RP135 Series
1 A to 200 A Chassis Mount Filter
Specifications
Operating Frequency
Usable Frequency
Max. Operating Voltage*
Ambient Temperature
Climatic Category
Hipot Rating (L-G)
Terminals (-T)
Safety Approvals
50/60 Hz
DC - 400 Hz
250 V +10%
-25 to 40°C
25/100/21
2700 VDC
QD: 0.25 Tab (1-20 A)
S: 30 A (M4)
60-100 A (M6)
150-200 A (M10)
CSA, UR, EN60939
SINGLE PHASE FILTERS
High Performance Single Stage Power Line Filters
Electrical Schematic
*Available up to 300 VAC. Please contact us to verify specifications.
Part Number/Ordering
RP135
-X
(Amps)
1
3
6
10
16
20
30
60
100
150
180
200
-Y
(Ycap, nF)
0
0.47
1
2.2
4.7
10
22
100
-T
QD
QD
QD
QD
QD
QD
S
S
S
S
S
S
Typ. Weight,
lbs (kg)
0.1 (0.04)
0.1 (0.04)
0.1 (0.04)
0.1 (0.04)
0.5 (0.2)
0.5 (0.2)
0.5 (0.2)
2.8 (1.3)
6.0 (2.7)
6.0 (2.7)
6.0 (2.7)
6.0 (2.7)
Leakage Current
Y-cap, nF
0
0.47
1
2.2
4.7
10
22
100
mA,
120 V/60 Hz
0.0
0.04
0.09
0.2
0.4
0.9
2.0
9.0
mA,
250 V/60 Hz
0.0
0.08
0.18
0.4
0.8
1.8
4.0
18.0
Note:
Use any combination of -Y with any -X (Amps) rating
e.g. RP135-100-4.7-QD (100 Amps with 4.7 nF Ycap)
Specifications are subject to change. Consult factory to verify specifications.
For more information on our filter products call us at: (800) 527-4362 or (714) 289-0055
LCR, Radius Power, and Filter Concepts are now part of Astrodyne TDI
www.AstrodyneTDI.com
RP135 Series
1 A to 200 A Chassis Mount Filter
Typical Insertion Loss, dB (50/50 Ohm)
Freq (MHz)
0.15
0.5
1.0
10
30
SINGLE PHASE FILTERS
High Performance Single Stage Power Line Filters
P
P
P
Mechanical Dimensions
RADIUS POW
RADIUS POW
Your Power Pa
RADIUS POW
Your Power P
Insertion Loss, dB (50/50ohm)
1 Amp
Insertion Loss,
50
(50/50ohm)
dB
50 45 40
CM(dB)
40
DM(dB)
15
Insertion Loss,
26
(50/50ohm)
dB
45 50 50
3 Amp
CM(dB)
DM(dB)
6 Amp
CM(dB)
30
18
1 Amp
42
30
50
40
36
32
40
40
55
55
35
50
Mechanical Dimensions
