F-219
TMMH–116–04–L–6
TMMH–125–04–F–D–EP
(2.00 mm) .0787"
FLEXIBLE THROUGH-HOLE HEADER
SPECIFICATIONS
For complete specifications
see www.samtec.com?TMMH
Insulator Material:
Black Liquid Crystal Polymer
Terminal Material:
Phosphor Bronze
Plating:
Sn or Au over
50 µ" (1.27 µm) Ni
Current Rating (TMMH/ESQT):
4.5 A per pin
(2 pins powered)
Current Rating (TMMH/SQT):
5.1 A per pin
(2 pins powered)
Operating Temp Range:
-55 °C to +105 °C with Tin;
-55 °C to +125 °C with Gold
Voltage Rating:
281 VAC mated with SQW;
250 VAC mated with SQT
RoHS Compliant:
Yes
Lead–Free Solderable:
Yes
Board Mates:
CLT, SQT, SQW, ESQT,
TLE, SMM, MMS
Cable Mates:
TCSD
10 YEAR MFG
WITH 30 µ" GOLD
Choice of 2, 3, 4, 5 and
6 rows on (2.00 mm)
.0787" pitch
(2.00 mm)
.0787"
EXTENDED LIFE
PRODUCT
HIGH MATING
CYCLES
APPLICATION
Through-hole
(2.00 mm)
.0787"
Retention Clip Option (–RC)
ALSO AVAILABLE
(MOQ Required)
• Other platings
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
TMMH
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD STYLE
from chart
PLATING
OPTION
FILE NO. E111594
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
03 thru 50
OPTION
06
300
= Gold flash
on post,
Matte Tin on tail
–F
–L
Other Solutions
Press-fit
Surface
Mount
See PTT Series.
No. of
rows
x
(2.00)
.0787
01
295
Z
LEAD
STYLE
–01
–04
–05
–06
A
B
C
See previous page.
(2.92)
.115
(4.70)
–EC
.185
–EP & –EPC
(6.10)
.240
(4.45)
–EL & –EBC
.175
– ES
(7.67) (3.20) (2.46)
.302 .126 .097
(6.45) (1.91) (2.57)
.254 .075 .101
(5.94) (1.65) (2.29)
.234 .065 .090
(8.74) (3.20) (3.53)
.344 .126 .139
= 10 µ" (0.25 µm)
Gold on post,
Matte Tin on tail
= Matte Tin
–T
Low Profile
See TMM Series.
(2.00)
.0787
02
No. of positions x (2.00) .0787 +
Z
(2.00) .0787
100
B
(2.00)
.0787
Right-angle
Four Row
See TMM Series.
(6.35)
.250
01
(Shrouded option requires -D)
A
C
99
–D
(2.00)
.0787
No. of positions x (2.00) .0787
–T
(2.00) .0787
B
–Q
(2.00) .0787
Shrouded
Four Row
Vertical &
Right-angle
A
C
See TMMS Series.
Paste In Hole (PIH) processing.
Contact Samtec ASP Group for
part customization.
(0.50) .020
SQ
(2.00) .0787
–5
–6
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
TMMH–125–04–F–D–RA–ES
TMMH–118–04–T–D–EL
TMMH–110–04–L–D
TMMH–120–01–L–D–RA
TMMH–109–01–L–D
TMMH SERIES
Right-angle
option
FLEX SHROUD OPTIONS
–EL OPTION
–EBC OPTION
APPLICATIONS
SQT TMMH
–ES OPTION
Optional
end shrouds
HORIZONTAL
–EP OPTION
–EPC OPTION
ROW
OPTION
TAIL OPTION
FLEX SHROUD OPTIONS
OTHER
OPTIONS
= Double Row
(Required for
Flex Shroud
option)
–D
= Triple Row
–T
= Right-angle
(Double & Triple Row only)
(–ES, –EP, –EL Double Row only)
(–EC, –EBC and –EPC not available)
(–06 Lead style not available)
B
(1.27)
.050
–RA
Flex Shroud requires -D row & 9 pins/row minimum
(For board-to-board interfaces. Will not mate with TCSD)
= End Shroud
–ES
= Polarized Position
(Specify position
of omitted pin)
–“XXX”
–RC
= Four Row
–Q
–5
–6
= End Shroud with Locking Clip
(Manual placement required)
–EC
–EP
–EL
(2.62)
.103
= End Shroud with Guide Post
(2.00)
.0787
(3.20)
.126
= Retention Clip
(Mates to TCSD)
(Double row only,
minimum position 4
and available only
–06 lead style)
= Five Row
–D– RA
= Six Row
D
–T– RA
(Lead style –01 only)
LEAD
STYLE
E
= End Shroud with Board Lock
(Boards are positively locked and cannot be unmated)
X
Y
–01
(5.84) (4.45)
.230 .175
= End Shroud with Board Lock and Locking Clip
(Boards are positively locked and cannot be unmated)
–EBC
–EPC
LEAD
STYLE
–01
–04
–05
D
E
(2.34) (6.60)
.092 .260
(1.17)
(2.62) (5.26)
.046
.103 .207
(3.12) (5.26)
.123 .207
–D– RA –ES
(–RA also available with
other flex shroud options)
(3.20)
.126
(2.44)
.096
–04 &
(4.50) (3.02)
–05
.177 .119
(4.00)
.157
= End Shroud with Guide Post and Locking Clip
(Manual placement required)
(1.91)
.075
DIA
(1.83)
.072
(1.41) .056
–RC
Y
Y
X
(1.83)
.072
(2.29)
.090
(2.03)
.080
(1.83)
.072
–D– EL
(1.41) .056
–D– EBC
–D– ES
(1.41)
.056
–D– EC
–D– EPC
–D– EP
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
