Part Number

Search

599-0010-007F

Description
Standard LED-SMD SMD 0603 RED
CategoryLED optoelectronic/LED    photoelectric
File Size814KB,3 Pages
ManufacturerDIALIGHT
Websitehttps://www.dialight.com
Environmental Compliance
Download Datasheet Parametric Compare View All

599-0010-007F Online Shopping

Suppliers Part Number Price MOQ In stock
599-0010-007F - - View Buy Now

599-0010-007F Overview

Standard LED-SMD SMD 0603 RED

599-0010-007F Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerDIALIGHT
Reach Compliance Codecompliant
Samacsys DescriptionStandard LEDs - SMD SMD 0603 RED
colorRED
ConfigurationSINGLE
Maximum forward current0.03 A
Lens typeNONDIFFUSED
Nominal luminous intensity45.0 mcd
Installation featuresSURFACE MOUNT
Number of functions1
Number of terminals2
Maximum operating temperature100 °C
Minimum operating temperature-40 °C
Optoelectronic device typesSINGLE COLOR LED
total height0.7 mm
method of packingTR, 7 INCH
shapeRECTANGULAR
size1.1 mm
surface mountYES
Terminal pitch1.6 mm
perspective140 deg
MicroLED
®
SMD LED, Single Color 0603 Package
1.6 mm x 0.8 mm x 0.7 mm
Certifications & Ratings
• RoHS compliant
599 Series
Features & Benefits
• Compatible with automatic placement equipment
• Packaged in 8 mm tape, 7" reel (4000 pcs/reel)
and 20 per strip
• Meets EIA-481-1 pkg. std.
Part Number Guide
RoHS Compliant
Dimensions
inches [mm]
.063 [1.6]
.031
[0.8]
Tolerance
±0.2
mm unless otherwise noted
Package
5 9 9 - 0 0
Color
Red
X
1
2
3
4
6
8
9
X - 0 0 X F
Packaging Option
0
0
0
0
0
1
1
2
20 piece tape
7" reel
7
4000 pcs/reel
1
2
1
R .007
[R 0.18]
2
.028
[0.7]
Red-Orange
Orange
Yellow
Yellow-Green
Green
Polarity Mark
.028 [0.7]
.043 [1.1]
.012 [0.3]
.028 [0.7]
1
+
2
Blue
Tape
Tolerance
±0.1
mm unless otherwise noted
Soldering
.031
[0.8]
.031
[0.8]
.031
[0.8]
Feed Direction
.036
[0.92]
.079
[2.0]
.157
[4.0]
.061
[1.55]
Cathode
Polarity Mark
.069
[1.75]
.315
.071 [8.0]
[1.8]
0.094[2.4]
Direction of
Light Emission
.207
[5.25]
Reflow Profile
Temp °C
250
time at peak 10 sec (max)
ramp up
3°C/sec (max)
time above 217 °C
60–150 sec
Top
of Tape
.037 [0.95]
Back view
Tpeak = 260 °C
Hand Soldering
Temperature: 300° C max.
Soldering time: 3 sec max.
(one time only)
TL = 217 °C
200
Tsmax = 200 °C
Reel
Tolerance
±0.1
mm unless otherwise noted
150
.315 [8.0]
7.01
[178±1.0]
2.362
[60±1.0]
25
Tsmin=
150 °C
120 sec (max)
Pre-heat: ∆T: 150–200 °C
60 sec
(min)
ramp down
6 °C/sec (max)
0603
598 Series, pkg
pkg diagram scaled at 1 : 45
RF-AUB190TS-ED E2 RF-0055NP
2017-11-4.pdf
.512
[13±0.5]
Total Time to Peak temp < 8 min.
∆T: 25–260 °C
Time
Label
www.dialightsignalsandcomponents.com
60 sec
598 Series, pkg 0603
pkg diagram scaled at 1 : 45
RF-AUB190TS-ED E2 RF-0055NP
2017-11-4.pdf
598 Series, pkg 0603
