852604 BK002 Overview

Multi-core cable 26AWG 4C UNSHIELDED 500FT SPOOL BLACK

852604 BK002 Parametric

Parameter Name	Attribute value
Maker	Alpha Wire
Product Category	multi-core cable
Shipping restrictions	Due to product size or weight, shipping to your country can only be purchased in USD.
type	Xtra-Guard
Number of conductors	4 Conductor
length	500 ft
Shell color	Gray (Slate Gray)
outer diameter	6.3 mm
Shell material	Polyvinyl Chloride (PVC), Oil Resistant
shield	Shielded
conductor material	Copper
Insulation Materials	Polyvinyl Chloride (PVC)
stranded	19 x 38
Voltage rating	600 V
Factory packaging quantity	1
unit weight	6.123 kg

Preview

Download Datasheet

View All

Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207

Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com

Customer Specification

PART NO. 852604

Construction

Diameters (In)

1) Component 1

a) Conductor

b) Insulation

(1) Print

(2) Color(s)

Cond

Color

RED #1

Cond

Color

RED #3

Cond

Color

4 X 1 COND

26 (19/38) AWG Bare Copper

0.022" Wall, Nom. PVC

0.020

0.064

ALPHANUMERIC NUMBERS - 1-ONE ALTERNATING AND

INVERTED

RED #2

YELLOW/GREEN/GR

EEN

2) Cable Assembly

a) Twists:

b) Orientation:

c) Core Wrap

3) Jacket

a) Color(s)

b) Jacket Separator

4 Components Cabled

8.0 Twists/foot (min)

Components to be arranged from INSIDE

LAYER to OUTSIDE LAYER

REMAY Tape, 25% Overlap, Min.

0.035" Wall, Nom.,PVC, Oil Resistant

BLACK

Tissue Tape, 25% Overlap, Min.

ALPHA WIRE-* P/N 852604 4C 26 AWG

XTRAGUARD(R) CONTINUOUS FLEX CONTROL CABLE

0.248+/- 0.016

c) Print

RU AWM 2587 CONSTANT FLEXING OR CRU

AWM I/II A/B FT1 90C 600V

CE ROHS (SEQ FOOTAGE)

* = Factory Code

Applicable Specifications

1) UL

a) Component 1

b) Overall

2) CSA International

AWM/STYLE 10012

AWM/STYLE 2587

C(RU) AWM I/II A/B

FT1

3) Other

4) CE:

VDE 0472, Section 803 Oil Test

EU Low Voltage Directive 2014/35/EU

90°C / 600 VRMS

EU/China ROHS CERTIFICATE OF COMPLIANCE

To Whom It May Concern:

Alpha Wire Part Number: 852604

852604 , RoHS-Compliant Commencing With 2/15/2018 Production

Note: all colors and put-ups

This document certifies that the Alpha part number cited above is manufactured in accordance with Directive 2011/65/EU of the European

Parliament, better known as the RoHS Directive (commonly known as RoHS 2), with regards to restrictions of the use of certain hazardous

substances used in the manufacture of electrical and electronic equipment. This certification extends to amending Directive 2015/863/EU which

expanded the list of restricted substances to 10 items (commonly known as RoHS 3) The reader is referred to these Directives for the specific

definitions and extents of the Directives. No Exemptions are required for RoHS Compliance on this item. Additionally, Alpha certifies that the listed

part number is in compliance with China RoHS “Marking for Control of Pollution by Electronic Information Products” standard SJ/T 11364-2014.

Substance

Lead

Mercury

Cadmium

Hexavalent Chromium

Polybrominated Biphenyls (PBB)

Polybrominated Diphenyl Ethers (PBDE) ,

Including Deca-BDE

Bis(2-ethylhexyl) phthalate (DEHP)

Butyl benzyl phthalate (BBP)

Dibutyl phthalate (DBP)

Diisobutyl phthalate (DIBP)

0.1% by weight (1000 ppm)

Maximum Control Value

0.1% by weight (1000 ppm)

0.01% by weight (100 ppm)

0.1% by weight (1000 ppm )

0.1% by weight (1000 ppm)

The information provided in this document and disclosure is correct to the best of Alpha Wire's knowledge, information and belief at the date of its

release. The information provided is designed only as a general guide for the safe handling, storage, and any other operation of the product itself or

the one that it will become part of. The intent of this document is not to be considered a warranty or quality specification. Regulatory information is

for guidance purposes only. Product users are responsible for determining the applicability of legislation and regulations based on their individual

usage of the product.

Authorized Signatory for the Alpha Wire:

Dave Watson, Director of Engineering & QA

Alpha Wire

711 Lidgerwood Ave.

Elizabeth, NJ 07207

Tel: 1-908-925-8000

12/4/2018
