CM1-86DX2
Extreme Rugged™ PC/104 Single Board Computer
with Vortex86DX2 System-on-Chip
Features
●
●
●
●
●
●
●
●
●
●
Ultra low power, DM&P Vortex86DX2 SoC
Full ISA bus support
512MB/1GB onboard DDR2 memory
2x Ethernet ports
8x GPIO
VGA and 18/24-bit single channel LVDS
HD Audio for CM1-86DX2-1G version
PCI Express Mini Card and optional microSD slot
Extreme Rugged™ operating temperature: -40°C to +85°C
Supports Smart Embedded Management Agent (SEMA) functions
P
Specifications
●
●
●
●
●
●
●
●
●
●
Core System
CPU
Vortex86DX2 SoC, 800/1000 MHz
●
●
●
Ethernet
Standard
1x integrated PHY (10/100 Mbit)
Memory
Standard: 512MB DDR2 soldered on board
Optional: 1GB DDR2 soldered on board
●
●
●
Optional
1x integrated PHY (10/100 Mbit)
1x Intel
®
i210IT (10/100/1000 Mbit)
Cache
512 kB to 2 MB L2 cache
BIOS
AMI BIOS, integrated in SoC
●
●
●
●
●
●
I/O Interfaces
USB
3x USB 2.0
●
●
SEMA
®
Yes
SATA
1x SATA 1, 5 Gb/s or 1x mSATA
●
●
●
●
●
●
●
Hardware Monitor
2x LAN, watchdog
MicroSD
1x standard slot for micro SD and micro SDHC, UDMA-2 mode
●
●
●
●
●
Serial
Standard: 2x RS-232/485, Optional: 4x RS-232/485
Watchdog Timer
Yes, 3 different
PS2
Keyboard and mouse
Expansion Busses
PC/104 (ISA)
PCI Express Mini Card slot
●
●
●
●
●
LPT
Yes
GPIO
Standard: 8x
Alternative configuration(s): TTL level COM
●
●
●
Video
VGA Interface
Yes
●
●
A/D
8x Input
●
●
LVDS Interface
18/24-bit single channel
●
●
●
Power
Standard Input
ATX = 5V±5% / 5Vsb ±5% or AT = 5V±5%
●
●
●
Audio (option)
HD Audio
ALC886
●
●
Power States
No ACPI
●
●
Power Consumption
Approx. ~ 6 to 7 W
●
●
●
Mechanical and Environmental
Form Factor
PC/104 Specification 2.6
●
●
●
●
Intelligent Middleware
SEMA
®
Local management, control of embedded computer systems Extended EAPI for
● ●
monitoring, controlling and analytics applications Multiple OS support and across
●
platforms (x86, ARM)
●
●
Dimension
96 mm x 90 mm (3.775” x 3.550”)
●
●
●
●
●
Operating Temperature
Standard: 0°C to +60°C
Industrial: -20°C to +70°C
Extreme Rugged™: -40°C to +85°C
●
●
Humidity
10% to 90% (non-condensing)
●
●
●
Shock and Vibration
Non-operating: 50G peak-to-peak, 11ms duration, MIL-STD-202G Method 213B
Operating: 11.95 Grms, 50-2000 Hz, each axis, MIL-STD-202G Method 214A
●
●
Storage Temperature
-55°C to +85°C
●
●
Cooling
Passive
●
●
●
Operation System
Standard Support
Windows XP, Windows XPe, Linux
Functional Diagram
Optional:
512 MB DDR2-400
Memory Down
1GB DDR2-400
LCD
DS90C385A
LCD to LVDS
LVDS
Inverter
(Backlight)
Bridge of
Redundancy
VGA
PCIe
I
2
C
ADC
VGA
Ethernet
JTAG
I
2
C
8x A/D Input
i210IT
Optional:
GbE
ETH
8x GPIO
Vortex86DX2
RS
232/ 485
SATA
Optional: SATA or mSATA
3x USB 2.0
PCIe
2x COM
LPT
PS/ 2
mPCIe or mSATA
1x USB 2.0
Optional: 4x COM
Optional:
MicroSD Socket
PC/ 104
ISA
Speaker
Audio Codec
ALC886
Optional:
HD Audio
BMC/ SEMA
I
2
C
DIGA
LM73
Power Supply
5VDC
ATX
Stack
+
-
CM1-86DX2 Standard Variants
Product Name
CM1-86DX2-512
CM1-86DX2-1G
Product Name
CM1-86DX2-512
CM1-86DX2-1G
Form Factor
P/N
PC/104
702-0020-10
802-0020-10
902-0020-10
Vortex 86DX2
1.0 GHz
(@ ext. temp. max.
800 MHz)
~ 6-6.5W
Yes / Yes / Yes
512MB
Yes
Yes
Yes
Yes
Yes
PC/104
702-0018-10
802-0018-10
902-0018-10
Vortex 86DX2
1.0 GHz
(@ ext. temp. max.
800 MHz)
~ 7W
Yes / Yes / Yes
1GB
Yes
Yes
Yes
Yes
Yes
Speaker
HD Audio
VGA
LVDS
microSD socket
S ATA (1.5 Gbit/s)
mSATA
(lose 1x SATA port AND mPCIe)
miniPCIe (lose mS ATA)
10/100 Mbit ETH
GbE Ports
USB 2.0
COM Ports
LPT
GPIO
A/D Input(s)
Yes
No
Yes
Yes
No
1
1
1
1
0
3
2
1
8
8
Yes
Yes
Yes
Yes
Yes
1
1
1
1
1
3
4
1
8
8
CPU / SoC
CPU / SoC Speed
Overall TDP
Supply Voltage
[5 VDC / ATX / Stack]
Soldered DDR2 RAM
Bridge of Redundancy
ISA Bus (PC/104)
JTAG
IC
2
PS/2
Ordering Information
●
●
●
●
●
●
●
702-0018-10
PC/104, CM1-86DX2, Vortex 86DX2, 1.0 GHz, 1GB DRR2
onboard, incl. heatsink, Standard operating temperature
0°C to +60°C
702-0020-10
PC/104, CM1-86DX2, Vortex 86DX2, 1.0 GHz, 512MB DRR2
onboard, incl. heatsink, Standard operating temperature
0°C to +60°C
802-0018-10
PC/104, CM1-86DX2, Vortex 86DX2, 1.0 GHz, 1GB DRR2
onboard, incl. heatsink, Industrial operating temperature
-20°C to +70°C
802-0020-10
PC/104, CM1-86DX2, Vortex 86DX2, 1.0 GHz, 512MB DRR2
onboard, incl. heatsink, Industrial operating temperature
-20°C to +70°C
902-0018-10
PC/104, CM1-86DX2, Vortex 86DX2, 800 MHz,
1GB DRR2 onboard, incl. heatsink, Extreme rugged
operating temperature -40°C to +85°C
902-0020-10
PC/104, CM1-86DX2, Vortex 86DX2, 800 MHz,
512MB DRR2 onboard, incl. heatsink, Extreme rugged
operating temperature -40°C to +85°C
763-0024-10
Cable set, CM1-86DX2
*other configurations by request
www.adlinktech.com
All products and company name listed are trademarks or trade names of their respective companies.
Updated Jul. 29, 2016. ©2016 ADLINK Technology, Inc. All Rights Reserved.
All specifications are subject to change without further notice.
