HSA50R075J Product Details
Fixed Resistors
Always EU RoHS/ELV Compliant
(
Statement of Compliance
)
Product Highlights:
Fixed Resistor
Resistor Type = Power Resistor
Resistance Selection = <1K Ω
Resistance = .075 Ω
Power Rating = 50.00 W
View all Features
Share
Print
Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
HSA50R075J
(416301867)
TE Internal Number: 416301867
Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
View 3D PDF
Documentation & Additional Information
Product Drawings:
HSA50 WIDE BORE (PDF, English)
Catalog Pages/Data Sheets:
1309350_PASSIVE_COMPONENT (PDF, English)
Aluminium Housed Power Resistors Type HS Series (PDF, English)
417734606_RESISTIVE_SOLUTIONS_RAIL (PDF, English)
817734594_POWER_FILTERING_AND_RESISTIVE_SOLUTIONS_... (PDF, English)
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files: (CAD Format & Compression Information)
2D Drawing (DXF, Version AM)
3D Model (IGES, Version AM)
3D Model (STEP, Version AM)
Additional Information:
Product Line Information
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Product Type = Fixed Resistor
Resistor Type = Power Resistor
Element = Wirewound
Electrical Characteristics:
Resistance Selection (Ω) = <1K
Resistance (Ω) = .075
Power Rating (W) = 50.00
Tolerance (%) = 5
Termination Features:
Termination Type = Solder Lug
Body Features:
Mount Style = Chassis Mount
Package, Component Size = 72.5 x 30
Configuration Features:
Number of Terminations = 2
Number of Resistors = 1
Industry Standards:
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Not relevant for lead free process
RoHS/ELV Compliance History = Always was RoHS compliant
Conditions for Usage:
Temperature Coefficient (ppm/°C) = ±50
Operation/Application:
Application = High Power
Packaging Features:
Package Type = Loose Piece Tray
Other:
Series = HS
Brand = CGS
