F-219 SUPPLEMENT
YTQ–116–01–F–Q
YTQ–110–01–L–5
YTS–114–01–F–6
(2.00 mm) .0787"
YTS, YTQ SERIES
HIGH-DENSITY SOCKET STRIP
SPECIFICATIONS
For complete specifications
see www.samtec.com?YTS
or www.samtec.com?YTQ
Insulator Material:
Black Liquid Crystal
Polymer
Contact Material:
Phosphor Bronze
Operating Temp Range:
-55 °C to +125 °C
Plating:
Sn or Au over
50 µ" (1.27 µm) Ni
Insertion Depth:
(2.62 mm) .103" to
(5.03 mm) .198"
Max Cycles:
100 with 10 µ" (0.25 µm) Au
RoHS Compliant:
Yes
Mates with:
YTT, YTW, YTE, TMMS
Choice of four,
four,
five or six row
five or six row
(6.35 mm)
.250"
(2.00 mm)
.0787" TYP
PROCESSING
YTS Lead–Free Solderable:
Wave Only
YTQ Lead–Free Solderable:
Wave or reflow with
Matte Sn plating
(2.00 mm)
.0787" pitch
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
TYPE
SOCKET
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
PLATING
OPTION
ROW
OPTION
OTHER
OPTION
= Flat Tail
(Style –01 only)
YTS
02 thru 50
= Square Tail
YTQ
=10 µ"
(0.25 µm)
Gold contact,
Matte Tin
on tail
–L
= Four
Row
–Q
–5
–6
–“XXX”
=Polarized
Position
(Indicate
position
number)
300
06
=Gold flash
on contact,
Matte Tin
on tail
LEAD
STYLE
–F
= Five
Row
= Six
Row
No. of
rows
x
(2.00)
.0787
295
01
A
(2.29)
.090
(15.24)
.600
(5.28)
.208
TYPE
SOCKET
B
(0.25) (0.51)
.010 x .020
(0.51)
.020 SQ
– 01
– 02
YTS
YTQ
(2.00)
.0787
TYP
– 03
No. of rows x (2.00) .0787 + (0.30) .012
(6.35)
.250
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
–Q
(0.38)
.015
A
(2.00) .0787
TYP
Due to technical progress, all designs, specifications and components are subject to change without notice.
–5
B
–6
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
