PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
1723751707
Active
Impact Backplane Connector and Cable Assembly System
Impact zX2 95 Ohm 6 Pair Vertical Backplane Header, Unguided, 14 Columns, 336
Circuits, Plated Through Hole Dimension 0.36mm, Lead-Free
Documents:
3D Model
Drawing (PDF)
Product Specification PS-172374-999 (PDF)
Product Specification PS-172374-999-001 (PDF)
General
Product Family
Series
Application
Component Type
Overview
Product Name
UPC
Physical
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Guide to Mating Part
Keying to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Columns
Number of Pairs
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Polarized to PCB
Stackable
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
Electrical
Current - Maximum per Contact
Data Rate
Impedance
Application Specification AS-172374-0001 (PDF)
Packaging Specification PK-70873-7703 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
EU ELV
Not Relevant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per
-ED/01/2018 (15
January 2018)
Halogen-Free
Status
Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Green Image
Not Relevant
Not Contained
Backplane Connectors
172375
Backplane, Conventional
PCB Header
Impact Backplane Connector and Cable Assembly
System
Impact zX2
887191652382
336
336
Black
200
No
No
None
High Performance Alloy (HPA)
Gold
Tin
High Temperature Thermoplastic
6.568/g
14
6
24
Vertical
1.40mm
No
None
1.00mm
Tray
1.35mm, 1.90mm
1.35mm, 1.90mm
0.762µm
No
Yes
No
-55°C to +85°C
Through Hole - Compliant Pin
0.75A
28.0 Gbps
95Ω
Search Parts in this Series
172375 Series
Mates With
Impact zX2 Daughtercard 173092
Application Tooling
|
FAQ
Tooling specifications and manuals are
found by selecting the products below.
Crimp Height Specifications are then
contained in the Application Tooling
Specification document.
Global
Description
Product #
Press-In Tool for 6- 0622018639
Pair by 14-Column
Backplane
Shield Type
Shielded
Voltage - Maximum
Solder Process Data
Lead-freeProcess Capability
Material Info
Reference - Drawing Numbers
Application Specification
Packaging Specification
Product Specification
Ground Plane Shield
Yes
150V AC (RMS)
N/A
AS-172374-0001
PK-70873-7703
PS-172374-999, PS-172374-999-001
