VS-VSKU105/04

Description
SCR Module 400 Volt 105 Amp 2094 Amp ITSM
Categorysemiconductor    Discrete semiconductor    thyristor    SCR module
File Size272KB,10 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Environmental Compliance
Download Datasheet Parametric Compare View All

VS-VSKU105/04 Overview

SCR Module 400 Volt 105 Amp 2094 Amp ITSM

VS-VSKU105/04 Parametric

Parameter NameAttribute value
MakerVishay
Product CategorySCR module
On state RMS current - It RMS165 A
No repetitive on-state current2000 A
Rated repetitive off-state voltage VDRM400 V
Off-state leakage current (at VDRM IDRM)15 mA
On state voltage1.8 V
Maximum holding current Ih250 mA
Gate trigger voltage-Vgt2.5 V
Gate trigger current-Igt150 mA
Minimum operating temperature- 40 C
Maximum operating temperature+ 130 C
Installation styleChassis
Package/boxADD-A-PAK
EncapsulationBulk
Maximum turning current IBO2094 A
Current rating105 A
Circuit typeThyristors / Thyristors
Factory packaging quantity10
unit weight110 g
VS-VSKU105.., VS-VSKV105.. Series
www.vishay.com
Vishay Semiconductors
AAP Gen 7 (TO-240AA) Power Modules
Thyristor/Thyristor, 105 A
FEATURES
• High voltage
• Industrial standard package
• UL approved file E78996
• Low thermal resistance
• Designed and qualified for industrial level
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
ADD-A-PAK
BENEFITS
PRIMARY CHARACTERISTICS
I
T(AV)
Type
Package
105 A
Modules - thyristor, standard
AAP Gen 7 (TO-240AA)
• Excellent thermal performances obtained by the usage of
exposed direct bonded copper substrate
• Up to 1600 V
• High surge capability
• Easy mounting on heatsink
MECHANICAL DESCRIPTION
The AAP Gen 7 (TO-240AA), new generation of AAP
module, combines the excellent thermal performances
obtained by the usage of exposed direct bonded copper
substrate, with advanced compact simple package solution
and simplified internal structure with minimized number of
interfaces.
ELECTRICAL DESCRIPTION
These modules are intended for general purpose high
voltage applications such as high voltage regulated power
supplies, lighting circuits, temperature and motor speed
control circuits, UPS and battery charger.
MAJOR RATINGS AND CHARACTERISTICS
SYMBOL
I
T(AV)
I
T(RMS)
I
TSM
I
2
t
I
2
t
V
RRM
T
Stg
T
J
Range
50 Hz
60 Hz
50 Hz
60 Hz
CHARACTERISTICS
85 °C
VALUES
105
165
2000
2094
20
18.26
200
400 to 1600
-40 to +130
-40 to +130
kA
2
s
kA
2
s
V
°C
°C
A
UNITS
Revision: 26-Jul-2018
Document Number: 94656
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
