F-219 (Rev 11MAR19)
ACP–16–01–G–00.25–S–S–P–1
ACP–16–06–G–00.25–T–T–M–1
ACP-16 SERIES
IP68 SEALED 16 mm CABLE ASSEMBLY
SPECIFICATIONS
For complete specifications see
www.samtec.com?ACP-16
Insulator Material:
Thermoplastic
Terminal Material:
Brass
Contact Material:
Brass/BeCu
Operating Temp Range:
-10 °C to +105 °C
Housing:
–P: Thermoplastic
–M: Zinc Alloy
Cable Jacket:
TPU
RoHS Compliant:
Yes
CURRENT RATING
LEAD
PINS
CCC per
STYLE POWERED
PIN
–01
14
1.3 A
–02
10
2.6 A
2
(plus 8
–06
signal pins
11.6 A
powered
@ 1 A)
For general reference only.
See www.samtec.com?ACP-16
for complete test data or contact
AccliMate@samtec.com for
applications requiring higher
current carrying capacity.
Mates with:
ACR-16, ACRK-16
Solutionator
DESIGN IN A MINUTE
®
• Easy sealed cable solutions
• Build a standard or flexible custom online
• Calculate performance, current rating,
voltage drop
• Live chat with AccliMate
™
engineers
for custom options
• Variety of shells, pin sizes, signal,
power, I/O interfaces
• Assembly and field kits available
Field
termination
kit option
Choice of
terminals or sockets
ACP
16
LEAD
STYLE
PLATING
LENGTH
END
1
END
2
HOUSING
MATERIAL
KEYING
OPTIONS
DUST CAPS
• DCA-ACP-16-M-X (Metal)
• DCA-ACP-16-P-X (Plastic)
= 0.5 mm DIA (14)
terminals or sockets
(28 AWG)
–01
–02
–06
= 10 µ"
(0.25 µm)
= Length in meters = Terminal = Terminal
Gold over
(00.25 m min.
50 µ"
to 50.00 m max.)
(1.27 µm)
= Socket = Socket
Ni on contact Standard lengths
–G
–“XX.XX”
–T
–T
= Plastic
–P
–S
–S
= Metal
–M
= Orange,
45°
–1
= 1.0 mm DIA (10)
terminals or sockets
(24 AWG)
–BC
= Blunt
Cut
(1.5) .060
DIA (2)
(1.0) .040
DIA (10)
= 1.5 mm DIA (2)
terminals or sockets
(16 AWG)
+ 0.5 mm DIA (8)
terminals or sockets
(28 AWG)
• Visit sealedio.samtec.com
for a complete list of sealed
systems
APPLICATION
–02
(0.5) .020
DIA (8)
(0.5) .020
DIA (14)
–06
ACP–16
ACR–16
ALSO AVAILABLE
(MOQ Required)
• Other assembly lengths
(12.50)
.492
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
–01
Overall Length (XX.XX) ±2 %
(22.50)
.886
(55.45) 2.18
–P HOUSING
Due to technical progress, all designs, specifications and components are subject to change without notice.
(56.65) 2.23
–M HOUSING
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
