The EVK75123 is the evaluation kit for the MLX75023 and MLX75123
Time-of-Flight (TOF) chipset. This new chipset enables real-time 3D imaging
at full QVGA resolution with unsurpassed sunlight robustness. The evaluation
kit is a complete camera built around this chipset and can be directly connected
to a PC for visualization and recording of depth map data, while allowing direct
access to many configuration settings.
EVK75123 is a modular plug and play platform perfectly set up for customization by its customers. The kit consists
of four stacked PCBs (from top to bottom: illumination board, TOF chipset board, interface board and a processor
board). It is possible to detach the top two PCBs from the bottom two PCBs by bypassing the board to board
connection with an external cable suitable for FPD-Link III communication. A graphical user interface for
Windows is provided for live depth map visualization, basic recording, analysis and configuration. For custom SW
development, a MATLAB SDK and C API is also provided. The built-in flexibility of our evaluation kit enables any
designer to develop the necessary system know-how and experience for use in their application.
The evaluation kit is available in variants with 60 deg and 110 deg field-of-view (FOV).
KEY FEATURES
k
MLX75023 and MLX75123 TOF Chipset
k
QVGA resolution
k
120 klux sunlight rejection
k
VCSEL illumination (60° or 110°)
k
Modulation frequency up to 40MHz
k
Distance and confidence data at max. 60 FPS
k
Visualizer, C API and Matlab SDK
k
Dimensions: 80 x 50 x 35mm
15mm TOF chipset board only
FOR MORE INFORMATION: WWW.MELEXIS.COM/EVK75123
Microbats generate ultrasound via the larynx and emit the
sound through the nose or open mouth: from 14,000 to over
100,000 hertz, well beyond the range of the human ear. The
emitted vocalizations form a broad beam of sound used to
probe the environment, as well as communicate with other bats.
ILLUMINATION BOARD
k
4x VCSELs (60° or 110° field of view)
k
Programmable peak optical power (0 - 25W)
k
Onboard temperature sensor
k
Eye safe (certificate available)
EVK75123 PACKAGE CONTENTS
k
1x HW module
k
1x external AC/DC PSU
k
1x ethernet cable
k
Visualizer for Windows
k
MATLAB SDK & C API (+ example code)
k
Registration number (for SW, documentation
& support)
TOF CHIPSET BOARD
k
MLX75023 QVGA, 320x240 pixels, TOF sensor array
k
MLX75123 TOF companion chip
k
Standard S mount (M12x0.5) lens holder
k
Two temperature sensors
k
Programmable input clock and VMIX voltage
k
FPD-Link III serializer
EVK75123 ORDER CODES
k
EVK75123-60-850-1 : 60deg FOV, 850nm VCSELs
k
EVK75123-110-850-1 :
110deg FOV, 850nm VCSELs
k
EVK75123-110-940-1 :
110deg FOV, 940nm VCSELs
INTERFACE BOARD
k
Interface between TOF Chipset Board and
CM-i.MX6 Board
k
FPD-Link III deserializer
k
Power input (9 - 16V) and RJ45 ethernet connector
k
GPIO connector (I
2
C, SPI, VIN, 3V3 & three GPIOs)
CM-I.MX6 PROCESSOR BOARD
k
Quad core i.MX6 processor running up to 1.2 GHz
k
Calculates the distance and confidence data
BLOCK DIAGRAM
3V3
RECEIVING
OPTICS
VMIX
Array
Blas
3V3
1V8
CLK
TOF CHIPSET BOARD
MEMORY
D+
TOF SENSOR
MLX75023
Digital
control
TOF CC
MLX75123
I
2
C
SERIALIZER
Digital
Data
D-
DESERIALIZER
MICRO-
CONTROLLER
I.MX6
Analog
Data
SCENE
SCENE
LEDN
LCDP
INTERFACE
BOARD
Ethernet
Connection
CM-I.MX6 PROCESSOR
BOARD
BEAM
SHAPING
OPTICS
LED
OR
VCSEL
ILLUMINATION
ILLUMINATION
DRIVER
ILLUMINATION BOARD
LEN
