
Tin Lead Option
Tin Lead and Lead (Pb)-free Finish
Passivated nichrome
Silicon
DERATING CURVE
TOMC-1601,
TOMC-1603
0.48 W
Single
Resistor
0.085 W
0.045 W
0.05 W
- 50 °C
- 25 °C
+ 70 °C + 125 °C + 150 °C
Copper alloy
100 % matte tin
Sn85
Plated
GLOBAL PART NUMBER INFORMATION
New Global Part Numbering: TOMC16031002BUF
T
T
O
O
M
M
C
C
T
1
1
6
6
0
0
3
1
Power
Molded epoxy
0.75 W
0.65 W
1
1
0
0
0
0
2
3
B
Z
U
T
F
1
GLOBAL MODEL
(4 or 5 digits)
TOMC
(Tin lead)
TOMCT
(Lead (Pb)-free)
(e3)
PINS
16
SCHEMATIC
01
= 15 bussed
equal resistors
03
= 7 or 8
isolated equal
resistors
RESISTANCE
First 3 digits are
significant figures and
the last digit specifies
the number of zeros
to follow.
Example:
1002 = 10K
1003 = 100K
TOLERANCE AND
RATIO TOLERANCE
Abs. Tol.
A
= 0.1 %
(1)
B
= 0.1 %
C
= 0.25 %
D
= 0.5 %
F
=1%
Z
= 0.1 %
(2)
Ratio
0.05 %
0.1 %
0.1 %
0.1 %
0.5 %
0.025 %
PACKAGING
TAPE AND REEL
T0
= 100 min., 100 mult
T1
= 1000 min., 1000 mult
(3)
T3
= 300 min., 300 mult
T5
= 500 min., 500 mult
TF
= Full reel 2000
TS
= 100 min., 1 mult
UF
= TUBED
Historical Part Number example: TOMC16011002Z (for reference purposes only)
TOMC
SERIES
16
NUMBER OF LEADS
01
SCHEMATIC
1002
RESISTANCE
Z
TOLERANCE AND
RATIO TOLERANCE
Notes
(1)
Tolerance available 250 and up
(2)
Tolerance available 1K and up
(3)
Preferred packaging code
