* Value in () relates to the inductive current charge: cosφ = 0.65
2
EMC/EMI Products
Schaffner Group
Datasheets
11 Oct 2018
Filter selection table
Filter
Rated current
@ 40°C (25°C)
Leakage current*
@ 250 VAC/50 Hz
(@120 VAC/60Hz)
[A]
FN 9264xx-1-06-y
FN 9264xx-2-06-y
FN 9264xx-3-06-y
FN 9264xx-4-06-y
FN 9264xx-6-06-y
FN 9264xx-10-06-y
1 (1.2)
2 (2.3)
3 (3.6)
4 (4.6)
6 (6.9)
10 (11.5)
[mA]
0.31 (0.18)
0.31 (0.18)
0.31 (0.18)
0.31 (0.18)
0.31 (0.18)
0.31 (0.18)
[mH]
5.15
2.7
2
1
0.3
0.21
0.1
0.1
0.1
[μF]
0.1
0.1
[nF]
2.2
2.2
2.2
2.2
2.2
2.2
[kΩ]
1000
1000
1000
1000
1000
1000
-06
-06
-06
-06
-06
-06
[g]
55
55
55
55
55
55
Inductance
L
Capacitance
Cx
Cy**
Resistance
R
Output
connections
Weight
* Leakage current under normal operating conditions (acc. to IEC60939-3). Note: if the neutral line is interrupted, worst case leakage could reach twice this level. For B type filters with
out Y2-capacitors the leakage current is 0.00mA.
Product selector
For example: FN 9264-1-06, FN 9264 B-6-06, FN 9264 SB-4-06-30
3
EMC/EMI Products
Schaffner Group
Datasheets
11 Oct 2018
Typical filter attenuation
Per CISPR 17; A=50 Ω/50 Ω sym; B=50 Ω/50 Ω asym
1 A types
dB
90
80
70
60
50
40
30
20
10
0
10k
100k
1M
10M
100M
B
A
2 A types
dB
90
80
70
60
50
40
30
20
10
0
10k
100k
1M
10M
100M
B
A
3 A types
dB
90
80
70
60
50
40
30
20
10
0
10k
100k
1M
10M
100M
B
A
4 A types
dB
90
80
70
60
50
40
30
20
10
0
10k
100k
1M
10M
100M
B
A
6 A types
dB
90
80
70
60
50
40
30
20
10
0
10k
100k
1M
10M
100M
B
A
10 A types
dB
90
80
70
60
50
40
30
20
10
0
10k
100k
1M
10M
100M
B
A
1 B types
2 B types
3 B types
4 B types
6 B types
10 B types
4
EMC/EMI Products
Schaffner Group
Datasheets
11 Oct 2018
Mechanical data
FN 9264
Panel cut out*
**Recommended torque for M3 (90° countersunk flat head) is 0.5 Nm
FN 9264 S
Panel cut out
Installation
5
EMC/EMI Products
Schaffner Group
Datasheets
11 Oct 2018
Accessories for IEC Inlet Filters and Power Entry Modules
The accessories displayed are a selection of available accessories for IEC Inlet filters and IEC Power entry modules. As they are displayed in a general way there might
be variants of the filters where the accessories are not available.
For further information please ask your local Schaffner Sales Partner and visit our homepage https://www.schaffner.com/.
