F-219
LPHS–04–24–L–RT1–GP
LPHS–04–24–L–VP1–GP
(12.00 mm) .472"
(PWR)
(1.27 mm) .050"
(SIG)
LPHS SERIES
EXTreme LPHPower SOCKET ASSEMBLY
™
Mates with:
LPHT
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?LPHS
Insulator Material:
Black LCP
Terminal Material:
Signal: Brass
Power: Copper Alloy
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
Current Rating:
Power: 30 A per power blade
(4 blades powered)
Signal: 1 A per signal contact
Operating Temp Range:
-40 °C to +105 °C
Voltage Rating:
250 VAC
Standard Creepage:
(2.86 mm) .113"
(with -VP1 power)
(5.63 mm) .222"
(with -RTX power)
Standard Clearance:
(2.69 mm) .105"
(with -VP1 power)
(1.36 mm) .054"
(with -RTX power)
RoHS Compliant:
Yes
LPHS
POWER
POSITIONS
SIGNAL
POSITIONS
PLATING
TAIL
GP
(Total, 2 per power bank)
–02, –04,
–06, –08, –10
–16, –20,
–24, –32
(Total)
= 10 µ" (0.25 µm)
Gold on contact,
Matte Tin on tail
–L
= Vertical Press-fit
–VP1
–RT1
–RT2
B
(5.08)
.200
(12.00) .472
(5.08)
.200
= Right-angle Through-hole
(Use with (1.60 mm) .062"
thick board)
(5.11)
.201
= Right-angle Through-hole
(Use with (2.36 mm) .093"
thick board)
(12.29)
.484
(5.83)
.230
(18.00)
.709
(15.21)
.599
APPLICATION
PROCESSING
Lead–Free Solderable:
Yes
(-RT1 & -RT2 option)
(2.51)
.099
(1.27)
.050
(4.53)
.178
(4.50)
.177
LPHS–04–24–L–VP1–GP
SIGNAL
POSITIONS
POWER POSITIONS
(–02)
(0.64)
.025
(2.50)
.098 (2.58) (3.33)
.102 .131
(0.38)
.015
(5.72)
.225
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
A
(–02)
B
(–04)
A
(–04)
B
(–06)
A
(–06)
B
(–08)
A
(–08)
B
(–10)
A
(–10)
B
–16
–20
–24
–32
(31.64)
1.918
(34.18)
1.346
(36.72)
1.446
(41.80)
1.646
(25.88)
1.019
(28.42)
1.119
(30.96)
1.219
(36.04)
1.419
(43.64) (37.88) (55.64) (49.88) (67.64) (61.88) (79.64) (73.88)
1.718 1.491 2.191 1.964 2.633 2.436 3.135 2.909
(46.18) (40.42) (58.18) (52.42) (77.18) (64.42) (82.18) (76.42)
1.818 1.591 2.291 2.064 2.763 2.536 3.235 3.009
(48.72) (42.96) (60.72) (54.96) (72.72) (66.96) (84.72) (78.96)
1.918 1.691 2.391 2.164 2.863 2.636 3.335 3.109
(53.80) (48.04) (65.80) (60.04) (77.80) (72.04) (89.80) (84.04)
2.118 1.891 2.591 2.364 3.063 2.836 3.535 3.309
ALSO AVAILABLE
(MOQ Required)
• Other platings
• 28 Signal positions
• No Guide post
A
(7.49)
.295
CREEPAGE
AND
CLEARANCE
(12.00) .472
(1.27) .050
Notes:
Series is rated
up to 60 A per power bank.
Some lengths, styles and
options are non-standard,
non-returnable.
The Molex EXTreme
LPHPower
™
line is a
second source to the
Samtec LPHS Series
* EXTreme LPHPower
is a trademark of Molex
Incorporated.
™
(0.46)
.018
(0.64)
.025 SQ
(2.50) .098
(21.42)
.843
(3.30)
.130
DIA
Selectively loading
contacts achieves customer
specific creepage and
clearance requirements.
Contact asp@samtec.com
(6.83)
.269
(3.30) .130 DIA
(3.84) .151
LPHS–04–24–L–RTX–GP
TOOLING
(9.20)
.362
(3.25)
.128
• Press-Fit
(3.07)
.121
DIA
(2.46) .097
(3.07)
.121
DIA
CAT-PT-LPHS-XX-XX
For more information, visit
www.samtec.com/tooling
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
