F-219
ACR–12–05–G–00.25–T–S1–M–1
ACR-12 SERIES
IP68 SEALED 12 mm PANEL ASSEMBLY
SPECIFICATIONS
For complete specifications see
www.samtec.com?ACR-12
Insulator Material:
Thermoplastic
Terminal Material:
Brass
Contact Material:
Brass/BeCu
Plating:
Au over 50 µ" (1.27 µm) Ni
Operating Temp Range:
-40 °C to +80 °C
Housing:
–P: Black Nylon
–M: Zinc Alloy
RoHS Compliant:
Yes
CURRENT RATING
LEAD
PINS
CCC per
STYLE POWERED
PIN
–01
4
3.8 A
–02
5
3.6 A
2
(plus 4
–05
signal pins
5.0 A
powered
@ 1.2 A)
For general reference only.
See www.samtec.com?ACR-12
for complete test data or contact
AccliMate@samtec.com for
applications requiring higher
current carrying capacity.
Mates with:
ACP-12, ACPK-12
Variety of
end 2 options
Solutionator
DESIGN IN A MINUTE
®
• Easy sealed cable solutions
• Build a standard or flexible custom online
• Calculate performance, current rating,
voltage drop
• Live chat with AccliMate
™
engineers
for custom options
• Variety of shells, pin sizes, signal,
power, I/O interfaces
• Assembly and field kits available
Choice of
terminals or sockets
ALSO AVAILABLE
(MOQ Required)
• Other assembly lengths
ACR
12
LEAD
STYLE
PLATING
LENGTH
END
1
END
2
HOUSING
MATERIAL
KEYING
OPTIONS
DUST CAPS
• DCA-ACR-12-M-X (Metal)
• DCA-ACR-12-P-X (Plastic)
= 1.0 mm DIA (4) terminals
or sockets (24 AWG)
–01
–02
–05
= 1.0 mm DIA (5) terminals
or sockets (24 AWG)
= 10 µ"
(0.25 µm)
Gold
over 50 µ"
(1.27 µm) Ni
on contact
–G
= Length in
= Terminal
meters
(00.20 m min.
to 50.00 m max.) = Socket
Standard
lengths
–“XX.XX”
–T
= Blunt Cut
–BC
–S1
= Plastic
–P
–S
= Metal
–M
= Orange,
45°
–1
= 1.0 mm DIA (2) terminals
or sockets (24 AWG)
+ 0.5 mm DIA (4) terminals
or sockets (28 AWG)
(1.0) .040
DIA (4)
(1.0) .040
DIA (2)
= Connector
determined
by lead style.
(Specify
LEAD STYLE
from chart)
LEAD
STYLE
–01
–02
–05
–S1 END 2
MMSS (24 AWG)
MMSS (24 AWG)
MMSS (24 AWG (2x),
28 AWG (4x))
IPL1
MATES
WITH –S1
• Visit sealedio.samtec.com
for a complete list of sealed
systems
(0.5) .020
DIA (4)
–05
–05 END 2 (MMSS)
PANEL OPENING
(16.10)
.634
DIA
–01
Overall Length (XX.XX) ±2%
(13.60) .535
(1.0) .040
DIA (5)
–02
(22.00)
.866
–01 END 2 (MMSS)
END 1
Note:
Some lengths,
styles and options are
non-standard, non-returnable.
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
