F-219
PTF–130–03–L–D
PTF–110–01–L–D
PTT–115–01–L–D
(2.00 mm) .0787"
PTT, PTF SERIES
PRESS-FIT HEADERS & SOCKETS
PTT Mates with:
PTF, ESQT, PTHF,
SQW, SQT, SMM
PTF Mates with:
PTT, TMMH, TMM, MTMM,
MMT, TW, LTMM, ZLTMM
PTT
1
NO. PINS
PER ROW
01
PLATING
OPTION
ROW
OPTION
OPTION
SPECIFICATIONS
For complete specifications
see www.samtec.com?PTT
or www.samtec.com?PTF
Insulator Material:
Black Liquid Crystal Polymer
Contact Material:
Phosphor Bronze
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
Current Rating:
2.9 A per pin
(2 pins powered)
Operating Temp Range:
-55 °C to +125 °C
Insertion Depth:
(2.67 mm) .105" to
(3.56 mm) .140"
Normal Force:
60 grams (0.59 N) average
Max Cycles:
100 with 30 µ" (0.76 µm) Au
RoHS Compliant:
Yes
02 thru 50
= 10 µ" (0.25 µm) Gold contact,
Matte Tin on tail
–L
= Single Row
–S
= Double Row
–D
–T
–“XXX”
= Polarized
Position
(2.00)
.0787
No. of positions x (2.00) .0787
04
ROW
OPTION
A
(2.00) .079
(4.00) .158
(6.00) .236
(8.00) .314
(10.00) .393
(12.00) .472
= Triple Row
A
01
(2.00)
.0787
(0.50) .020 SQ
(3.20)
.126
–S
–D
–T
–Q
–5
–6
= Four Row
–Q
–5
–6
= Five Row
(2.00)
.0787
= Six Row
(8.03)
.316
(0.91)
.036
(2.82) .111
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
PTF
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
PLATING
OPTION
D
OPTION
ALSO AVAILABLE
(MOQ Required)
• Other platings
–“XXX”
= 10 µ" (0.25 µm) Gold on post,
Matte Tin on tail
02 thru 50
–L
= Polarized
Position
TOOLING
• Press-Fit
PTT: CAT-PT-PH-1XX-X-X
PTF: CAT-PT-PH-1XX-X-B
For more information, visit
www.samtec.com/tooling
No. of positions x (2.00) .0787
+ (0.30) .012
(4.00)
.158
02
(2.00)
.0787
LEAD
STYLE
A
(6.35)
.250
(9.14)
.360
– 01
01
–03
A
(-01)
(0.30)
.012
(0.50)
.020
Style –01
(0.94) .037
Style –03
(6.35)
.250
(2.29)
.090
A
(-03)
(2.00)
.0787
(2.29)
.090
(0.30) .012
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
