MAX40003EVKIT# Overview

Amplifier IC development tool MAX40003 EVAL KIT

MAX40003EVKIT# Parametric

Parameter NameAttribute value
MakerMaxim
Product CategoryAmplifier IC Development Tools
productEvaluation Kits
typeComparators
Tools for assessmentMAX40003ANS02
Working power voltage100 mV to 5.5 V
Description/FunctionEvaluates WLP-4 package
Factory packaging quantity1
MAX40002–MAX40005
Evaluation Kits
Evaluates: MAX40002–MAX40005
The MAX40002–MAX40005 evaluation kits (EV kits) are
fully assembled and tested PC boards that evaluate
the
MAX40002ANS02–MAX40005ANS02
single
comparators. The MAX40002ANS02–MAX40005ANS02
operate from a V
CC
supply between 1.7V to 5.5V, come
with an internal reference voltage of 0.2V, and have a
wide 0.1V to 5.5V input voltage (IN) range. These EV kits
demonstrate the MAX40002ANS02–MAX40005ANS02 in
an ultra-small, 0.76mm x 0.76mm, 4-bump wafer-level
package (WLP) with 0.35mm bump spacing.
These EV kits are configured to evaluate the entire
MAX40002–MAX40005 family with a 4-bump wafer-level
package (WLP).
General Description
Quick Start
Required Equipment
Before beginning, the following equipment is needed:
Three +5V DC power supplies (V
CC
/REF, IN, and V
PU
)
One digital multimeter (DMM)
Procedure
The MAX40002–MAX40005 EV kits are fully assembled
and tested. Follow these steps to verify board operation.
Do
not turn on the power supply until all connections are
completed.
1)
2)
3)
4)
5)
6)
7)
Connect the positive terminal of a DC power supply to
the V
CC
pad and the ground terminal to the GND pad.
Connect the positive terminal of a DC power supply to
the V
PU
pad and the ground terminal to the GND pad
(MAX40002/MAX40003 only).
Connect the positive terminal of a DC power supply to
the IN pad and the ground terminal to the GND pad.
Turn on the V
CC
power supply and set it to the
desired level.
Turn on the V
PU
power supply and set it to the
desired level (MAX40002–MAX40003 only).
Turn on the IN power supply and set it to the
desired level.
Monitor the output using a DMM at the OUT pad,
and study its response to varying voltage at IN (refer
to
Table 1
for more information).
Features
0.1V to 5.5V Input Voltage Range
1.7V to 5.5V External Reference Range
(MAX40002ANS─MAX40005ANS)
1.7V to 5.5V V
CC
Range with Internal Reference
(MAX40002ANS_ _─MAX40005ANS_ _)
• 0.2V, 0.5V, 0.9V and 1.222V Internal Reference
Options Available
Evaluates 4-Bump WLP Package
Fully Assembled and Tested
Ordering Information
appears at end of data sheet.
19-8554; Rev 0; 1/17
