F-219 (Rev 23JAN19)
S2M–105–01–L–D–DS
S2M–105–02–F–D
(2.00 mm) .0787"
S2M–110–01–L–D
S2M SERIES
HIGH-RELIABILITY CABLE SOCKET
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?S2M
Insulator Material:
Black Liquid Crystal Polymer
Contact Material:
BeCu
Plating:
Sn or Au over
50 µ" (1.27 µm) Ni
Current Rating (S2M/T2SD):
2.6 A per pin
(2 pins powered)
Operating Temp Range:
-55 °C to +125 °C
Insertion Depth:
(3.05 mm) .120" to
(3.25 mm) .128"
Max Cycles:
100 with 10 µ" (0.25 µm) Au
RoHS Compliant:
Yes
Board Mates:
T2M
Cable Mates:
T2SD
Up to 30
positions per row
Mates with
Tiger Eye™ discrete
wire cable assemblies
MATED HEIGHT
• Locking clip
S2M
SM= (7.06 mm) .278"
THT= (6.17 mm) .243"
T2M
PROCESSING
Lead–Free Solderable:
Yes
SMT Lead Coplanarity:
(0.10 mm) .004" max
No. of positions x (2.00) .0787 + (0.35) .014
04 02
(2.00)
(0.51) .020
.0787
Choice of surface mount
or through-hole
HIGH-SPEED CHANNEL PERFORMANCE
Rating based on Samtec reference
channel. For full SI performance data
visit Samtec.com or contact
SIG@samtec.com
G b p s
8
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
(4.25)
.167
S2M
(2.08)
.082
(2.00)
.0787
1
NO. OF
(2.00) .0787
POSITIONS
03 01
LEAD
STYLE
(4.52)
.178
PLATING
OPTION
(4.65)
.183
(6.30)
.248
(1.42)
.056
D
(1.52)
.060
OPTION
OTHER
OPTION
05, 07, 10,
15, 20, 25, 30
(Per Row)
(0.51)
.020
= Through-
hole
–01
OTHER
SOLUTIONS
(6.00)
.236
No. of positions x (2.00) .0787 + (14.38) .566
No. of positions x
(2.00) .0787 + (8.28) .326
02
= Surface
Mount
–02
= Gold flash on contact,
Matte Tin on tail
–F
–L
= (5.50 mm)
.217" DIA
Polyimide
film Pick &
Place Pad
(–SM only)
–K
= Tape &
Reel
Packaging
–TR
= 10 µ" (0.25 µm)
Gold on contact,
Matte Tin on tail
(1.78)
.070
01
= Locking Clip
(Manual
placement
required)
(–SM only)
–LC
(8.50)
.335
See www.samtec.com?T2SD
(0.66) .026 DIA
–DS
No. of positions x (2.00) .0787 + (0.35) .014
04 02
(2.00)
(0.51) .020
.0787
= Screw Down
(N/A with–LC)
(mates with
–T2M–DS)
–DS
ALSO AVAILABLE
(MOQ Required)
• Other platings
(4.25)
.167
(2.08)
.082
(2.00) .0787
03 01
(4.52)
.178
(0.51)
.020
(6.30)
.248
(4.65)
.183
(1.42)
.056
(1.52)
.060
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
–TH
(2.00)
.0787
–SM
–LC
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
No. of positions x (2.00) .0787 + (14.38) .566
WWW.SAMTEC.COM
