F-219
TD –108–G–AA
TS –119–G–A–1
HTS–115–T–C–2
(2.54 mm) .100"
TS, TD, HTS SERIES
PRECISION MACHINED TERMINAL STRIPS
SPECIFICATIONS
For complete specifications see
www.samtec.com?TS,
www.samtec.com?TD or
www.samtec.com?HTS
Insulator Material:
Black G.F. Polyester (TS, TD)
Black Liquid Crystal Polymer
(HTS)
Terminal Material:
Brass, except Style G is
Phosphor Bronze
Plating:
Au over 50 µ" (1.27 µm) Ni or
Sn over 100 µ" (2.54 µm) Cu
or 50 µ" (1.27 µm) Ni
Operating Temp Range:
-55 °C to +125 °C with Gold
-55 °C to +105 °C with Tin
RoHS Compliant:
Yes
Lead-Free Solderable:
Wave only
Mates with:
SS, SD, HSS, SL,
SDL, ESS, ESD
TYPE
STRIP
1
NO. PINS
PER ROW
PLATING
OPTION
LEAD
STYLE
= Single
Row Terminal
Strip
TS
(2.54) .100 x No. of Positions
(2.54)
.100
(2.54)
.100 TYP
= 20 µ" (0.51 µm) Gold
Except –J & –L are
10 µ" (0.25 µm) Gold
–G
–T
= Tin
= Single Row
High Temp
Terminal Strip
HTS
(2.54)
.100
01
thru
32
=TS Series
(2.54) .100 x No. of Positions
(5.08)
.200
(2.54)
.100
(2.54)
.100 TYP
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
= Double Row
Terminal Strip
TD
= HTS & TD Series
01
thru
36
FILE NO. E111594
(2.54)
.100
Note:
Some lengths, styles and options
are non-standard, non-returnable.
–AA
(0.46)
.018
DIA
(1.78)
.070
DIA
(0.46)
.018
DIA
(4.22)
.166
(0.64)
.025
DIA
(1.78)
.070
DIA
(1.32)
.052
(3.96)
.156
±.015
–A, –A–1, –A–2
(4.22)
.166
–C, –C–1, –C–2
Y
(1.83)
.072
DIA
(3.99)
.157
(2.54)
.100
(0.89)
.035
LEAD
STYLE
–A
–A–1
–A–2
(DIA) (±.015)
(0.46) (3.96)
.018
.156
(0.64)
.025 (5.33)
(0.89) .210
.035
X
LEAD
STYLE
–C
–C–1
–C–2
(DIA) (±.015)
(0.46) (3.96)
.018
.156
(0.64)
.025 (5.33)
(0.89) .210
.035
X
Y
(1.32)
.052
X
Y
X
Y
Component No. = T-1R5-
-A Component No. =T-1R0-
-A-X Component No. =T-1R7
-C Component No. =T-1R2-
-C-X Component No. =T-1R9-
–G–1
(0.51)
.020 DIA
(1.78)
.070 DIA
(0.51)
.020
(1.32)
.052 DIA
(0.46)
.018 DIA
(4.47)
.176
–J
(1.83)
.072
DIA
(7.62)
.300
± .015
(3.18)
.125
± .010
(1.07)
.042
DIA
(1.07)
.042
–L–1, –L–2, –L–3
(1.83)
.072 DIA
LEAD
STYLE
–L–1
–L–2
–L–3
(DIA)
(12.95)
.510
(9.14)
.360
(6.60)
.260
Y
(±.015)
(17.86)
.703
(14.05)
.553
(11.51)
.453
Y
(12.90)
(1.02) .508
.040 ± .015
(4.75)
.187
(3.81)
.150
(1.32)
.052 DIA
(0.51)
.020 DIA
(0.76)
.030
(1.32)
.052
DIA
(0.64)
.025
SQ
Z
Y
Component No. = T-1R5-
Component No. = S-1P1-
Component No. = S-1W1
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
