COMMUNICATIONS AND
CONTROL PROCESSOR
RABBITCORE
RCM4000 SERIES
®
The RCM4000 series is designed to mount directly to a user-
supplied motherboard and acts as the microprocessor of the
embedded system. The microprocessor features 28 GPIO lines
shared with up to five serial ports and four levels of alternate
pin functions that include variable phase PWM, quadrature
decoder and input capture.
The RCM4000 series, with its robust feature set, ample
memory, 10Base-T Ethernet and analog, is ready for network
A powerful embedded Ethernet control device with the intelligence and Internet
connectivity needed for remote monitoring and control of your devices
connectivity and I/O control for true device Internet
communication and control. Evaluation of the RCM4000 is
easy with the RCM4000 development kit.
BENEFITS
– Rabbit 4000 running at 59 MHz
– Up to 1 MB (16-bit) Program Flash, 1 MB (16-bit)
SRAM, 32 MB of Flash memory
– 10Base-T Ethernet (RJ-45 connector), up to 28
GPIO, up to 5 serial ports
– 8 channels 12-bit A/D converter
– Web server capability and remote device control
– Low-cost and easily deployable platform for
non-critical embedded security
– Security-key feature with “tamper detect” and
encryption capabilities
APPLICATION EXAMPLE
Ethernet
COMPUTER
TERMINAL
JUNCTION BOX WHERE
RCM400 RESIDES
BUILDING SECURITY
RABBITCORE® RCM4000
RELATED PRODUCTS
RS-232
RabbitCore®
RCM4100
Series
RabbitCore®
RCM4200
Series
Rabbit® SBC
BL4S200
Series
RabbitCore®
RCM4300
Series
Dynamic C®
Door Sensor
Camera
Door Sensor
SPECIFICATIONS
FEATURES
RCM4000
Rabbit® 4000 at 59 MHz
Spectrum spreader for reduced EMI (radiated emissions)
10Base-T, RJ-45, 2 LEDs
512K
512K
32 MB (NAND flash)
| RCM4010
MICROPROCESSOR
EMI REDUCTION
ETHERNET PORT
SRAM (16-BIT)
FLASH MEMORY (16-BIT)
(PROGRAM)
SERIAL MEMORY (DATA)
(NAND FLASH)
BACKUP BATTERY
GENERAL PURPOSE I/O
ADDITIONAL INPUTS
ADDITIONAL OUTPUTS
ANALOG INPUTS
A/D CONVERTER RESOLUTION
A/D CONVERSION TIME
(INCLUDING 120 ΜS RAW COUNTED
AND DYNAMIC C®)
AUXILIARY I/O BUS
SERIAL PORTS
SERIAL RATE
SLAVE INTERFACE
REAL TIME CLOCK
TIMERS
WATCHDOG/SUPERVISOR
PULSE-WIDTH MODULATORS
QUADRATURE DECODER
POWER
OPERATING TEMPERATURE
HUMIDITY
CONNECTORS
BOARD SIZE
—
Connection for user-supplied backup battery (to support RTC and data SRAM)
22 parallel digital I/O lines: Configurable with 4 layers of
alternate functions
2 startup mode, reset in, CONVERT
Status, reset out, analog VREF
8 channels single-ended or 4 channels
differential programmable gain 1, 2, 4, 5, 8, 10, 16 and 20 V/V
12 bits (11 bits single-ended)
180 μs
28 parallel digital I/O lines: Configurable with 4 layers of
alternate functions
2 startup mode, reset in
Status, reset out
—
—
—
8 data lines and 6 address lines (shared with parallel I/O lines), plus I/O read/write
4 shared high-speed, CMOS-compatible ports: All 4 configurable
as asynchronous (with IrDA) or as clocked serial (SPI) 1 asynchro-
nous clocked serial port shared with programming port 1 clocked
serial port shared with A/D converter
Maximum asynchronous baud rate = CLK/8
Slave port allows the RCM4000 to be used as an intelligent peripheral device slaved to a master processor
Yes
Ten 8-bit timers (6 cascadable from the first), one 10-bit timer with 2 match registers, and one 16-bit timer with 4 outputs
and 8 set/reset registers
Yes
—
2 channels: Synchronized PWM with 10-bit counter
Variable-phase synchronized PWM with 16-bit counter
2-channel quadrature decoder accepts inputs from external
incremental encoder modules
5 shared high-speed, CMOS-compatible ports: All 5 configurable
as asynchronous (with IrDA), 4 as clocked serial (SPI), and 1 as
SDLC/HDLC 1 asynchronous clocked serial port shared with
programming port
—
3.0– 3.6 VDC, 90 mA @ 3.3V (preliminary, pins unloaded)
0° C to +70° C
5% to 95%, non-condensing
Programming header
1.84” × 2.42” × 0.77” (47 mm × 61 mm × 20 mm)
PART NUMBERS
20-101-1094
20-101-1112
DESCRIPTION
RCM4000
RCM4010
