Slim-SATA SSD MO-297
X-200s Series
SATA II - 3.0Gb/s
up to UDMA6 / MDMA2 / PIO4
Standard and industrial
temperature grade
B U:
Sw i ss b it Gr ou p
Date :
De ce m be r 18 , 20 1 4
Re vi si o n: 1 .1 2
X - 2 00 s_ fa ct_ s he e t_ SA - V x BR_Re v 1 1 2 .d oc
Swissbit AG
Industriestrasse 4
CH-9552 Bronschhofen
Switzerland
Swissbit reserves the right to change products or specifications without notice.
www.swissbit.com
info@swissbit.com
Revision: 1.12
X-200s_fact_sheet_SA-VxBR_Rev112
Page
1 of 4
X-200s Series – Industrial Slim-SATA Solid State Drive
2GByte up to 64GByte (MO-297)
Feature summary
Form factor:
o
Full-sized mSATA form factor
o
JEDEC MO-297 sized Solid State Drive (SSD)
o
54mm x 39mm x 4mm
o
7+15 pin (SATA+power) SATA connector
o
Replacement of a standard SATA-compliant HDD
Interface:
o
SATA Rev 2.6 - 3Gbit/s (1.5Gbit/s compatible)
Highly-integrated memory controller
o
max. UDMA6 supported
o
max. PIO mode 4, MDMA2 supported
o
SLC NAND Flash
o
Hardware BCH-code ECC (8 Bit correction per sector for SLC)
o
fix drive configuration
Low-power CMOS technology
5.0V ± 10% power supply (3.3V optional)
Low Power, less than 500mA
optional activity LED, write protect, Quick erase switch and conformal coating on request
No mechanical noise
Wear Leveling: active wear leveling of static and dynamic data
The wear leveling assures that dynamic data as well as static data is balanced evenly across the
memory. With that the maximum write endurance of the device is guaranteed.
High reliability
o
MTBF > 2,500,000 hours
o
Data reliability: < 1 non-recoverable error per 10
14
bits read
o
Number of connector insertions/removals: >1,000
High performance
o
Up to 300MB/s burst transfer rate in SATA II - 3.0Gb/sec
o
Sustained Write performance: up to 95MB/s
o
Sustained Read Performance: up to 120MB/s
Available densities
o
2GByte up to 64GByte (SLC NAND Flash)
S.M.A.R.T., HPA, Security and 48bit feature set
2 Temperature ranges
o
Commercial Temperature range
0 … +70°C
o
Industrial Temperature range
-40 … +85°C
Life Cycle Management
Controlled BOM
RoHS compatible
Swissbit AG
Industriestrasse 4
CH-9552 Bronschhofen
Switzerland
Swissbit reserves the right to change products or specifications without notice.
www.swissbit.com
info@swissbit.com
Revision: 1.12
X-200s_fact_sheet_SA-VxBR_Rev112
Page
2 of 4
Pin out
The SLIM SATA connector is a standard SATA 7+15pin connector.
Table 1: Pin Assignment, name, and description
Pin
S1
S2
S3
S4
S5
S6
S7
P1…P3
P4…P6
P7
P8…P9
P10
P11
P12
P13…P15
Signal Name
Ground
A+
A-
Ground
B-
B+
Ground
3.3V
Ground
5V
5V
Ground
Device activity
Ground
12V
Description
Signal Ground
+ Differential Receive signal
- Differential Receive signal
Signal Ground
- Differential Transmit signal
+ Differential Transmit signal
Signal Ground
3.3V power (optional on request)
Power Ground
5V precharge
5V power
Power Ground
DA / LED (optional NC on request)
Power Ground
12V power (not used)
Swissbit AG
Industriestrasse 4
CH-9552 Bronschhofen
Switzerland
Swissbit reserves the right to change products or specifications without notice.
www.swissbit.com
info@swissbit.com
Revision: 1.12
X-200s_fact_sheet_SA-VxBR_Rev112
Page
3 of 4
Table 2: System Performance
System Performance
Data transfer Rate (SATA burst)
Sustained Read (max. measured)
Sustained Write (max. measured)
2GB
~60
~26
8...32GB
3.0 (1.5)
~110
~120
~47
~95
4GB
64GB
~110
~94
Unit
Gbit/s
MB/s
1.
2.
All values refer to modules with Toshiba or Micron Flash chips in UDMA mode 5, SATA 3.0Gbit/s, write/read data sequential
256 Sectors/Transfer command.
Sustained speed depends on flash type and number, file size, and burst speed
Table 3: Current consumption
(1)
at 5V ± 10%
Current Consumption
Write (UDMA6)
Read (UDMA6)
Standby
typical
350
250
125
max
400
350
140
Unit
mA
1.
All values are typical at 25° C and nominal supply voltage and refer to 16GByte SSD module.
Table 4: Environmental Specifications
Environmental Specifications
Temperature (commercial)
Temperature (industrial)
Humidity (non-condensing)
Vibration (peak -to-peak)
Shock
Operating
Non Operating
0 to 70°C
-50 to 100°C
-40 to 85°C
-50 to 100°C
85% RH, at 85°C
max. 95% RH, at 85°C
20G Peak, 10…2000Hz
1500G, 0.5ms duration, half sine wave
Table 5: Physical Dimensions
Physical
Dimensions
Width
Height
Thickness max.
Weight (typ.)
54.0
39.8 (with connector)
4 (connector)
7
Unit
mm
g
Table 6: SSD capacity specification
Capacity
2GB
4GB
8GB
16GB
32GB
64GB
Default_cylinders
3,886
7,732
15,498
16,383*)
16,383*)
16383*)
Default_heads
16
16
16
16
16
16
Default_sectors
63
63
63
63
63
63
Sectors_drive
3,896,928
7,793,856
15,621,984
31,277,056
62,586,880
125’313’024
Total addressable Bytes
1,995,227,136
3,990,454,272
7,998,455,808
16,013,852,672
32,044,482,560
64‘160‘268‘288
*) The CHS addressing is limited to about 8GB. Larger drives should be used in LBA mode.
Table 7: System Reliability and Maintenance
MTBF (at 25°C)
Data Reliability
(1) Dependent on final system qualification data.
> 2,500,000 hours
14
< 1 Non-Recoverable Error per 10 bits Read
For more information on MO-297 mechanical standard, please visit JEDEC at
www.jedec.org.
For more information on Serial ATA Revision 2.6, please visit Serial ATA International Organization at
www.serialata.org
