DR4K3.5InvarB&WV5: DescriptionImage sensor DR4K3.5_Invar_B&W_v5 FT SE; CategoryThe sensor Optical sensors The image sensor; File Size136KB，3 Pages; ManufacturerAMS; Websitehttps://ams.com/zh

Download Datasheet Parametric Compare View All

DR4K3.5InvarB&WV5 Overview

Image sensor DR4K3.5_Invar_B&W_v5 FT SE

DR4K3.5InvarB&WV5 Parametric

Parameter Name	Attribute value
Maker	AMS
Product Category	Image Sensor
Shipping restrictions	Mouser does not currently sell this product.
series	Dragster
Factory packaging quantity	1

Preview

Download Datasheet

View All

PRODUCT SHEET

DRAGSTER LINE SCAN

LINE SCAN SENSORS

Designing high-speed

highand resolution line-

scan sensors were always

in the core of ams Sensors

Belgium´s development

activities. Repeatedly, ams Sensors Belgium has

set a bench mark in the resolution and speed

sensitivity of its custom line scan sensor design.

With the Dragster series of digital line scan

sensors ams Sensors Belgium oﬀers a series of

standard line scan sensors. Armed with ease of

integration the Dragster line scan series remains

unequaled in sensitivity, bandwidth, and SNR.

Dragster is the most complete digital line scan

sensor family available on the market. All sensors

share the same electrical interface and are mainly

pin compatible with each other. The Dragster

sensors are highly scalable which make them

ideal for various applications. In addition, they can

easily be integrated in standard cameras or image

processing boards.

SPECIFICATIONS

Resolution

Pixel size

Shutter type

Frame rate

Output interface

Sensitivity

Conversion gain

Full well charge

Dark noise

SNR max

Dark current

Fixed pattern noise

Chroma

Supply voltage

Power

Operating temperature range

Package

2k up to 16k

7 x 7 and 3.5 x 3.5

Global shutter

up to 80k scans/s

13 bit

77 DN/nJ/cm2 (@12bit)

0.076 DN/e-

46 ke-

22 e- rms

44

3 e-/ms

DSNU: 4 [DN] PRNU: 0.7%

Mono and RGB

3.3 V

400 mw per 2K segment

0ºC - 60ºC

LCC or Invar

Andon Electronics

(http://www.andonelectronics.com)

Dragster LCC: 690-90-SM-G10-

L14-0 Rev1

Socket

The sensor can be delivered wihthout cover glass

upon request.

For pricing and lead time please contact

ISS.CIS_info@ams.com.

CMOSIS takes care to ensure the accuracy of the information contained in this document but reserves the right to change speciﬁcations without notice.

Page 1/2
