Product Brief
LSI SAS 9201-16e
16-Port, 6Gb/s SAS+SATA to PCI Express Host Bus Adapter
Key Features
■■
■■
■■
■■
16-Port SAS HBA Provides Maximum Connectivity and Performance for
External JBOD and External RAID Enclosures
Overview
The LSI SAS 9201-16e, quad port, host bus adapter provides maximum connectivity and
performance for external JBOD and external RAID enclosures. The LSI SAS 9201-16e provides
16 lanes of 6Gb/s SAS connectivity to 8 lanes of PCI Express 2.0. Performance is based on the
LSISAS2116 IO controller that highly integrates the latest enhancements in PCI Express and SAS
technology. The HBA supports up to 512 SAS or SATA devices.
The LSI SAS 9201-16e has four (x4) external mini -SAS connectors (SFF8088) enabling a solution
which provide SAS and SATA data transfer rates of 1.5, 3 and 6Gb/s per lane through automatic
speed negotiation that can achieve over 430,000 IOPs. Enhanced features include T-10 Protection
Information Model for early detection of and recovery from data corruption, and Spread Spectrum
Clocking (SSC) for minimal EMI.
16 external 6Gb/s SAS+SATA ports
8 lanes, PCI Express 2.0
Standard height form factor
Four x4 external mini-SAS connectors
(SFF8088)
LSISAS2008 6Gb/s SAS+SATA
Controller
Supports up to 512 SAS or SATA
end devices
Supports SSDs, HDDs and tape drives
■■
■■
■■
Key Advantages
■■
Maximum external connectivity
and performance in a standard height
form factor
8 lanes of PCI Express 2.0 provides
fast signaling for high-bandwidth
applications and broad compatibility
with latest motherboards
High performance with 6Gb/s data
transfer rates
■■
SAS Leadership
LSI offers the broadest SAS product portfolio in the industry with true end-to-end solutions
including controllers, expanders, active-active multiplexers, ROCs, host bus adapters, RAID solutions,
and external storage. LSI’s proven SAS core has completed extensive stress and interoperability
testing resulting in the industry’s most robust, interoperable solution.
LSI has supplied leading edge serial technology to systems throughout the world for over seven
generations, making LSI the most experienced enabler of serial interconnect for storage in the
world. Integrators can be assured that their LSI adapter is providing the most advanced and robust
serial technology available.
■■
Fusion MPT Architecture
The LSI SAS host bus adapters are based on the Fusion MPT™ architected SAS controllers, which
implements LSI’s Fusion-MPT (Message Passing Technology) architecture. Each controller features
embedded PowerPC™ processors that deliver maximum host CPU offload. The builtin intelligence
enables LSI to publish a single binary OS driver to operate any Fusion MPT controller or adapter. The
architecture enables high performance, reduced software development, and faster time to market.
Product Brief
LSI SAS 9201-16e Host Bus Adapter
IO Controller
Storage Connectivity Data Transfer Rates
SAS Bandwidth
Port Configurations
Host Bus
PCI Data Burst Transfer Rates
LSISAS2116, Fusion MPT 2.0
16 ports; 6Gb/s SAS 2.0 compliant
Half Duplex
600 MB/s per lane
16 ea, x1 ports (individual drives)
4 ea, x4 wide ports
x16 lane, PCI Express 2.0 compliant
Half Duplex
x8, PCIe, 4000 MB/s
3.3 V Add-in Card
Physical Dimensions
Connectors
Brackets
Cable Support
PCI Card Type
Operating Voltage
PCI Power (Nominal)
Device Support
Environmental
Full Height (4.2” x 6.6”)
Four mini-SAS external connectors (SFF8088)
Full height
Passive, Active Copper
3.3 V Add-in Card
+12V +/-8%; 3.3V +/-8%
17W typical (Airflow min 200 LFM)
512 Non-RAID SAS/SATA devices
Operating
0oC to 55oC
5 to 90% Non-condensing
MTBF
Regulatory Certifications
OS Support
Warranty
>2,000,000 Hours
EMC: Class B-US (CFR 47, P15B); Canada (ICES-003); Japan (V-3/02.04); Europe (EN55022/EN55024);
Australia/ New Zealand (AS/NZS 3548); Safety: EN60950; RoHS; WEEE
Microsoft Windows, Linux (SuSE , Red Hat), Solaris, VMware
See http://www.lsi.com/channel/ChannelDownloads for details on versions
3 years; with advanced replacement option
Free technical support at http://www.lsi.com/channel/support
Storage
-45°C to 105°C
5 to 90% Non-condensing
Ordering Information
SAS 9201-16e SGL
MPN: H5-25379-00
OPN: LSI00276
Visit the Avago Server Storage website at:
avagotech.com/server-storage
