MICRO SWITCH™ Watertight
Miniature Basic Switches
V15W Series
Datasheet
MICRO SWITCH™ V15W Series
Watertight Miniature Basic Switches
Honeywell MICRO SWITCH™ V15W Series miniature, sealed basic switches feature industrial-grade performance
(IP-rated sealing and 10 A electrical rating). These redesigned and upgraded switches are cost-effective solutions for a
variety of applications.
The V15W switch with sealed plunger and sealed wire leads conforms to the IP67 environmental seal rating
(temporary submersion). The IP67 seal rating is designed for indoor and outdoor applications on commercial
appliances, industrial equipment, surface transportation, and agriculture equipment where the switch could be
exposed to liquid or particulate contaminants.
In addition, the V15W Series is designed to control logic level/computer based circuits or electrical circuits up to 10 A.
Electrical connectivity for the switch is achieved via combination quick connect/solder terminals or sealed wire leads.
A wide variety of levers for the V15W Series are available to enhance the application flexibility of the switch package.
The V15W Series is further enhanced with certification from CQC (Asia-Pacific), ENEC (Europe), UL and cUL
(Americas) agencies for global applications.
What makes our switches better?
Watertight. Dust tight. Leaded versions are sealed to IP67
High current capacity: this V-sized sealed switch is rated up
to 10 A!
Many different switch characteristics, actuators,
and terminations resulting in thousands of potential
configurations
Product performance matched to customer design
expectations
VALUE • CUSTOMIZATION • RELIABLE
ENVIRONMENTAL PROTECTION • FLEXIBLE
2
sensing.honeywell.com
Features
and Benefits
EXCELS IN DUSTY, DIRTY, WET CONDITIONS
Silicone rubber plunger seal and epoxy resin
assure the V15W Series delivers
high sealing capability with an
IP67 rating on all pre-leaded switches
that
makes them a great choice for wet, dirty, and/or dusty application settings.
V-sized sealed switch rated to 10 A!
HANDLES LOW VOLTAGE AND POWER-DUTY LOADS WITH EASE
MICRO SWITCH™ V15W Series basic switches are available with a choice of
silver alloy or gold-plated silver alloy contacts
to easily control low-voltage
logic level applications. The silver alloy contacts are designed for controlling power-
duty ac or dc circuits.
REDUCES INSTALLATION TIME
Offered with pre-leaded 300 mm wire, the V15W Series can reduce and simplify
installation.
DESIGN FLEXIBILITY
Available with pin plungers, stainless steel levers, three types of terminations, and a
variety of switch characteristics to meet an assortment of equipment requirements,
MICRO SWITCH™ V15W Series switches also boast electrical ratings from 0.1 A
up to 10 A for design flexibility in one package size.
WORLDWIDE USE
The V15W Series is certified to UL, cUL (North America), CQC (Asia-Pacific), and
ENEC (Europe) for world-wide applications.
sensing.honeywell.com
3
Potential Applications
FOOD PACKAGING PLANTS
Performs a variety of position and counting functions
ATV AND OFF-ROAD VEHICLES
Often used in brake light assemblies, brake position detection, handle bar controls,
run-away prevention, shift lever position, and marine controls
GARBAGE AND SALT TRUCKS, COMMERCIAL BUSES, VANS
Operates in a variety of functions, including lift position, door ajar/open, salt spreader
on/off detection, and wheel chair lifts (sense position of movable platforms)
VENDING MACHINES
Aids with product selection, liquid dispensing on/off position, and product delivery
detection
GOLF CARTS
Determines foot pedal position and initiates reverse alarm on shift lever
MEDICAL EQUIPMENT
Often used on hospital bed controls, dental chairs, foot pedals, and pneumatic
switches
FORKLIFT AND RIDING LAWN MOWER SEATS
Senses operator presence or absence and shifter position
4
sensing.honeywell.com
MICRO SWITCH™ Watertight Miniature Basic Switches
PRODUCT NOMENCLATURE
V15W
—
D
Z
200
Operating
Force
A
Lever
Location
No lever
02
Lever
Type
Pin plunger
—
Mounting
Holes
Metric
(Ø 3,1 mm)
A
Contact
Material
Standard
silver alloy
W1
Electrical Rating
(must be included)
Special
Designator
A special designator
code is used to
indicate some
non-standard feature
such as a special
actuator, wire color,
wire length, connector,
etc. Review product
specification to
determine the nature
of the non-standard
feature. This code
will consist of up to
three alphanumeric
characters. A blank
designates no
difference from
standard listing.
