F-219
PHT–110–04–L–S
PHF–130–01–L–D
PHT–125–01–L–D
(2.54 mm) .100"
PHF–110–04–L–S
PHT, PHF SERIES
PRESS-FIT HEADERS & SOCKETS
PHT Board Mates:
SSW, SSQ, ESW,
ESQ, BCS, BSW,
CES, SLW, PHF, SSM
PHT Cable Mates:
IDSD, IDSS
PHF Board Mates:
TSW, MTSW, MTLW,
EW, ZW, TSS, ZSS,
TSM, TSSH, PHT, DW, HW
= (single row only)
PHT
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
PLATING
OPTION
ROW
OPTION
OTHER
OPTION
01
= 10 µ" (0.25 µm)
Gold on post,
Matte Tin on tail
–L
= Single
Row
–S
–“XXX”
= Polarized
Position
02 thru 50
50
(2.49)
.098
(2.54) .100
SPECIFICATIONS
For complete specifications
see www.samtec.com?PHT
or www.samtec.com?PHF
Insulator Material:
Liquid Crystal Polymer
Contact Material:
Phosphor Bronze
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
Current Rating (PHT/PHF):
4.8 A per pin
(2 pins powered)
Operating Temp Range:
-55 °C to +125 °C with Gold
(PHF) Insertion Depth:
(3.68 mm) .145" to
(6.35 mm) .250"
RoHS Compliant:
Yes
No. of positions x (2.54) .100
= Double
Row
100
(2.54) (5.02)
.100 .198
99
(0.64)
.025
SQ
–D
LEAD
STYLE
–01
–02
–03
A
(2.54)
.100
(5.08)
.200
(7.62)
.300
(10.16)
.400
(5.84)
.230
A
A
(3.10)
.122
(3.10)
.122
A
(3.10)
.122
(0.31)
.012
A
(3.10)
.122
–04
STYLE
–02, –03 & –04
STYLE
–01
(1.19)
.047
STYLE
–01
STYLE
–02, –03 & –04
PROCESSING
Contact ipg@samtec.com
PHF
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
PLATING
OPTION
ROW
OPTION
OTHER
OPTION
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
= (single row only)
01
= 10 µ" (0.25 µm)
Gold on contact,
Matte Tin on tail
–L
= Single
Row
–S
–“XXX”
= Polarized
Position
02 thru 50
01
(2.41)
.095
ALSO AVAILABLE
(MOQ Required)
• Other platings
No. of positions x (2.54) .100 + (0.51) .020
= Double
Row
02
(2.54) (4.95)
.100 .195
–D
(2.54) .100
01
LEAD
STYLE
–01
–02
–03
–04
A
(8.50) .335
(11.05) .435
(13.59) .535
(16.13) .635
TOOLING
• Press-Fit
PHT: CAT-PT-PH-1XX-X-X
PHF: CAT-PT-PH-1XX-X-B
For more information, visit
www.samtec.com/tooling
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
A
A
A
A
A
STYLE
–03 & –04
STYLE
–02
STYLE
–01
(1.19)
.047
(0.31)
.012
STYLE
–01
STYLE
.123
–02
(3.12)
STYLE
–03 & –04
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
