F-219
MPSS–02–16–L–03.25–SR
MPSS–08–16–L–03.25–DR–NUS
(5.00 mm) .1969"
MPSS SERIES
POWERSTRIP /30 CABLE ASSEMBLY
™
SPECIFICATIONS
For complete specifications
see www.samtec.com?MPSS
Insulator Material:
Nylon 6/6
Contact Material:
Copper Alloy
Plating:
Au or Sn over
50 µ" (1.27µm) Ni
Latch:
Nylon 6/6
Operating Temp Range:
-30 °C to +105 °C
Voltage Rating:
600 VAC/848 VDC
Wire:
14 or 16 AWG
RoHS Compliant:
Yes
Mates with:
MPT
MPSS/MPT-V
CURRENT
WIRE
RATING
GAUGE
(PER PIN)
14 AWG
19.7 A
16 AWG
15.9 A
1 PIN POWERED
Dual leaf
blade
contacts
Positive
latching
system
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
• Positive latching
(5.00 mm)
.1969"
pitch
Polarized
Guide Posts
MPSS
NO. OF
POSITIONS
WIRE
GAUGE
PLATING
OPTION
ASSEMBLED
LENGTH
END 1
OPTION
END 2
OPTION
(Available
with –DR
only)
COMPONENTS
• For body, see
www.samtec.com?IMS5
• For contacts, see
www.samtec.com?CC46L
www.samtec.com?CC46R
–02, –03,
–04, –06, –08
NO. OF
POSITIONS
–14
–16
A
B
(20.26) .798
(25.25) .994
= 10 µ"
(0.25 µm)
Gold on
contact
–L
–“XX.XX”
= Wire Length
in Inches
(83.00 mm)
03.25" min.
= Single
End
= Double
End
–SR
–DR
–02
–03
–04
–06
–08
(30.07) 1.184 (15.27) .601
(35.07) 1.381
(40.08) 1.578
= Matte Tin
–T
= Notch up,
straight
–NUS
–NDS
= Notch
down,
straight
(50.09) 1.972 (35.26) 1.388
(60.10) 2.366 (45.26) 1.782
(18.55) .730
(22.59) .890
(10.16)
.400
(5.00)
.1969
A
B
–DR–NUS
Assembled Length ± (3.2) .13
–DR–NDS
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
