Product Overview
AR0221: CMOS Image Sensor, 2.1 MP, 1/1.7"
For complete documentation, see the data sheet.
ON Semiconductor AR0221 is a 1/1.7-inch CMOS digital image sensor with an active-pixel array of 1928 (H) × 1088 (V). This
advanced image sensor captures images in either linear or high dynamic range, with rolling-shutter readout. It includes sophisticated
camera functions such as in-pixel binning, windowing and both video and single frame modes. AR0221 is optimized for both low light
and high dynamic range scene performance with 4.2um BSI pixels. The sensor includes flexible functions such as in-pixel binning,
windowing, and both video and single frame modes. The device is programmable through a simple two-wire serial interface, and
supports both MIPI and HiSPi output interfaces.
Features
•
•
•
•
•
•
•
•
•
•
2.1Mp at 60 fps for Excellent Video Performance
Optical Format (1/1.7-inch)
1080p Mode for 16:9 Video
Superior Low-light Performance
4.2um large Back Side Illuminated Pixel Technology
Supports Line Interleaved T1/T2/T3 Readout to Enable HDR Processing in ISP Chip at 1080P and 30fps
On-chip Phase-locked Loop (PLL) Oscillator
Integrated Color and Lens Shading Correction
Slave Mode for Precise Frame-rate Control
Data Interfaces: - 4-lane MIPI CSI-2 and HiSpi SLCS
For more features, see the data sheet
Applications
• Video Surveillance
• High Dynamic Range Imaging
End Products
•
•
•
•
Security Camera
Action camera
Car DVR
Body camera
Part Electrical Specifications
Product
AR0221SR2C00SUEA
0-DPBR
Compliance
Pb-free
Halide free
Status
NEW
Type
CMOS
Megapixel
s
2.1
Frame
Rate (fps)
60
Optical
Format
1/2 inch
Shutter
Type
Pixel Size
(µm)
Output
Interface
Multi
Color
RGB
Package
Type
IBGA-87
Electronic 4.2 x 4.2
Rolling
and Global
Reset
Release
Electronic 4.2 x 4.2
Rolling
and Global
Reset
Release
AR0221SR2C00SUEA
0-DRBR
Pb-free
Halide free
NEW
CMOS
2.1
60
1/2 inch
Multi
RGB
IBGA-87
For more information please contact your local sales support at www.onsemi.com.
Created on: 12/6/2018