Switch Type
Terminals/Wiring
4,8 mm x
0,8 mm
4,8 mm x
0,5 mm
300 mm long
wires
1
Special
Circuitry
MICRO SWITCH™
D
V-Basic
Standard
E
V15W
Watertight
Switch
W
Z
P
C
SPDT
SPNO
SPNC
050
100
150
200
300
2
50 g max.
100 g max.
150 g max.
200 g max.
2
300 g max.
2
W1
W2
W3
0.1 A, 125/250 Vac
0.1 A, 30 Vdc
6 A, 125/250 Vac
5 A, 30 Vdc
10 A, 125/250 Vac
2
5 A, 30 Vdc
2
A
B
Lever pivot
far from
plunger
Lever pivot
near plunger
01
02
03
04
05
06
99
Short straight
lever
Standard
straight lever
Long straight
lever
Simulated
roller lever
Roller lever
Long roller
lever
Special
K
USA
(Ø 2,9 mm)
A
Gold-plated
silver alloy
S
1
Electrical rating and
wire type (standard)
W1: 24 AWG (0,20 mm
2
)
W2: 18 AWG (0,82 mm
2
)
W3: 16 AWG (1,31 mm
2
)
200 g and 300 g operate
forces are the only forces
allowed with the W3 electrical
rating.
Not all combinations of model code are available.
Please contact your Honeywell provider/representative for assistance.
Table 1. Specifications
Characteristic
Circuitry
Operating force
Termination
Actuators (levers 300 series
stainless steel)
Agency certification
Sealing
Plunger sealing
Operating temperature
Mechanical life (cycles)
Dielectric strength
Switch resistance (initial)
Insulation resistance
Contact material
Housing material
Table 2. Electrical Ratings
Switch option
W1
W2
W3
cUL, UL per 61058-1, File 12252
0.1 RA (Resistive Amp) 125/250 Vac
0.1 RA 30 Vdc
6 RA (Resistive Amp) 125/250 Vac
5 RA 30 Vdc
10 RA (Resistive Amp) 125/250 Vac
5 RA 30 Vdc
CQC per GB15092-1, ENEC per 61058-1
0.1 A 125/250 Vac
0.1 A 30 Vdc
6 A 125/250 Vac
5 A 30 Vdc
10 A 125/250 Vac
5 A 30 Vdc
Parameter
SPDT, SPNO, SPNC
50 gf, 100 gf, 150 gf, 200 gf, 300 gf
quick connect: 4,8 mm x 0,8 mm
quick connect: 4,8 mm x 0,5 mm
300 mm lead wire length
pin plunger, short straight lever, standard straight lever, long straight lever,
simulated roller lever, roller lever, long roller lever
UL, cUL, ENEC, CQC
IP67 (leaded versions)
IP00 (quick-connect versions due to exposed terminal)
silicone
-40 °C to 85 °C [-40 °F to 185 °F]
1,000,000 cycles min. @ 180 cycles/minute max.
500 Vac (RMS) for 1 minute
leakage current ≤ 0.5 mA between open contacts
300 mΩ max.
100 MΩ min. (500 Vdc for 1 minute)
silver alloy, gold-plated silver alloy
PBT thermoplastic polyester
Note: cUL, UL, ENEC, and CQC use temperature is 55 °C max. for wired versions, 85 °C max. for terminal versions.
