Datasheet> All Categories > Connector bracket> 8-696412-2
PDF
Preview

8-696412-2

Description
PIDG 16-14 SHURPLUG 156 PIN
CategoryConnector bracket
File Size136KB，1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric View All

8-696412-2 Overview

PIDG 16-14 SHURPLUG 156 PIN

8-696412-2 Parametric

Parameter NameAttribute value
Brand NameTE Connectivity
Is it Rohs certified?conform to
MakerTE Connectivity
Reach Compliance Codeunknown
Is SamacsysN
Connector bracket typeCONNECTOR ACCESSORY
Manufacturer's serial number696412
Base Number Matches1

Preview

Download Datasheet
This browser does not have Java enabled.
TE Connectivity
 My Cart |
 My Part Lists | Sign In/Register
English
(Change)
Have a Question?
Chat with a Product
Information Specialist
What can we help you find?
Products
Industries
Resources
About TE
My Account
Innovation
Support Center
Home > Products > Terminals & Splices > Product Feature Selector > Product Details
8­696412­2 Product Details
Miscellaneous Terminals

Always EU RoHS/ELV Compliant
 (
Statement of Compliance
)
Product Highlights:
Terminal Style = Shur­Plug
Insulation Support
Wire Range = 1.25­2.00² [16­14] mm [AWG]
Not For Use With Double Wire
Length = 23.13 mm
View all Features
 Share
 Print
 Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
8­696412­2

TE Internal Number: 8­696412­2
 Preliminary
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Related Products:
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Insulation Support = Insulation Support
Color = Blue
Finish = Tin
Product Series = .156
Wire/Cable Type = Regular Wire
Dimensions:
Length (mm [in]) = 23.13 [0.911]
Insulation Diameter (mm [in]) = 2.67 ­ 4.06 [.105 ­ .160]
Body Features:
Wire Range (mm [AWG]) = 1.25­2.00² [16­14]
Double Wire = No
Material = Brass
Insulation Material = Nylon
Sleeve Finish = Tin
Sleeve Material = Copper
Contact Features:
Terminal Style = Shur­Plug
Industry Standards:
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Not relevant for lead free process
RoHS/ELV Compliance History = Always was RoHS compliant
Packaging Features:
Packaging Method = Small Pack
Packaging Quantity = 50/Box
Other:
Brand = TE Connectivity
Proprietary Name = PIDG
