F-219
RPBE–01–01–E
RPCE–01–E–00.25–D–C5E
RPBE, RPCE SERIES
IP68 SEALED ETHERNET SOCKET
Mates with:
RCE
SPECIFICATIONS
For complete specifications
see www.samtec.com?RPBE
Insulator Material:
Black Liquid Crystal Polymer
Contact:
Phosphor Bronze
Operating Temp Range:
-40 °C to +75 °C
Seal:
Rubber
Screw:
Stainless Steel
Nut:
Stainless Steel
Sealing Washer:
Rubber
RPBE
NO. OF
PORTS
LEAD
STYLE
PLATING
–01, –02
A
= Right-angle
–01
A
= 50 µ" (1.27 µm) Gold on contact,
Flash Gold on tail
–E
NO. OF
PORTS
(12.50)
.492
(23.00)
.906
B
C
–01
–02
(46.10)
1.815
(67.10)
2.642
(36.95) (19.72)
1.455 .776
(57.95) (40.72)
2.281 1.603
(7.50)
.295
DUST CAPS
PORT
PART NO.
DCA-RPBE-01-01-L
DCA-RPBE-02-01-L
B
C
(17.67)
.696
APPLICATION
RCE
Meets CAT3,
CAT5 and CAT5e
specifications
TYPE
–01
–01
–02
Push-On/
DCA-RPBE-01-01-P No Latch
Latching
(3.51)
.138
DIA
Some components
removed for clarity
Note:
Meets IP68 requirements
for dust and waterproof sealing
when mated or with dust cap.
Audible click
positive latching
RPBE
Mates with:
RCE
SPECIFICATIONS
For complete specifications
see www.samtec.com?RPCE
Insulator Material:
Glass Filled Thermoplastic
Contact:
Phosphor Bronze
Shield:
Phosphor Bronze
Operating Temp Range:
-40 °C to +75 °C
Overmold:
Rite Flex 640F
Seal:
Rubber
Screw:
Stainless Steel
Nut:
Stainless Steel
Sealing Washer:
Rubber
Wire:
24 AWG
RPCE
01
–E
PLATING
WIRE
LENGTH
END
OPTION
C5E
= (0.25 m) 9.84"
–00.25
–00.50
= 50 µ" (1.27 µm) Gold on contact, Nickel on shell
= Double Ended
–D
= (0.50 m) 19.69"
Standard lengths
(23.00)
.906
= Blunt Cut
–BC
ALSO
AVAILABLE
(MOQ Required)
01
08
Cable Length + (17.01) .669
• Other wire lengths
DUST CAPS
PORT
PART NO.
DCA-RPBE-01-01-L
DCA-RPBE-02-01-L
TYPE
–01
–01
–02
DCA-RPBE-01-01-P Push-On/
No Latch
Latching
(46.10)
1.815
(11.68)
.460
Note:
Meets IP68 requirements
for dust and waterproof sealing
when mated or with dust cap.
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
