F-219 (Rev 04DEC18)
ERCD–020–10.00–TEU–STR–3–R
(0.80 mm) .0315"
ERCD–050–08.00–SBR–STR–3–D
ERCD SERIES
EDGE RATE COAX CABLE ASSEMBLIES
®
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?ERCD
Cable:
34 AWG coax
ribbon cable
Signal Routing:
50 W Single-Ended
Plating:
Au over 50 µ" (1.27 µm) Ni
Operating Temp Range:
-25 °C to +105 °C
Current Rating:
1.3 A per pin
(2 pins powered)
RoHS Compliant:
Yes
Mates with:
ERF8 (-L), ERM8 (-L)
Broadside wiping
contacts reduce
unwanted
crosstalk
34 AWG
micro ribbon
coax cable
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
HIGH-SPEED CHANNEL PERFORMANCE
ERCD
Rating based on Samtec reference channel.
For full SI performance data visit Samtec.com
or contact SIG@samtec.com
14
G b p s
Rugged metal
latching system
FILE NO. E111594
ERCD
NO. POSITIONS
PER ROW
WIRE
LENGTH
END
NO. 1
END
NO. 2
WIRING
OPTION
LATCH
POSITIONS
PER ROW
–010
–013
–020
–025
–030
–040
–050
–060
END TO END
DV to DV
Edge Mount (-TEX)
A
(22.66) .892
(25.06) .987
(30.66) 1.207
(34.65) 1.364
(38.66) 1.522
(46.66) 1.837
(54.66) 2.152
(62.66) 2.467
–010, –013,
–020, –025, –030,
–040, –050, –060
OAL = Wire Length +
B
02
01
= Wire Length
in Inches
(43.7 mm) 01.72"
minimum
–“XX.XX”
= Terminal, Top Right
–TTR
–TTL
= Pin 1 to Pin 1
–1
–2
–3
–4
= Terminal, Top Left
= Pin 1 to Pin 2
(Required
callout)
Specify
LATCH
from
chart
02
= Terminal, Bottom Right
01
–TBR
–TBL
= Terminal, Bottom Left
Note:
Mating
= Pin 1 to Pin N -1
connectors
require
latching
option –L
= Pin 1 to Pin N
LATCH
ASSEMBLY
End No. 1 Standard Latch,
End No. 2 Squeeze Latch
End No. 1 Squeeze Latch,
End No. 2 Standard Latch
Both Ends Standard Latch
No Housing
Both Ends Standard Latch
Both Ends Squeeze Latch
End No. 1 Screw Option,
End No. 2 Friction Latch
End No. 1 Friction Latch,
End No. 2 Screw Option
Both Ends Screw Option
End No. 1 Screw Option,
End No. 2 Squeeze Latch
End No. 1 Squeeze Latch,
End No. 2 Screw Option
B
(23.47) .924
A
= Socket, Top Right
–STR
–STL
†
–L
♦
–R
–D
–N
*
–B
–F
–S
–C
†
–G
♦
–T
= Socket, Top Left
DV to Edge Mount (-TEX)
(26.69) 1.051
(29.92) 1.178
= Socket, Bottom Right
(18.75)
.738
–SBR
–SBL
–TEU
–TED
Notes:
Cable lengths longer than
40.00" (1 meter) are not
supported with S.I. test data.
Design your High-Speed Cable
with Samtec’s High-Speed
Cable Solutionator
®
at
www.samtec.com/hdr
Some lengths, styles and
options are non-standard,
non-returnable.
(10.15)
.400 (7.72)
.304
= Socket, Bottom Left
(13.76)
.542
= Terminal, Edge Mount Up
= Terminal, Edge Mount Down
END NO.1
(–STL SHOWN)
END NO.2
(–TTR SHOWN)
†
–TEX on second end.
♦
–R & –T option only available with
–TEX on first end.
on both ends.
*
–TEX –G option only available with
–L &
–B option only available with
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
