Getting started
3.1 Kit contents/packing list
The FRDM-HB2001FEVM contents includes:
•
Assembled and tested evaluation board/module in anti-static bag
•
FRDM-KL25Z
•
Quick start guide
3.2 Jump start
NXP’s analog product development boards provide an easy-to-use platform for
evaluating NXP products. The boards support a range of analog, mixed-signal and power
solutions. They incorporate monolithic ICs and system-in-package devices that use
proven high-volume SMARTMOS technology. NXP products offer longer battery life, a
smaller form factor, reduced component counts, lower cost and improved performance in
powering state of the art systems.
1. Go to
www.nxp.com/FRDM-HB2001FEVM.
2. Review your Tools Summary Page.
3. Locate and click:
4. Download the documents, software and other information.
Once the files are downloaded, review the user guide in the bundle. The user guide
includes setup instructions, BOM and schematics. Jump start bundles are available on
each tool summary page with the most relevant and current information. The information
includes everything needed for design.
3.3 Required equipment
This kit requires the following items:
•
3/16” blade screwdriver for connecting the cables
•
DC Power supply: 5.0 V to 40 V with up to 20 A current handling capability, depending
on motor requirements
•
USB Standard A (male) to mini-B (male) cable
•
Typical loads (brushed DC motor, power resistors or inductive load with up to 5.0 A and
28 V operation)
•
Function generator (optional)
•
FRDM-KL25Z Freedom Development Platform for SPI communication (included in KIT)
•
SPIGen software (for using FRDM-KL25Z based SPI Dongle)
3.4 System requirements
The kit requires the following to function properly with the software:
•
USB enabled computer with Windows XP or newer
KTFRDMHB2001FEVMUG
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2016. All rights reserved
User guide
Rev. 1.0 — 25 May 2016
3 / 35
NXP Semiconductors
KTFRDMHB2001FEVMUG
FRDM-HB2001FEVM evaluation board
4
Getting to know the hardware
4.1 Board overview
The FRDM-HB2001FEVM evaluation kit exercises all the functions of the MC33HB2001
H-Bridge device. The parallel input can be easily controlled by lab equipment or any
MCU with GPIOs.
The board can be used in conjunction with a FRDM-KL25Z board connected to a PC’s
USB port. Configure, control and monitor the status of MC33HB2001 by using the
board’s SPI communication capabilities.
4.2 Board features
The FRDM-HB2001FEVM board evaluates the NXP part MC33HB2001, including all
functions. The board features the following:
•
•
•
•
•
•
Built-in reverse battery protection
Test points allows probing its signals
Built-in voltage regulator to supply logic level circuitry
LEDs to indicate the supply status and the direction of the motor
Low Equivalent Series Resistance (ESR) capacitor to reduce ripple in the power supply
Transient voltage suppressor to handle system level transients
KTFRDMHB2001FEVMUG
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2016. All rights reserved
User guide
Rev. 1.0 — 25 May 2016
4 / 35
