1
Introduction
The AS5170-SO_EK_SB socket board is used for quick programming of the AS5170A and
AS5170B magnetic rotary position sensors without soldering due to its ZIF socket.
This board can be used in combination with the AS5xxx-EK-USB-PB UART Programming Board
and the provided LabVIEW evaluation software.
Figure 1: Kit content
1
Pos.
1
Item
AS5170-SO_EK_SB
Comment
Socket board
ams Eval Kit Manual, Confidential
[v1-0] 2016-Apr-26
Page 3
Document Feedback
AS5170 Socket Board
2
Board description
The PCB offers direct connecting option to the AS5xxx-EK-USB-PB UART Programmmer with
the 4-pin single-row connector on the left side. A ZIF Open-Top-Socket for SOIC8 packages is
mounted in the middle. Pin 1 of the IC is indicated by a small white dot on the PCB.
All passive components needed for proper operation are included on bottom side the PCB.
Figure 2: AS5170 socket board
ZIF socket for SOIC8
Connector to
AS5xxx-EK-
USB-PB UART
Programmer
ams Eval Kit Manual, Confidential
[v1-0] 2016-Apr-26
Page 4
Document Feedback
AS5170 Socket Board
3
AS5170-SO_EK_SB Hardware
3.1
AS5170-SO_EK_SB schematics
Figure 3: AS5170-SO_EK_SB schematics
ams Eval Kit Manual, Confidential
[v1-0] 2016-Apr-26
Page 5
Document Feedback
