F-219
TW–08–09–F–T–165–100
TW–16–06–T–D–500–100
(2.00 mm) .0787"
TW–20–03–L–Q–400–085
TW SERIES
THROUGH-HOLE BOARD STACKERS
SPECIFICATIONS
For complete specifications
see www.samtec.com?TW-TH
Insulator Material:
Black Liquid Crystal Polymer
Terminal Material:
Phosphor Bronze
Plating:
Sn or Au over
50 µ" (1.27 µm) Ni
Current Rating:
5.2 A per pin
(2 pins powered)
Operating Temp Range:
-55 °C to +105 °C with Tin;
-55 °C to +125 °C with Gold
RoHS Compliant:
Yes
Lead–Free Solderable:
Yes
Board Mates:
CLT, SQT, SQW, ESQT,
TLE, SMM, MMS
Cable Mates:
TCSD
Specify stacker
height in (0.13 mm)
.005" increments
OTHER SOLUTIONS
Paste In Hole (PIH) processing.
Contact Samtec ASP Group.
Choice of
one through
six rows
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
ALSO AVAILABLE
(MOQ Required)
• Other platings
(2.00 mm)
.0787 pitch
FILE NO. E111594
TW
Notes:
For added mechanical
stability, Samtec recommends
mechanical board spacers be
used in applications with gold or
selective gold plated connectors.
Contact ipg@samtec.com for
more information.
This Series is non-standard,
non-returnable.
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
below.
PLATING
OPTION
ROW
OPTION
STACKER
HEIGHT
TAIL
SPEC
02 thru 50
= Gold flash
on post,
Matte Tin on tail
–F
–L
–T
= Single
Row
–S
–“XXX”
= Stacker
Height
in inches
(0.13 mm)
.005"
increments
Other Solutions
2 mm Shunt
See 2SN Series.
= 10 µ" (0.25 µm)
Gold on post,
Matte Tin on tail
= Double
Row
–D
–T
300
04
= Matte Tin
No. of
rows
x
(2.00)
.0787
= Triple
Row
= Tail Length
in inches
(0.13 mm) .005"
increments
Example: -150
Example: –250
= (3.81 mm)
= (6.35 mm)
.150"
.250"
–“XXX”
–“XXX”
= Polarized
Position
(Specify
position to
be removed)
Surface
Mount
See previous page.
(2.00)
.0787
TYP
= Four
Row
–Q
–5
–6
LEAD
STYLE
OAL
(8.20) .323
(9.60) .377
(13.60) .535
(14.10) .555
(15.10) .594
(17.10) .673
(19.10) .751
(21.10) .830
(11.60) .456
(15.60) .614
(10.08) .397
(28.19) 1.110
Low
Profile
See TMM Series.
01
–S, –D*, –Q
= Five
Row
–T, –5, –6
295
(0.51) .020 SQ
POST
STACKER
(1.27)
HEIGHT
See
OAL
.050
MIN
Chart
TAIL
(0.00) .000 MIN
(2.00) .0787
Right-
angle
See TMM Series.
= Six
Row
*
*
ROW OPTION
–01
–02
–03
–04
–05
–06
–07
–08
–09
–10
–11
–12
Shrouded
Double
Row
See ZLTMM
Series.
*
Style –08 & –12 = S & D only
–S, –D*, & –Q
–T, –5, –6
STACKER HEIGHT
(3.05) .120 MIN
(4.06) .160 MIN
–S, –D*, –Q
–T, –5, –6
*
–D with stacker height greater than (4.06 mm) .160"
will not have standoffs.
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
