RF-18 (Rev 06APR18)
SMP–J–B–GF–ST–1450
SMP–PF–P–HH–ST–EM3
SMP–J–C–GF–RA–CA7
SMP–PF–P–GF–ST–TH2
SMP–J–B–GF–ST–0645
SMP–J–C–GF–ST–CS5
SMP SERIES
50
W
SMP JACKS/PLUGS & ADAPTOR
SMP-PF, SMP-PL,
SMP-PS, SMP-PC
Mate with:
SMP-B Bullet Adaptor
Cable Mates:
RF405, RF25S
SMP
GENDER
TYPE
PLATING
ORIENTATION
TERMINATION
SPECIFICATIONS
For complete specifications see
www.samtec.com?SMP-TH,
www.samtec.com?SMP-EM,
www.samtec.com?SMP-B or
www.samtec.com?SMP-CA
Shell Material:
Au plated Brass (–TH2, –EM3)
Au plated BeCu (–J–B, –J–C)
Contact Material:
Brass (–TH2, –EM3)
BeCu (–CA)
Insulator Material:
PTFE
Impedance:
50
W
Frequency Range:
DC to 40 GHz,
DC to 20 GHz (25 AWG)
Working Voltage:
335 Vrms min
Dielectric Withstanding:
500 Vrms min
Engagement Force:
-PF: 15 lbs. max
-PL: 10 lbs. max
-PS & -PC: 2 lbs. max
Disengagement Force:
-PF: 2 lbs. min
-PL: 2 lbs. min
-PS & -PC: 0.5 lbs. min
Operating Temperature:
-65 °C to +165 °C
RoHS Compliant:
Yes
= Plug, Full Detent
–PF
–PL
= PCB
Mount
–P
= Plug, Limited Detent
= Plug, Smooth Bore
–PS
= 10 µ"
(0.25 µm)
Gold center
contact,
Gold Flash
outer contact
(–TH2 only)
–GF
= Straight
A
DIA
(4.19) .165
(5.99) .236
(5.08)
.200
–ST
= Through-hole
–TH2
GENDER
–PF
–PL
–PS
–PC
(4.34)
.171
= Drop-in
Edge Mount
(Not available
with –PC)
–EM3
= Plug, Catcher’s Mitt
(5.78)
.228 SQ
A
DIA
(4.09)
.161
(5.99)
.236
SQ
A
DIA
(2.09)
.082
–PC
= 30 µ"
(0.76 µm)
Gold center
and outer
contact
(–EM3 )
–HH
(4.43)
.174
(4.06)
.160
(2.13)
.084
(7.09)
.279
(1.88)
.074
–EM3
APPLICATION
–PC–TH2
–PF/–PL/–PS–TH2
EXTRACTION TOOL
• CAT-EX-SMP-01
Contact Samtec
LENGTH BOARD
SPACE
–0645
–1450
(9.05)
.356
(17.10)
.673
BOARD
SPACE
SMP
J
TYPE
PLATING
ORIENTATION
BULLET
LENGTH
Leave blank
for cable end
CABLE
END
Leave blank
for bullet type
PROCESSING
Lead–Free Solderable:
Yes
ALTERNATIVE
SOLUTIONS
The SMP Series is an
alternative to the Corning
Gilbert GPO Series.
The SMPM Series is in
development.
= Bullet Adaptor
–B
–C
= Cable End
(3.40)
.134
DIA
(6.45)
.254
= 10 µ"
(0.25 µm)
Gold center
contact, Gold
Flash outer
contact
–GF
= Straight
–ST
= Right-angle
(Not available
with –B)
–RA
–0645
= 6.45 mm
(.254")
= 14.50 mm
(.571")
–1450
= RG 405
(.086" DIA)
Semi-flexible
Cable
–CA7
= MWC-2550-01
25 AWG
Microwave
Cable
(5.31)
.209
–CS5
–0645
(3.55)
.140
DIA
(14.50)
.571
(8.00)
.315
(7.00)
.276
Note:
While optimized for 50
W
applications, this connector
can also perform well in certain
75
W
applications. Contact
RFGroup@samtec.com for
further information.
(4.36)
.172
–1450
–ST–CXX
–RA–CXX
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
