The information provided in this documentation contains general descriptions and/or technical characteristics of the performance of the products contained herein.
This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications.
It is the duty of any such user or integrator to perform the appropriate and complete risk analysis, evaluation and testing of the products with respect to the relevant specific application or use thereof.
Neither Schneider Electric Industries SAS nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information contained herein.
Complementary
Touch panel
Backlight lifespan
Brightness
Contrast
Character font
Analogue
10000 hours (red)
50000 hours (amber)
16 levels
8 levels via touch panel
ASCII
Chinese (simplified Chinese)
Japanese (ANK, Kanji)
Korean
Taiwanese (traditional Chinese)
24 V DC
External source
19.2...28.8 V
<= 60 A
13 W
1 LED with green for normal operation
Limited by internal memory capacity
Modbus Telemecanique Modicon
Third party protocols Mitsubishi Melsec
Third party protocols Omron Sysmac
Third party protocols Rockwell Automation Allen-Bradley
Third party protocols Siemens Simatic
Uni-TE Telemecanique Modicon
Built-in
Flush mounting
By 2 spring clips
By 4 screw clamps
PPT
PPT
CE
5.12 in (130 mm)
4.09 in (104 mm)
1
[Us] rated supply voltage
Supply
Supply voltage limits
Inrush current
Power consumption in W
Local signalling
Number of pages
Downloadable protocols
Realtime clock
Product mounting
Fixing mode
Front material
Enclosure material
Marking
Width
Height
Jul 28, 2019
Depth
Product weight
1.57 in (40 mm)
0.88 lb(US) (0.4 kg)
Environment
Immunity to microbreaks
Standards
<= 2 ms
EN 61131-2
FCC Class A
IEC 61000-6-2
UL 1604
UL 508
CSA C22.2 No 14
ATEX zone 2/22
CSA Class 1 Division 2 T4A
CSA Class 1 Division 2 T5
C-Tick
CULus
UL Class 1 Division 2 T4A
UL Class 1 Division 2 T5
32...122 °F (0...50 °C)
-4...140 °F (-20...60 °C)
0...85 % without condensation
< 6561.68 ft (2000 m)
IP20 (rear panel) conforming to IEC 60529
IP65 (front panel) conforming to IEC 60529
NEMA 4X front panel (indoor use)
15 gn 11 ms conforming to IEC 60068-2-27
9.14 V/yd (10 V/m) conforming to IEC 61000-4-3
2 kV conforming to IEC 61000-4-4 level 3
Product certifications
Ambient air temperature for operation
Ambient air temperature for storage
Relative humidity
Operating altitude
IP degree of protection
NEMA degree of protection
Shock resistance
Resistance to electromagnetic fields
Resistance to fast transients
Ordering and shipping details
Category
Discount Schedule
GTIN
Nbr. of units in pkg.
Package weight(Lbs)
Returnability
Country of origin
22569 - MAGELIS XBT-GT (AND XBT-G)
MC2
00785901670650
1
1.76
N
CN
Contractual warranty
Warranty period
18 months
2
Product data sheet
Dimensions Drawings
XBTGT1105
Dimensions
Product Reference
XBTGT1105
XBTGT1135
XBTGT1335
a in mm
41
40
a in in.
1.61
1.57
3
Product data sheet
Mounting and Clearance
XBTGT1105
Clearance
Installation Requirements
For easier maintenance, operation and improved ventilation, be sure to install the unit at least 100 mm (3.94 in) away from adjacent
structures and other equipment:
Panel Cut-out Dimensions
Dimensions in mm
Graphic Display Terminal Cut-out for Flush Mounting
